Lenoxx CD-105 User manual

IB-CD105(SY)-DG-E-041602

COMPACT DISC PLAYER

AM/FM STEREO CASSETTE RECORDER

MODEL CD-105

OPERATING INSTRUCTIONS

PLEASE READ CAREFULLY BEFORE USE

PLAYS MUSIC COMPACT DISCS

FULLY PROGRAMMABLE CD PLAYER WITH REPEAT

RECEIVES AM/FM STEREO BROADCASTS

RECORDS FROM CD, RADIO, OR BUILT-IN MICROPHONE

FM STEREO INDICATOR

2 WAY POWER - AC/DC

REQUIRES 8 SIZE C BATTERIES (not included)

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM1

IB-CD105(SY)-DG-E-041602

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN EXTENSION

CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY

INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings, install in accordance with the manufacturers

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A grounding type plug has two blades and a

third grounding prong. The wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Unplug this apparatus during lightening storms or when unused for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally or has been dropped.

14. This appliance shall not be exposed to dripping or splashing water and that no object filled

with liquid such as vases shall be placed on the apparatus.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

The lightning flash with

arrowhead symbol, within an

equilateral triangle, is

intended to alert the user to

the presence of uninsulated

dangerous voltage within

the products enclosure that

may be of sufficient

magnitude to constitute a risk

of electric shock to persons.

WARNING: TO REDUCE THE

RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER

(OR BACK). NO USER

SERVICEABLE PARTS

INSIDE. REFER SERVICING

TO QUALIFIED SERVICE

PERSONNEL.

The exclamation point within

an equilateral triangle is

intended to alert the user to the

presence of important

operating and maintenance

(servicing) instructions in the

literature accompanying the

appliance.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM2

IB-CD105(SY)-DG-E-041602

ADDITIONAL SAFETY INSTRUCTIONS

1. Power Sources - The appliance should be connected to a power supply only of the type

described in the operating instructions or as marked on the appliance.

2. Wall or Ceiling Mounting - The appliance should not be mounted to a wall or ceiling.

3. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are

not spilled into the enclosure through openings.

4. Servicing - The user should not attempt to service the appliance beyond that described in

the operating instructions. All other servicing should be referred to qualified service

personnel.

CAUTION

Use of controls or adjustments or performance of procedures other than those

specified herein may result in hazardous radiation exposure.

This compact disc player is classified as CLASS 1 LASER PRODUCT as stated

on the back of the set.

Do not apply oil or petroleum products or solvents to any part of this set.

It is the intent of Lenoxx that this product be used in full compliance with the

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM3

IB-CD105(SY)-DG-E-041602

1. Use only the type and size of batteries mentioned in the operating instructions

booklet (batteries are not included with this set, please buy the proper batteries).

2. Do not dispose the batteries into a fire. The cells may explode. Check with local

codes for possible special disposal instructions.

3. Do not open or mutilate the batteries. Released electrolyte is corrosive and may

cause damage to the eyes or skin. It may be toxic if swallowed.

4. Be careful when handling batteries in order not to short the battery with conducting

materials such as rings, bracelets and keys. The battery or conductor may over

heat and cause burns.

5. Do not attempt to recharge non-rechargeable batteries. The batteries may leak

corrosive electrolyte or explode.

6. Do not attempt to rejuvenate the batteries identified for use with this product by

heating them. Sudden release of the battery electrolyte may cause burns or

irritation to eyes or skin.

7. All batteries should be replaced at the same time. Mixing fresh and discharged

batteries could increase internal cell pressure and rupture the batteries.

8. When inserting batteries into this product, the proper polarity ( and ) or

direction must be observed. Reverse insertion of some or all of the batteries may

result in battery electrolyte leakage or explosion.

9. Remove the batteries from this product if the product will not be used for a long

period of time (several months or more) since during the period the batteries could

leak, damaging the product.

10. Discard weak or dead batteries as soon as possible since they are more likely to

leak in the product. Batteries should be replaced (depending on the product) when

the display gets dim or if the Low Battery Indicator shows or if the sound gets

distorted.

11. Do not store this product in high temperature areas. Batteries that are stored in a

freezer or refrigerator for the purpose of extending shelf life should be protected

from condensation during storage and defrosting. Batteries should be stabilized at

room temperature prior to use after cold storage.

12. If this product does not operate normally, see TROUBLE SHOOTING in this

instruction manual. If you cant resolve the problem, or if the product is damaged, refer to the

LENOXX WARRANTY INFORMATION. Opening or removing covers may expose you to

dangerous voltages or other risks. Incorrect reassembly can cause electric shock when

the appliance is subsequently used.

13. If liquid leaks from the batteries, carefully wipe this liquid. Do not allow it to touch your skin,

and discard the leaking batteries.

14. Do not mix batteries (OLD and NEW or CARBON and ALKALINE, etc.).

15. The use of rechargeable batteries is not recommended for this set because their

voltage and life is lower than standard batteries.

16. Installation of batteries should be done by an adult only.

SAVE THESE INSTRUCTIONS

CAUTION: TO REDUCE THE RISK OF FIRE OR PERSONAL INJURY OR DAMAGE TO YOUR

SET, READ AND FOLLOW THESE INSTRUCTIONS.

BATTERY SAFETY INSTRUCTIONS

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM4

IB-CD105(SY)-DG-E-041602

CHOOSING THE POWER SOURCES

You can use the AC power or batteries as a power source.

TIP

If the plug of the AC power

cord does not match your

outlet, do not force it.

Reverse it and try again.

The plugs are polarized

and only fit one way into

the wall outlet and back of

the set.

