lifelong LLMB50 User manual
DIRECT COOL
SINGLE DOOR
REFRIGERATOR
Quiet OperationSleek &
Compact Design
Environment-friendly
Refrigerant
Easy Temperature
Control Knob
1 YEAR
PRODUCT WARRANTY
5 YEAR
COMPRESSOR WARRANTY
Index:
Features
Important Safety Instructions
Know Your Product
Installation Method
Operating Instructions
Maintenance and Care
Technical Specifications
Diagram of electrical principle
Packing list
Warranty Terms and Conditions
E-waste management
This symbol on the products and or accompanying documents means that used
electrical and electronics products should not be mixed with general household waste. For
proper treatment, recoveries, recycling, please take these products to designated collection
points, where they will be accepted on a free of charge basis.
DIRECT COOL
SINGLE DOOR
REFRIGERATOR
FEATURES:
Mechanical temperature control thermostat
50 Litres capacity
Adjustable legs
Separate chiller compartment
Manual defrost
Mini Size - place saving & easy to move
finish outer body
Important Safety Instructions:
WARNING
To reduce the risk of fire, electric shocks,
or personal injury while using your
refrigerator, follow these basic
precautions:
◆Read all the instructions carefully before using the refrigerator.
◆DANGER or WARNING: Risk of child entrapment.
◆To avoid the possibility of child entrapment; please take the following precautions
before disposing off the refrigerator.
- Remove all doors from the unit.
- Keep the shelves out of reach of small children
◆This appliance can be used by children, 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
◆Children should not be allowed to play with the appliance.
◆
Cleaning and maintenance of the fridge should not be done by children without
proper supervision.
◆Do not store explosive substances such as aerosol cans with flammable propellant
inside the refrigerator.
◆This appliance is intended to be used for household use and similar applications
such as
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type
environments;
WARNING
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord
is damaged, get it replaced by Lifelong authorized service personnel.
This refrigerator should be properly grounded for your safety. The power cord of this
refrigerator is equipped with a three-prong plug which matches with standard three prong wall
outlets to minimize the possibility of electrical shock.
Do not, under any circumstances, remove the grounding plug from the power cord.
This refrigerator requires a standard 220-240V- /50 Hz electrical outlets with three-prong
ground.
This refrigerator is not designed to be used with an inverter.
The cord should be secured behind the refrigerator and not left exposed or dangling to
prevent any accidental injury.
Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull
straight out from the receptacle.
Do not use an extension cord with this appliance. If the power cord is too short, have a
qualified electrician or service technician install an outlet near the appliance. Use of an
extension cord can negatively affect the performance of the unit.
Know Your Product:
1 .Evaporator 2.Ice tray 3. Shelf
5. Thermostat 6.Door sealing stripe 7. Bottle guard
Note: Figure is for illustration purpose only. Actual figure may vary. Please refer to the
actual product.
Installation Method:
1. Place the refrigerator on a plain and even surface.
2. Avoid placing upside down or horizontal. The angle should be not less than 45°between
the cabinet and the ground when the inclination is necessary.
3. In order to maintain proper cooling and avoid higher energy consumption, please ensure to
keep the fridge by maintaining a gap of 5cm from the wall and also ensure to have a space of
30cm from the top.
4. Don’t keep the refrigerator in a humid environment.
5. Don’t place the refrigerator near heat sources (stove, warmer etc.) or expose the device to
direct sunlight.
Operating Instruction:
HOW TO USE THE REFRIGERATOR:
1.
Before you put the refrigerator for first time use please carry out the following steps;
2.
Do not connect the power cord to any wall outlet.
3.
Keep the refrigerator door open for 30 minutes , so that if there is any left out foul
odour , it will be dispersed out to the ambient.
4.
Open the refrigerator door; assemble all the accessory parts to it’s respective position.
Don’t keep any food items or beverages for the first time inside the fridge.
5.
6.
Insert the power cord into the wall socket.
7.
Set the thermostat to maximum position and switch ON the refrigerator.
8.
Allow the refrigerator to run for 8 hours; thereafter shut down the refrigerator.
9.
Now put the food items and beverages inside the refrigerator.
Adjust the thermostat knob based on the season
a. For winter- Adjust the thermostat knob to minimum position
b. For summer- Adjust the thermostat knob to maximum position
Note: Please refer to the self - explanatory image below; the figure is for illustration purpose
only. Actual figure may vary. Please refer to the actual product for thermostat configuration.
Switch ON the refrigerator
Defrost: it is required to periodically inspect the freezer chamber for excess ice deposition If
the ice layer is more than 5 mm, please undertake defrost action immediately.
Switch off the refrigerator, remove all food and beverage items and rotate the
thermostat knob in anti-clockwise direction and bring it to off position.
Once the defrost procedure is done, replace food items, and switch ON the fridge
ICE PREPARATION
Pour fresh and clean water into the ice-making tray and maintain the water level as indicated
in the ice tray; put the ice tray into the evaporator. Set the thermostat to the maximum position.
Ice is made within 2 - 3 hours. Slightly twist round the ice-making tray while taking out the
ice.
.
