Lightolier Lytespan 9276 User manual

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Lytespan®Track Lighting System 9276

Page 1 of 2 PowerWash™T5 2 Foot Track Mounted 24 Watt High Output Fluorescent

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Features

1. Ballast & Reflector Housing: Aluminum with die-cast endcaps.

2. Ballast: 24w electronic.

3. Flood Reflector: Aluminum, with highly reflective and

semispecular finish for a smooth wash of light.

4. Louver: Aluminum, for glare control, with captive locking springs for easy

installation and removal.

5. Vertical Pivot: Die cast rotation housing with positive rotation stop provides

0°(NADIR) –130°vertical rotation in both directions.

6. Sockets: 600v rated mini bi pin sockets with 90°rotor lock to engage

contacts and retain with a positive detent.

7. Socket Bracket: Adjustable steel, mounting bracket slides out for easy

lamping.

8. Attachment Fitting: Molded polycarbonate; pin rotates fitting into track to

engage luminaire.

9. Brass Contact: Extends for connection to second circuit in Advent®Lytespan

track.

10. Track Adapter Arm: Die-cast aluminum with integral polarity keyguard.

Electrical

Rapid Start High Power Factor, Class P Electronic Ballast

Power Factor: >.97%

Sound Rated: A

Minimum Start Temp: 0°F

Input Watts: 9276 52W

9277 26W

Finish

All painted finishes are baked enamel.

Labels

UL, c.U.L.

Advent®is a registered trademark of Lightolier.

Ordering Information

Catalog No. Finishes Track Mountings Lamps

9276WH Matte White Compatible with all Lytespan®Track Systems. 2 x 24w T5 High Output (Fluorescent)

9276BK Matte Black

9276AL Metallic Aluminum Not compatible with ProSpec Track, Clamp-On

9277WH Matte White Monopoint, Slope Ceiling Adapter or Extension 1 x 24w T5 High Output (Fluorescent)

9277BK Matte Black Wands.

9277AL Metallic Aluminum

EXAMPLE: With track located 4’from wall and multiple units spaced 6’on center and aimed

45˚from horizontal, the illumination on wall 4’from ceiling will be 33 f.c. beneath units and

27 f.c. between units.

0’1’2’3’4’5’

Lighting Data 2 - 24W T5 High Output

1’100 78 40 18 9 5

2’78 62 35 16 7 3

3’48 41 26 15 7 3

4’31 27 19 12 7 4

5’18 16 12 8 5 3

6’11 11 8 6 4 3

7’776432

8’554322

9’333222

120 88 120

92 74 92

63 56 63

48 45 48

29 20 29

23 22 23

15 15 15

11 11 11

999

107 38 107

80 33 80

51 29 51

37 20 37

21 17 21

17 15 17

11 10 11

878

666

Footcandles on Wall

Track 3 Feet From Wall Single Unit Multiple Units

4’6’

3’

Distance From Ceiling

45˚

1’54 44 27 13 5 1

2’53 45 30 16 8 4

3’39 34 24 15 8 4

4’29 25 19 13 8 5

5’20 18 15 11 7 5

6’13 12 10 8 6 4

7’997643

8’765543

9’544332

62 53 62

69 62 69

56 52 56

46 44 46

38 37 38

27 26 27

20 20 20

17 17 17

13 13 13

56 37 56

60 45 60

47 39 47

38 34 38

32 29 32

22 21 22

17 16 17

14 14 14

11 10 11

54 25 54

56 32 56

43 29 43

33 27 33

28 24 28

19 17 19

14 13 14

12 12 12

999

Track 4 Feet From Wall Single Unit Multiple Units

4’5’6’

4’

Distance From Ceiling

45˚

Footcandles are average and rounded off and data for multiple units are based on a minimum of five units.

Footcandles on wall:

One Lamp, with louver,

aimed 45˚down.

Two Lamps, without louver,

aimed 45˚up.

Two Lamps, with louver,

aimed 45˚down.

Beam Center

Lamp Information:

2 X 24W T5 High Output

Mini Bi-Pin Fluorescent (9276)

1 x 24W T5 High Output

Mini Bi Pin Fluorescent (9277)

111 58 111

84 50 84

54 41 54

41 35 41

24 21 24

19 18 19

13 12 13

999

777

5’

0’1’2’3’4’5’

1’37 32 23 15 9 5

2’37 33 24 16 10 6

3’33 30 23 16 10 6

4’24 22 17 13 9 5

5’18 17 14 10 8 5

6’14 13 11 9 7 5

7’10 10 8 7 5 4

8’776543

9’655433

57 54 57

60 57 60

58 56 58

44 43 44

36 35 36

30 30 30

25 25 25

19 18 19

15 15 16

49 42 49

51 45 51

49 45 49

36 34 36

30 29 30

25 24 25

21 20 21

15 15 15

13 13 13

44 32 44

45 35 45

44 36 44

32 28 32

25 23 25

22 20 22

18 17 18

13 12 13

11 11 11

Track 5 Feet From Wall Single Unit Multiple Units

4’5’6’

5’

Distance From Ceiling

45˚

Beam Center

0˚30˚

90˚

60˚

180˚150˚

120˚

90˚

0˚30˚

90˚

60˚

Lytespan®Track Lighting System 9276

Page 2 of 2 PowerWash™T5 2 Foot Track Mounted 24 Watt High Output Fluorescent

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 •(508) 679-8131 •Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:
