PARTS LIST
HARDWARE IS ACTUAL SIZE
(Unless otherwise indicated)
(Not actual size)
(Not actual size)
(Not actual
size)
RA RB
RC
RD RF
RI RJ LA
LC
LD
LE
SAFETY INSTRUCTIONS
Most injuries are caused by misuse and/or not following instructions. Use
caution when using this system.
Owner must ensure that all players know and follow these rules for safe operation of
the system.
To ensure safety, do not attempt to assemble this system without following the
instructions carefully. Check entire box and inside all packing material for parts and/
or additional instruction material. Before beginning assembly, read the instructions
and identify parts using the hardware identier and parts list in this document.
Proper and complete assembly, use and supervision are essential for proper
orientation and to reduce the risk of accident or injury. A high probability of serious
injury exists if this system is not installed, maintained, and operated properly.
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY OR
PROPERTY DAMAGE AND WILL VOID WARRANTY.
• If using a ladder during assembly, use extreme caution.
• Two capable adults are recommended for this operation.
• Check base daily for leakage. Leaks will cause system to fall.
• Assemble the pole sections properly. Failure to do so could cause the pole
sections to separate during play or transport.
• Minimum operational height is 7’6” (2.23m) to the rim.
ID Part # Description Qty
TP 1018842 Top Pole 1
MP 1018878 Middle Pole 1
BP 1018882 Bottom Pole 1
PA HA01800 Gas Spring 1
PB 825619 Rim 1
PC 1018938 Short Y-Arm 2
PD 1018939 Long Y-Arm 2
PF 1018837 Rear Lifter Arm 2
PG ZA10185 Bellows 1
PH 1018977 Backboard 1
PI 502027H Adjustment Handle 1
PJ 502049G Trigger 1
FS16400 Warning Sticker (Applied) 1
PK 604091 Height Sticker 1
PM CF01700 Pole Cap 1
PN DD00800 Net 1
PO 502056 Plastic Guard 1
PP CA00885 Zip Tie 2
PQ 1008630 Spring Bracket 1
PR 800165 Rim Cover Plate 1
PT Z090013 Clamp Plate 2
PU Z090014 Hold Down Base Bracket 2
PV ZA01800 Bracket Back Plate 2
AG 510022 Wheel 2
AH BD00100 1/2” x 8” Axle 2
AI 510035 Base Cap 1
AJ 510082 Base 1
AK ZA02600 U-Bolt Washer Plate 1
AP 1018883 Pole Brace 2
AR CH00199 Slide Collar 1
AS CH00399 Locking Knob 4
AT 510011 Base Plug 1
AU CA00299 Left Frame Pad 1
AV CA00399 Right Frame Pad 1
AW CA00999 Bottom Frame Pad 2
AX 1018699 Slide Collar Clamp 1
AY 1018587 Slide Collar Bracket 2
Rim Hardware (1001327)
RA BS01000 #7 x 3/8” Screw 4
RB 300104 3/8” Push Nut 2
RC 302009 5/16” x 1 1/4” Carriage Bolt 2
RD 300128 Jam Nut 2
RE 302084 4” U-Bolt 1
RF 302090 5/16” Nylock Flange Nut 4
RG 1001137 Compression Spring 2
RH 510038 3/8” x 5 1/2” Axle 1
RI 804018 Rim Pivot Bracket 1
RJ 804033 Spring Retainer Plate 1
Competition Lock Down Hardware (HH00400)
LA 300145 3/8” Zinc Nut 2
LC 300203 3/8” x 5.31” J-Bolt 2
LD 300204 3/8” x 3/4” Eye Bolt 2
LE 302204 Cement Anchor 2
