Lidix CL-2 User manual
CL-2 Service Manual
Service Manual
For CL-2
Date. Rev. Notice.
2018.05 1.0
2018.12 1.2
CL-2 Service Manual
1. Please read this service manual, before test and
setting change of CL-2.
2. Follow this manual to prevent any
physical/material damage and operating safely
and solve the problem.
3. Reproduction, copying, or fabrication of any
information contained in this manual, without
prior consent of LIDIX, is forbidden.
2
CL-2 Service Manual < Contents >
1. SAFETY
1-1. Safety Information
1-2. Operational Environment
1-3. Installation/Moving
1-4. Maintenance/Checking
2. APPEARANCE
2-1. Machine Overview
2-2. Operation Panel Overview
2-3. Basic Operation
3. Counting mode
3-1. Value Mode
3-2. Fitness Mode
3-3. TITO Mode
3-4. Batch Mode
3-5. Report
CL-2 Service Manual < Contents >
4. User Setting
4-1. Function
4-2. Ex Device
4-3. UI Config
4-4. Pocket Size
4-5. Product Info
5. ENG Setting (Engineer setting)
5-0. Entering ENG setting
5-1. Count Adjustment
5-2. Motor Calibration
5-3. CIS Calibration
5-4. UV Sensor Calibration
5-5. US Calibration
5-6. MG Calibration
5-7. CF Level Settings
5-8. Fitness Level settings
5-9. ATM Fitness Level settings
5-10. Function Settings
5-11. LXS Data
5-12. TACO
CL-2 Service Manual < Contents >
6. Error Code
6-1. < ROI > error
6-2. < Value > Error
6-3. < IR > Error
6-4. < UV > Error
6-5. < MG > Error
6-6. < US > Error
6-7. < Unfit > Error
6-8. < SN > Error
6-9. < Counting Error > Error
6-10. < Etc > Error
7. Explode View
7-1. Frame Assy’
7-2. LOWER UNIT Assy’
7-3. UPPER UNIT Assy’
7-4. RC UNIT Assy’
7-5. SUB Assy’
CL-2 Service Manual < Contents >
8. Daily cleaning
9. Accessories & Specification
CL-2 Service Manual
1-1. Safety Information
Important safety symbols
7
These warnings and precautions are included in order to prevent injury to you and others, as well as preventing any potential damage to your
machine. Be sure to read and understand all of these instructions before using the machine.
Use common sense for operating any electrical appliance and whenever using your machine. Also, follow all warnings and instructions marked on
the machine and in the accompanying literature.
This section explains the meanings of all icons and signs in the user’ guide. These safety symbols are in order, according to the degree of
danger.
Warning : Hazards or unsafe practices that may result in severe personal injury.
Caution : Hazards or unsafe practices that may result in severe personal injury.
Do not attempt
Do not touch.
Do not disassemble.
Make sure the machine is grounded to prevent electric shock.
The power plug be pulled out before taking necessary action.
Follow directions explicitly.
Explanation of all icons and signs used in the user’s guide :
CL-2 Service Manual
1-2. Operational Environment
8
Warning
Do not use if the power cord is damaged or if the electrical outlet is not grounded.
►This could result in electric shock or fire.
Do not place anything on top of the machine (water, small metal or heavy objects, etc.).
►This could result in electric shock or fire.
Do not bend, or place heavy objects on the power cord.
►This could result in electric shock or fire.
Do not remove the plug by pulling on the cord; do not handle the plug with wet hands.
►This could result in electric shock or fire.
If the machine gets overheated, it releases smoke, makes strange noises, or generates an odd odor,
immediately turn off the power switch and unplug the machine.
►This could result in electric shock or fire.
Never operate the machine without the protective cover. The reflected beam, although invisible, can
damage your eyes.
►When using this product, these basic safety precautions should always be followed to reduce risk of
fire, electric shock, and injury to persons.
CL-2 Service Manual
1-2. Operational Environment
9
Caution
Be careful not to put your hand, hairs and clothes(including tie) when handling machine.
Do not forcefully pull the note out during counting.
►It can cause damage to the machine.
Be care when removing jammed notes.
►You may get injured.
Make sure the machine stops completely before opening the covers of the machine.
►Otherwise, there is a risk of an injury.
Do not disassemble the machine unless instructed in the user manual.
►It can damage the machine.
When removing jammed paper, do not use tweezers or sharp metal objects.
►It can damage the machine.
During an electrical storm or for a period of non-operation, remove the power plug from the electrical
outlet.
►This could result in electric shock or fire.
CL-2 Service Manual
1-3. Installation/Moving
10
Caution
Before moving the machine, turn the power off and disconnect the cord.
Make sure lift the machine using both hands.
►The machine could fall, causing injury or machine damage.
Do not place the machine on an unstable surface.
Make sure you plug into a grounded electrical outlet.
►Otherwise, this could result in electric shock or fire.
Do not overload wall outlets and extension cords.
►This can diminish performance, and could result in electric shock or fire.
Risk of explosion, if battery is replaced by an incorrect type
Dispose of used batteries according to the instructions
