Licetec V-Comb User manual
Instruction Manual
Table of Contents
........................................................................................................................................... pg 3
................................................................................................................ pg 4
............................................................................................................................................... pg 5
........................................................................................................................................ pg 6
............................................................................................................................................... pg 7
....................................................................................................... pg 8
........................................................................................................................... pg 10
..................................................................................................................... pg 12
................................................................................................................................. pg 13
......................................................................................................... pg 13
................................................................................................................................ pg 14
................................................................................................. pg 15
1
2
3
4
5
6
7
8
9
Before using the V-Comb
Introduction
Important Safety Information
Overview
Technical Data
Starting Up
V-Comb Capture Filter Installation
Operating the V-Comb
Maintaining the V-Comb
Treatment Period
Important Treatment Summary
Product Guarantee
Contact Details and Additional Notes
2
Introduction
Thank you for purchasing the Licetec V-Comb.
In your box, you should have the following:
1x V-Comb unit (including adaptor)
4x Disposable capture lters
1x Quick guide
1x Instruction manual
1x Cleaning brush
FEATURES
• Chemical-free head lice treatment
• Rounded stainless steel teeth with adjustable combing angles
• LED illuminated lter unit
• Disposable head lice capture lter
• Compact and ergonomic design
• AC powered device
Warning! Small parts can be inhaled, swallowed or dangerous.
Cable, due to its length, may result in strangulation or asphyxiation!
3
Please read instructions before
operating your V-Comb and
retain for future reference.
4
Important Safety Information
PLEASE READ THROUGH THESE INSTRUCTIONS BEFORE OPERATING YOUR V-COMB AND RETAIN
FOR FUTURE REFERENCE.
CAUTION
• Check that the power source electric rating is the same as the V-Comb rating and that power source is in a fully usable condition.
• To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth.
• The V-Comb can be operated by most adults under the condition that the operator has understood the operating instructions.
• The V-Comb is intended for use on head hair only and can be operated both indoors and outdoors in dry conditions only.
• Suitable for use on most adults and children over the age of three years old.
• Note that this product is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they are under supervision.
• Children (even under supervision), should not play with the device.
• Avoid contact with eyes, ears or mouth.
• Do not use if sores or broken skin are present.
• Do not immerse the main body of the V-Comb in water or any other liquid.
• Keep all electrical connections clean and dry.
• It is highly recommended to clean this product immediately after each use.
• Avoid dropping or knocking the product in any way.
• No liability can be accepted for any damage caused by non compliance with these instructions or any other improper use or mishandling.
• V-Comb device and accessories must be disposed in accordance with local WEEE regulations.
• No modication of this equipment is allowed!
• Do not position the V-Comb where it will be difcult to unplug from electrical socket.
• Do not use or store V-Comb in a location where it is exposed to direct sunlight, extreme heat or cold, water, lint, pet hair, dust, etc.
• Do not modify this equipment without authorisation of the manufacturer!
• Warning! If the equipment is modied, appropriate inspection and testing must be conducted to ensure continued safe use
of equipment.
5
Please read instructions before operating
your V-Comb and retain for future
reference.
WARNING!
Only V-Comb capture lters are to be used.
Overview
V-Comb Parts List
1. Rounded stainless steel teeth
2. Combing angle adjustment knob
3. Combing head
4. LED illuminated lter unit
5. Disposable capture lter
6. Main body
7. On/Off switch
8. Adaptor
1
2
4
5
6
7
38
6
Technical Data
Product description
Product Model
Power Adaptor Model
Input Rating
Output Rating
Power source
Electric Shock Protection
Ingress Protection
EMC protection
Operating temperature/
humidity
Storage temperature/
humidity
Weight
Service Life of V-Comb/
Accessories
Note
Vacuum powered head lice removal device
TTVC01
PSED240100S W
240V, AC 50~60Hz
24V DC 1A
240V, AC 50~60Hz
Type BF
IP22 (Protected against foreign objects equal to or greater than 12.5mm and against
falling drops of water when enclosure tilted up to 15°).
Refer to Compliance section of manual - pages 14 - 21
5°C to 40°C
RH 15% to 93% (no condensation)
-25°C to 70°C
RH 5% ≤ 93% (no condensation)
approx. 320grams
approx. 5 years (1000hrs)
approx. 10 years
Disposal of this product should be carried out in accordance with the local and
national WEEE regulations for the disposal of electronic products.
7
Starting Up
2. Before connecting V-Comb adaptor to power source,
check that the power source electric rating is the same
as the V-Comb rating and that power source is in a fully
usable condition.
To avoid risk of electric shock, this equipment must only
be connected to a supply mains with protective earth
and all electrical connections should be kept clean and
dry.
1. Check the box contents.
Warning! The V-Comb power adaptor is permanently
connected to the V-Comb and cannot be disconnected.
Please read instructions before operating
your V-Comb and retain for future
reference.
8
V-Comb Capture Filter Installation
2. Securely attach capture lter to V-Comb combing head,
ensuring it clips into place (until you hear a click).
1. Tear open a capture lter wrapper provided in the box.
The wrapper will contain a capture lter and a lid, keep
the lid aside for use after treatment.
Capture lters are designed for single use only.
(Replacement capture lters are available).
9
V-Comb Capture Filter Installation
3. Carefully attach the combing head, making sure not to
damage or crush the capture lter.
4. Align the guiding arrows (highlighted below) and twist to
lock the combing head to the main body.
Now the combing head is securely locked in correct position.
10
Operating the V-Comb
1. To change the combing angle, hold and push down the
knobs on both sides of the combing unit and adjust the
angle of the teeth. Release both knobs to secure in place.
Two set positions are available:
straight position or raking position.
2. Hair should be clean, conditioned and dry. Brush
thoroughly to remove any knots.
Separate the hair into sections, no wider than the teeth,
using hair clips. Switch on the V-Comb to begin treatment.
Always start from the nape of the neck and work your way
up, one section at a time, combing the top of the head
last. Ensure you are holding the comb the right way up.
Straight position Raking position