ƚƚĞŶƚŝŽŶ
:KLOH VWRULQJ WKH IRRG LWHPV ZUDS WKH IRRG LWHP LQ DOXPLQLXP IRLO DQG VWRUH WKH VDPH LQ D
FRQWDLQHU ZLWK SURSHU OLG 7KLV ZLOO SUHYHQW WKH VPHOO DQG NHHS WKH IRRG IUHVK DQG KHDOWK\
7KHUH VKRXOG EH SURSHU VSDFH EHWZHHQ HDFK IRRG LWHPV GR QRW VWXII H[FHVV IRRG LWHPV
LQVLGH WKH UHIULJHUDWRU
7R FRQVHUYH HQHUJ\ GRQ¶W VXEMHFW WKH UHIULJHUDWRU GRRU WR IUHTXHQW RSHQ DQG FORVXUH
DĂŝŶƚĞŶĂŶĐĞ ĂŶĚ ĂƌĞ
3HULRGLF PDLQWHQDQFH PD\ HQKDQFH WKH OLIH RI WKH UHIULJHUDWRU 3RZHU FRUG PXVW EH
SXOOHG RXW IURP WKH ZDOO RXWOHW EHIRUH FDUU\LQJ RXW WKH PDLQWHQDQFH DFWLYLW\
5HPRYH WKH DFFHVVRU\ VXFK DV ERWWOH JXDUG VWHHO ZLUH VKHOYH
$EUDVLYH SRZGHU ZDVKLQJ VRGD EHQ]HQH SHWURO DFLG DOFRKRO DQG KRW ZDWHU HWF VKRXOGQ¶W
EH XVHG WR FOHDQ WKH UHIULJHUDWRU WKHVH PD\ GDPDJH WKH SDLQWLQJ DQG ILQLVK RI WKH SURGXFW DQG
DOVR GDPDJH WKH RWKHU SODVWLF SDUWV XVHG LQ WKH IULGJH
6DIHW\ LQVSHFWLRQ DIWHU PDLQWHQDQFH
&KHFN LI WKH SRZHU FRUG LV RN
&KHFN LI WKH SRZHU SOXJ LV RN
&KHFN LI WKH ZDOO VRFNHW LV RN
dƌŽƵďůĞ ^ŚŽŽƚŝŶŐ
3KHQRPHQRQ
3OHDVH FKHFN LW DV EHORZ
5HIULJHUDWLRQ
3UREOHP
&KHFN IRU SRZHU IDLOXUH
&KHFN LI VXSSO\ YROWDJH LV SURSHU
&KHFN LI WKH IXVH LV 2.
1RQVDWLVIDFWRU\
FRROLQJ
&KHFN LI WKH WKHUPRVWDW LV LQ SURSHU SRVLWLRQ
&KHFN LI SURSHU VSDFH LV PDLQWDLQHG EHWZHHQ WKH UHIULJHUDWRU
DQG DGMRLQLQJ ZDOO LQFOXGLQJ IUHH VSDFH RI FP DERYH WKH
WKH IULGJH
&KHFN LI WKH IULGJH GRRU LV VXEMHFWHG WR IUHTXHQW RSHQ
FORVXUH
&KHFN LI WKH IULGJH LV H[SRVHG WR GLUHFW VXQOLJKW RU DQ\ RWKHU
KHDW UDGLDWLQJ GHYLFH
&KHFN LI WKH UHIULJHUDWRU LV VWXIIHG ZLWK H[FHVVLYH IRRG LWHPV
)RRG LWHPV LQ IUR]HQ
VWDWH LQVLGH WKH
UHIULJHUDWRU
&KHFN LI WKH WKHUPRVWDW LV LQ PD[LPXP SRVLWLRQ
&KHFN LI WKH UHIULJHUDWRU LV VWXIIHG ZLWK H[FHVVLYH IRRG LWHPV
$EQRUPDO QRLVHV
FRPLQJ IURP WKH
UHIULJHUDWRU
&KHFN LI WKH DSSOLDQFH LV SODFHG RQ XQHYHQ VXUIDFH
&KHFN LI WKH IULGJH LV LQ FRQWDFW ZLWK DQ\ DGMRLQLQJ JRRGV
&RPSUHVVRU GRHVQ¶W
VWRS DQG UXQV
FRQWLQXRXVO\
&KHFN LI WKH UHIULJHUDWRU LV VWXIIHG ZLWK H[FHVV IRRG LWHPV
&KHFN LI WKH IULGJH GRRU LV VXEMHFWHG WR IUHTXHQW RSHQ
FORVXUH
Technical Specifications:
Main technical data:
Model
Climate Type
ST/T
Electrical Shock Protect Mode
I
Total Capacity (L)
50
Rated Voltage (V)
220-240
Rated Frequency (Hz)
50
Rated Current (A)
0.7
Rated Input Power (W)
70
Energy Consumption (kW.h/24h)
0.7
Refrigerant
R134a
Refrigerant Weight(g)
35
Vesicant
C
5
H
10
(CP)
Net Weight (kg)
14.5
Noise dB (A)
40
Overall Dimension(mm) [Width Depth Height]
453*455*503
Notice:
All data covered in this catalogue is given as general information. Lifelong reserves the right to
change or modify its product line up without prior notice.
LLMB50
Bulb
bulb
bulb
Replacing Bulb
Disconnect the power supply before replacing the bulb. Remove the used bulb by
turning anti-clockwise. Fix the new bulb by turning clockwise (the bulb should be
screw bulb less than 15W).
Diagram of electrical principle:
Packing list:
Model
Water tray
1
Refrigerator Shelf
1
Instruction manual
1
Ice Tray
1
LLMB50
