OWNER’S MANUAL

LED LCD MONITOR

E1942TC

E2042TC

E2242TC

E2442TC

Please read this manual carefully before operating

your set and retain it for future reference.

LED LCD MONITOR MODEL

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGANDPREPAR-

ING

3 Unpacking

4 Partsandbuttons

5 SettinguptheMonitorset

5 - AttachingtheStandBase

5 - DetachingtheStandBase

6 - Mountingonatable

6 - Usingthecableholder

8 - Mountingonawall

9 USINGTHEMONITORSET

9 ConnectingtoaPC

9 - D-SUBconnection

9 - DVI-Dconnection

11 CUSTOMIZINGSETTINGS

12 CustomizingSettings

12 - MenuSettings

13 -PICTURE

14 -COLOR

15 -DISPLAY

16 -OTHERS

17 SUPERENERGYSAVINGSetting

18 PICTUREMODESetting

19 TROUBLESHOOTING

21 SPECIFICATIONS

21 E1942TC

22 E2042TC

23 E2242TC

24 E2442TC

25 PresetModes(Resolution)

26 Indicator

27 PROPERPOSTURE

27 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

StandBody StandBase

CD(Owner'sManual)/

Card D-SUBCable DVI-DCable

(Thiscableisnotincluded

inallcountries.)

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.9)

Button(Seep.11)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

AttachtheStandBodytothemonitorset.

AttachtheStandBase.

Tightenthescrewtotherightwithacoin.

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

2

StandBase

StandBody

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

DetachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

2

StandBase

StandBody

PullouttheStandBodyandStandBase

fromthemonitorset.

Turnthescrewtotheleftwithacoin.

PullouttheStandBase.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

2 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

3 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder

or

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

Donotholdthissetlikebelowpicture.Monitor

screencandetachfromstandbaseandinjure

yourbody.

WARNING

Tiltfrom+20to-5degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonawall

Forproperventilation,allowaclearanceof10cm

oneachsideandfromthewall.Detailed

instructionsareavailablefromyourdealer,seethe

optionalTiltWallMountingBracketInstallationand

SetupGuide.

IfyouintendtomounttheMonitorsettoawall,

attachWallmountinginterface(optionalparts)to

thebackoftheset.

WhenyouinstalltheMonitorsetusingawall

mountinginterface(optionalparts),attachit

carefullysoitwillnotdrop.

1Please,Usethescrewandwallmountinterface

inaccordancewithVESAStandards.

2Ifyouusescrewlongerthanstandard,the

monitormightbedamagedinternally.

3Ifyouuseimproperscrew,theproductmightbe

damagedanddropfrommountedposition.In

thiscase,LGElectronicsisnotresponsiblefor

it.

4VESAcompatible.

5PleaseuseVESAstandardasbelow.

 784.8mm(30.9inch)andunder

*WallMountPadThickness:2.6mm

*Screw:Φ4.0mmxPitch0.7mmx

Length10mm

 787.4mm(31.0inch)andabove

*PleaseuseVESAstandardwallmountpad

andscrews.

10 cm

10 cm  Disconnectthepowercordfirst,andthen

moveorinstalltheMonitorset.Otherwise

electricshockmayoccur.

 IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.

 UseonlyanauthorizedLGwallmount

andcontactthelocaldealerorqualified

personnel.

 Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoid

yourwarranty.

 Useonlyscrewsandwallmountsthat

meettheVESAstandard.Anydamages

orinjuriesbymisuseorusinganimproper

accessoryarenotcoveredbythewarranty.

 UsethescrewsthatarelistedontheVESA

standardscrewspecifications.

 Thewallmountkitwillincludeaninstallation

manualandnecessaryparts.

 Thewallmountbracketisoptional.Youcan

obtainadditionalaccessoriesfromyourlocal

dealer.

 Thelengthofscrewsmaydifferdepending

onthewallmount.Besuretousetheproper

length.

 Formoreinformation,refertothe

instructionssuppliedwiththewallmount.

CAUTION

NOTE

Model E1942TC

E2042TC

E2242TC 

E2442TC 

VESA(AxB) 75x75 100x100

Standard

screw M4

Numberof

screws 4

ENG

ENGLISH

USING THE MONITOR SET

USINGTHEMONITORSET

ConnectingtoaPC

 YourMonitorsetsupportsPlug&Play*.

*Plug&Play:APCrecognizesaconnected

devicethatusersconnecttoaPCandturn

on,withoutdeviceconfigurationoruser

intervention.

D-SUBconnection

TransmitsanalogvideofromyourPCtothe

Monitorset.ConnectthePCandtheMonitorset

withthesuppliedD-sub15pinsignalcableas

showninthefollowingillustrations.

 Macadapter

ForAppleMacintoshuse,aseparateplug

adapterisneededtochangethe15pin

highdensity(3row)D-SUBVGAconnector

onthesuppliedcabletoa15pin2row

connector.

 WhenusingaD-Subsignalinputcable

connectorforMacintosh

NOTE

DVI-Dconnection

TransmitsadigitalvideosignalfromyourPCto

theMonitorset.ConnectthePCandtheMonitor

setwithaDVIcableasshowninthefollowing

illustrations.

ENG

ENGLISH

USING THE MONITOR SET

 WhenyouwanttousetwoPCinourMonitor,

pleaseconnectthesignalcable(D-SUB/

DVI-D)respectivelyinMonitorset.

 IfyouturntheMonitorsetonwhileitiscold,

thescreenmayflicker.Thisisnormal.

 Somered,green,orbluespotsmayappear

onthescreen.Thisisnormal.

 "SelfImageSetting"Function.

Thisfunctionprovidestheuserwithoptimal

displaysettings.Whentheuserconnects

themonitorforthefirsttime,thisfunction

automaticallyadjuststhedisplaytooptimal

settingsforindividualinputsignals.(Only

supportedinAnalogMode)

 ‘AUTO’Function.

Whenyouencounterproblemssuchas

blurryscreen,blurredletters,screenflicker

ortiltedscreenwhileusingthedeviceor

afterchangingscreenresolution,pressthe

AUTOfunctionbuttontoimproveresolution.

(OnlysupportedinAnalogMode)

NOTE NOTE

 Connectthesignal

inputcableandtighten

itbyturningthescrews

clockwise.

 Donotpressthescreenwithyourfingerfor

alongtimeasthismayresultintemporary

distortiononthescreen.

 Avoiddisplayingafixedimageonthe

screenforalongperiodoftimetoprevent

imageburn.Useascreensaverifpossible.

CAUTION SelfImageSettingFunction

Pressthepowerbuttononthebottompanelto

turnthepoweron.Whenmonitorpoweristurned

on,the"SelfImageSetting"Functionisexecuted

automatically.(OnlysupportedinAnalogMode)