TIP

Replace the batteries

when the display dims or

when the player stops

operating. Replace all the

batteries with new ones.

Before you replace the

batteries, be sure to take

out the CD from the player

and remember to check the

Battery Safety Instructions

on Page 3.

1. Connecting the AC power

cord

Insert one end of the supplied AC power cord

(located in the battery compartment) into the socket

located at the rear of the player, and the other end

to the wall outlet.

2. Using the player on batteries

Insert 8 size C batteries (not supplied) into the

battery compartment.

To use the player on batteries, disconnect the AC

power cord from the player.

AC SOCKET

Battery compartment

To a wall outlet

NOTE: One blade of plug

and outlet is wider.

IB-CD105(SY)-DG-E-041602.p65 4/29/02, 3:16 PM5

IB-CD105(SY)-DG-E-041602

1Slide the FUNCTION

switch to CD position, the

display will show two

dashes --, then  .

3Close the CD DOOR by

pushing it down. The

display will show the total

tracks on that CD.

Press the CD DOOR

OPEN button to open it

and place the CD in the

CD compartment. The

label side of the CD should

face upward.

Press the CD PLAY

button. The PLAY/

PAUSE lamp will be

steady on, the player

plays all the tracks once.

Connect the supplied AC power cord or batteries (see page 4).

Track

number

PLAY/PAUSE

lamp

PLAYING A CD

FUNCTION

5To change the sound

effect, adjust the TONE

knob to your taste.

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM6

IB-CD105(SY)-DG-E-041602

USE THESE BUTTONS FOR

ADDITIONAL OPERATIONS

To Press or Adjust

Adjust the volume VOLUME control

Stop playback

Pause playback The PLAY/PAUSE lamp will

flash during pause. Press

again to resume play after

pause.

Go to the next track

Go back to the previous

track

Locate a point in a song

Press and hold down while

playing until you find the

point.

TIP

When CD play is

paused, the PLAY/

PAUSE lamp will

flash and no music

will play.

Remove the CD Press the CD DOOR OPEN

button (press STOP first)

VOLUME

CONTROL

FUNCTION SWITCH

Turn off the power Slide the FUNCTION switch to

TAPE (POWER OFF) position

To resume play,

press the PAUSE

button again, the

PLAY/PAUSE lamp

will stop flashing

and music will play.

CD DOOR OPEN BUTTON

If you bump the set

during CD play, the

music will stop or

skip for a few

seconds. This is

normal for this type

of player.

TIP FORWARDS

BACKWARDS

STOP

PLAY/PAUSE

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM7

IB-CD105(SY)-DG-E-041602

LISTENING TO THE RADIO

Connect the supplied AC power cord or batteries (see page 4).

Slide the FUNCTION switch to

RADIO position.

Slide the BAND switch to the

proper band position (AM, FM, or

FM STEREO) that you want.

Tune into the station you prefer

using the TUNING control (at the

back of the set). Adjust for the

clearest sound.

4This FM STEREO indicator will light

up when receiving FM Stereo

broadcasts.

5To change the sound effect,

adjust the TONE knob to your

taste.

IB-CD105(SY)-DG-E-041602.p65 4/29/02, 3:16 PM8

IB-CD105(SY)-DG-E-041602

USE THESE BUTTONS FOR

ADDITIONAL OPERATIONS

To Slide or Adjust

Adjust the volume VOLUME control

TIP

•If the FM broadcast is

noisy, slide the BAND

switch from FM Stereo

to FM position (MONO). Turn off the Radio Slide the FUNCTION

switch to TAPE (POWER

OFF) position

To improve broadcast reception

Change position of the antenna for FM or FM Stereo.

Move the set itself for AM.

•Next time you want to

listen to the radio, just

slide the FUNCTION

switch to RADIO. The

player automatically

starts playing the

previously tuned

station.

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM9

IB-CD105(SY)-DG-E-041602

PLAYING A TAPE

Connect the supplied AC power cord or batteries (see page 4).

Press the STOP button

to open the tape

compartment and insert

a recorded tape. Close

the door.

3Press the PLAY button.

The player turns on and

starts playing.

PLAY

Slide the FUNCTION

switch to TAPE position.

4When the set finishes

playing this side of the

tape, the set will stop. To

hear the other side of the

tape, flip the tape over,

then insert and press

PLAY.

AUTO STOP

INSERT TAPE THIS WAY

FULL REEL ON RIGHT

STOP

FULL

REEL

EMPTY

REEL

TAPE PLAY DIRECTION

OK NO

IB-CD105(SY)-DG-E-041602.p65 4/26/02, 4:04 PM10

Other Lenoxx Portable Stereo System manuals

Lenoxx

Lenoxx CDB830 User manual

Popular Portable Stereo System manuals by other brands

Panasonic

Panasonic RXDS520 - RADIO CASSETTE W/CD operating instructions

LG SB159ST owner's manual

Philips

Philips AZ305 user manual

Manta

Manta BBX002 user manual

Sony

Sony ZS-BTG900 operating instructions

Memcorp

Memcorp Disney DB3000-P user guide

Sharp

Sharp GF-800HS Service manual

Philips

Philips AZ 2760 user manual

Hyundai

Hyundai H-1443 instruction manual

Grundig

Grundig RR 300 CD Service manual

Insignia

Insignia NS-BCDCAS1 user guide

Philips

Philips AZ380W user manual

Sony

Sony ZS-S10CP instruction & operation manual

AudioSonic

AudioSonic 42373117 user manual

Akai

Akai A60009 instruction manual

Sony

Sony HCD-E301 Service manual

Memorex

Memorex MW5554 user guide

Panasonic

Panasonic RXDS16 - RADIO CASSETTE W/CD operating instructions
