LIELONGREN LLR010A User manual
1/ 5
LIELONGREN
Large Number Display Alarm Clock
Model: LLR010A
KEY FEATURES
-Ultra-Clear Large Display with Curved-Edge Screen
-Dual Smart Alarm with Snooze
-Dual Alarm Mode with Buzzer and Vibrator
-Dual USB Port with Fast Charging
-Battery Backup with Battery Status Indicator
DEFAULT SETTINGS
Time Format: 24 hour
Time: 12:00
Date: 2018/1/1
Alarm Duration: 10 mins (Adjustable)
Snooze Duration: 9 mins (Adjustable)
Alarm Mode: Buzzer
Alarm Volume: Medium (MED)
INSTALLATION
1. Plug the AC/DC adaptor to an AC household outlet, and plug the DC jack to the
back of the unit. Then your clock is ready to work for you.
2. Insert 2xAA batteries (not included) into the battery compartment to provide
backup power to the clock in the event of a temporary power interruption.
WARM TIPS
1. In setting mode, if no operation within 10 seconds, the clock will automatically
save the current settings and return to time mode.
2. If AC power is interrupted, the LED display will go off and the alarm will not
function. But the backup battery will keep the time and all settings of your unit.
3. If AC power is interrupted, press SNOOZE button, the time will display for 5
seconds for emergency situations.
2/ 5
Note:
The USB-2 can reach DC 5V/2A output only when USB-1 is not being used.
3/ 5
SETTING TIME FORMAT
In time mode, press TIME button to switch time format between 12-hour and 24-
hour. If it is in afternoon, the P (PM) indicator will be on or off correspondingly.
SETTING TIME
1. In time mode, press and hold the TIME button to enter time setting mode, the
hour digits flash. Press or to set the current hour (hold to advance
rapidly).
2. Press TIME button again, the minute digits flash. Press or to set minute
(hold to advance rapidly).
3. Press TIME button again, the year digits flash. Press or to set year (hold
to advance rapidly).
4. Press TIME button again, the month digits flash. Press or to set month
(hold to advance rapidly).
5. Press TIME button again, the day digits flash. Press or to set day (hold to
advance rapidly).
6. Press TIME button again, exit time setting mode.
SWITCHING ALARM ON/OFF
In time mode, press Alarm-1 (Alarm-2) button to switch on or off the alarm, the AL1
(AL2) indicator will be on or off correspondingly.
SETTING ALARMS
1. In time mode, press and hold Alarm-1 (Alarm-2) button to enter alarm setting
mode, the hour digits flash. Press or to set the current hour (hold to
advance rapidly).
2. Press Alarm-1 (Alarm-2) button again, the minute digits flash. Press or to
set the current minute (hold to advance rapidly).
3. Press Alarm-1 (Alarm-2) button again, the alarm day digits flash. Press or
to set the current alarm day (hold to advance rapidly).
1-1: Single day alarm
1-5: Working day alarm
6-7: Weekend Alarm
1-7: Every day alarm
4. Press Alarm-1 (Alarm-2) button again, the alarm duration digits flash. Press
or to set the current alarm duration (hold to advance rapidly).
4/ 5
※Alarm Duration: Default 10 minutes (1-30 minutes adjustable)
5. Press Alarm-1 (Alarm-2) button again, exit alarm setting mode.
SETTING SNOOZE DURATION
1. In time mode, press and hold SNOOZE button to enter snooze duration setting
mode and the digits flash. Press or to set the current duration (hold to
advance rapidly).
※Snooze duration: Default 9 minutes (1-60 minutes adjustable)
2. Press SNOOZE button again, exit snooze duration setting mode.
STOPPING ALARM WHEN IT GOES OFF
When Alarm 1 (Alarm 2) is sounding, the related AL1 (AL2) indicator flash. Press any
buttons (except SNOOZE button) to stop and reset the alarm to go off the next day.
ACTIVATING SNOOZE MODE WHEN ALARM GOES OFF
When Alarm 1 (Alarm 2) is sounding, press SNOOZE button, the alarm will suspend
and go off again after the set snooze duration.
SETTING ALARM MODE
Buzzer: Wake by Buzzer
Vibration: Wake by Vibrator
Both: Wake by Buzzer and Vibrator
SETTING BRIGHTNESS
Adjust to your favorite brightness level by turning the knob at the right side.
KEY SPECIFICATION
Buzzer Volume:
-LO: 50dB
-MED: 65dB
-HI: 80dB
Vibrating Amplitude:
-LO: Weak
-MED: Medium
-HI: Strong
5/ 5
Adapter Input: AC 100-240v, 50/60Hz
Adapter Output: DC 5V/3A
USB 1 Output: DC 5V/1A (Maximum)
USB 2 Output: DC 5V/2A (Maximum)
Power Cord Length: 5ft
Vibrator Cord Length: 6ft
TROUBLE SHOOTING
If your clock displays irrelevant time or does not function properly, which may be
caused by electro- static discharge or other interference, unplug the DC jack to
disconnect the AC power (and remove the backup battery). The clock will be reset to
default settings and you need to set it again.
CARE OF YOUR PRODUCT
1. Place your clock on a stable surface, away from sources of direct sunlight or
excessive heat or moisture.
2. Protect your furniture when placing your units on a natural wood and lacquered
finish by using a cloth or protective material between it and the furniture.
3. Clean your unit with a soft cloth moistened only with mild soap and water.
Stronger agents such as Benzene, thinner or similar materials can damage the
surface of the unit. Make sure the unit is unplugged before cleaning.
4. If the unit is not to be used for a prolonged period, such as a month or longer,
remove the batteries to prevent possible corrosion. Should the battery
compartment become corroded or dirty, clean the compartment thoroughly and
replace the batteries.
PACKAGE LIST
1 x Alarm Clock
1 x Vibrator
1 x Power Adapter
1 x Power Cord
1 x User Manual
1 x Warranty Card
LIELONGREN Customer Service Team
Email: cst4lielongr[email protected]
