LG StudioWorks 910SC User manual
Colour Monitor
USER GUIDE
GUIA DEL USUARIO
StudioWorks
910SC
i
AGENCY REGULATORY NOTICE
FCC
Compliance
Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception (which can be determined
by turning the equipment off and on), the user is
encouraged to try to correct the interference by using
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and the receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not expressly
approved by the party responsible for compliance
could void the user's (or your) authority to operate the
equipment. Only peripherals (digital input/output
devices, terminals, printers, etc.) certified to comply
with the Class B limits may be attached to this
monitor. Operation with non-certified peripherals is
likely to result in interference to radio and TV
reception.
Only shielded Signal Cables may be used with this
System.
ii
Canadian
D.O.C.
Notice
CE
Conformity
Notice
Products with the “CE” Marking comply with the
EMC Directive(89/336/EEC) and LOW VOLTAGE
Directive (73/23/EEC) issued by the Commission of
the European Community.
Compiance with these directives implies conformity
to the following European Norms :
EN 55022 ; Radio Frequency Interference
EN 50082-1:1992 ; Electromagnetic Immunity
EN 60555-2 ; Power Line Harmonics
EN 60555-3 ; Voltage Fluctuations
EN 60950 ; Product Safety
This Class B digital apparatus meets all
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe B respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
iii
iv
v
vi
vii
Table of Contents
Introduction
Features....................................................................................................A1
Monitor Registration
Notice........................................................................................................A2
Trademark Acknowledgments ....................................................................A2
Important Precautions
On Safety..................................................................................................A3
On Installation.................................................................................................A4
On Cleaning....................................................................................................A4
On Repacking.................................................................................................A4
Connecting the monitor
Connection to any IBM VGA PC compatible system ..................................A5
Connecting to an Apple Macintosh PC...........................................................A6
Location and Function of Controls
Front View.................................................................................................A7
Rear View .......................................................................................................A7
Control Panel Function
OSD Enter Button...........................................................................................A8
OSD Exit Button..............................................................................................A8
OSD Select/Adjustment Buttons.....................................................................A8
Brightness Adjustment Control .......................................................................A8
Contrast Adjustment Control...........................................................................A8
Power (DPMS) Indicator.................................................................................A8
Power ON/OFF Button....................................................................................A8
On Screen Display (OSD) Control Adjustment...................................A9
On Screen Display (OSD) Selection and Adjustment....................A10
Video Memory Modes
Factory Preset Timing Signal Chart..............................................................A16
User Modes...................................................................................................A18
Recalling Display Modes...............................................................................A18
Energy Saving Design
Power Consumption......................................................................................A19
MPR II, Self Diagnostics and DDC
Low Radiation Compliance (MPR II).............................................................A20
Self Diagnostics............................................................................................A20
DDC (Display Data Channel)........................................................................A20
Troubleshooting and Service
Troubleshooting ............................................................................................A21
Service..........................................................................................................A22
Specifications
Specifications ..........................................................................................A23
Monitor Limited Warranty.....................................................................A25
A1
Introduction
Thank you for purchasing a high resolution monitor. It will give you
high resolution performance and convenient reliable operation in a
variety of video operating modes.
Features
The monitor is a 19 inches (18.0 inches viewable ) intelligent,
microprocessor based monitor compatible with most analog RGB
(Red, Green, Blue) display standards, including IBM PC®, PS/2®,
Apple®, Macintosh®, Centris®, Quadra®, and Macintosh II family.
The monitor provides crisp text and vivid color graphics with
VGA, SVGA, XGA, and VESA Ergonomic modes (non-
interlaced), and most Macintosh compatible color video cards
when used with the appropriate adaptor. The monitor's wide
compatibility makes it possible to upgrade video cards or
software without purchasing a new monitor.
Digitally controlled auto-scanning is done with the micro-
processor for horizontal scan frequencies between 30 and
100kHz, and vertical scan frequencies between 50-200Hz. The
microprocessor-based intelligence allows the monitor to operate
in each frequency mode with the precision of a fixed frequency
monitor.
The microprocessor-based digital controls allow you to adjust
conveniently a variety of image controls by using the OSD (On
Screen Display).
The monitor has 38 memory locations for display modes, 12 of
which are factory preset to popular video modes.
This monitor is capable of producing a maximum horizontal
resolution of 1600 dots and a maximum vertical resolution of
1200 lines. It is well suited for CAD work and sophisticated
windowing environments.
For greater user health and safety, this monitor complies with the
stringent Swedish TCO’95 requirements for low radiation
emissions.
For low cost of monitor operation, this monitor is certified as
meeting the EPA Energy Star requirements, and utilizes the
VESA Display Power Management Signalling (DPMS) protocol
for power saving during non-use periods.
A2
Monitor Registration
The model and serial numbers are found on the rear of this unit.
These numbers are unique to this unit and not available to others.
You should record requested information here and retain this guide
as a permanent record of your purchase. Staple your receipt here.
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Notice
All rights reserved. Reproduction in any manner, in whole or in part, is
strictly prohibited without the written permission of LG Electronics Inc.
Trademark Acknowledgments
LG is a trademark of LG Electronics Inc.
IBM is a registered trademark and VGA is a trademark of
International Business Machines Corporation.
Warning : To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
Avertissement :
Ne pas placer cet appareil dans un endroit humide.
Cela peut entraîner un incendie ou une décharge électrique.
