Lenovo ThinlPad T14s Gen 1 User manual

T14s Gen 1 / X13 Gen 1

Setup Guide

Printed in China

PN: SP40T79953

Initial Setup

*Lenovo USB-C to

DisplayPort Adapter

*Lenovo USB-C to

VGA Adapter

*Lenovo HDMI to VGA

Adapter

*ThinkPad Ethernet

Extension Adapter

Gen 2

*For selected models

Overview

ThinkPad T14s Gen 1

HDMI

4 45 34 1 432

ThinkPad X13 Gen 1

HDMIHDMI

4 45 34 1 432

*For selected models

*1. Infrared (IR) LED

*2. Camera with IR function

*3. ThinkShutter

*4. Microphones

*5. Camera

*6. Multi-touch screen

7. Power button

8. Security-lock slot

9. Always On USB 3.2 connector Gen 1

10. TrackPoint® pointing stick

*11. Fingerprint reader

*12. Smart-card slot

*13. NFC label

*14. Nano-SIM-card and microSD-

card slot

15.TrackPad

*16. NFC mark

17. TrackPoint buttons

18. Audio connector

19. HDMITM connector

20.USB 3.2 connector Gen 1

21.Docking-station connector

22. Ethernet extension connector

Gen 2

23. ThunderboltTM 3 connector

(USB-C)

24. USB-CTM connector (USB 3.2 Gen 1)

Read the statement on USB transfer rate in the User Guide. Refer to the Safety and

Warranty Guide for accessing the User Guide.

Customer Replaceable Units (CRUs)

•ac power adapter

•Power cord

•Base cover assembly

*•M.2 solid-state drive

*•M.2 solid-state drive bracket

*•Wireless WAN card

*•Nano-SIM-card and microSD-card

tray

•Keyboard (for X13 Gen 1)

Refer to the User Guide for CRU definition.

*For selected models

Additional information

European Union — compliance with the

Radio Equipment Directive

Hereby, Lenovo (Singapore) Pte. Ltd., declares that

the radio equipment type ThinkPad T14s Gen 1 /

ThinkPad X13 Gen 1 is in compliance with Directive

2014/53/EU.

The full text of the system EU declaration of

conformity is available at the following Internet

address:

https://www.lenovo.com/us/en/compliance/eu-

doc

This radio equipment operates with the following

frequency bands and maximum radio-frequency

power:

Technology

Frequency

band [MHz]

Maximum

transmit power

WLAN

802.11b/g/n/ax

2400 - 2483.5 < 20 dBm

WLAN

802.11a/n/ac/ax

5150 - 5725 < 23 dBm

WLAN

802.11a/n/ac/ax

5725 - 5875 < 13.98 dBm

Bluetooth

BR/EDR/LE

2400 - 2483.5 < 20 dBm

WWAN

UMTS

1, 8 < 24.5 dBm

WWAN

LTE

1, 3, 7, 8, 20, 28 < 24 dBm

WWAN LTE

38/40/42

< 24 dBm

NFC 13.56

< -5.31 dBμA/m

@10m

E-manual

First Edition (April 2020)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a

General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to

restrictions set forth in Contract No. GS-35F-05925.

Reduce I Reuse I Recycle
