LEISUREWIZE LW680 Specification sheet
Technical Support & Spare Parts
If you require any technical support & spare parts, please contact us on support@
streetwizeaccessories.com and provide the product name and supplier code (see Technical
Specifications) along with the technical query and proof of purchase.
Technical Specifications
Product name
Supplier code
Frame material
Fabric material
Max load capacity
Leisurewize All-Terrain Heavy Duty Outdoor Trolley
LW680
Steel
600D polyester with PE coating
80kg
Streetwize, Ashburton Road West,
Trafford Park, Manchester, M17 1RY
www.streetwizeaccessories.com
EU Regd. Address: Ace Supply Co (Europe) Ltd. D02 A098, ROI
For Product Support:
E: suppor[email protected]
T: +44 (0)161 447 8597
For Trade Enquiries:
T: +44 (0)161 447 8580
Information for use
LW680
All Terrain Heavy Duty
Outdoor Trolley
Intention For Use
Product Elements
Assembly
Thank you for purchasing this outdoor trolley from Leisurewize. This product has a range of
uses. Its durable steel frame allows it to carry a maximum load of 80kg and it comes with
wide wheels for navigating in a bumpy terrain.
It is ideal for transporting items (including luggage) in caravan parks, motorhome parks and
camping sites and beaches. This outdoor trolley is also suitable for gardeners for carrying
plants, garden waste and gardening equipment.
1. Folding trolley frame
2. Trolley fabric
3. 4 x bolts
4. Base mat
5. Storage bag for fabric
To assemble the trolley, please follow the instructions below:
1. Carefully remove the trolley and the fabric out of the packaging.
2. The trolley frame will come folded. To unfold, stand the folded trolley upright and
ensure the wheels are correctly positioned (see Figure 1).
3. Then pull apart the trolley as far as you can (see Figure 2). Then press the joint
component of the frame base (Figure 3) to secure the frame in place.
4. Then place the trolley fabric onto the frame, making sure the top corners of the frame
align with the pre-drilled holes and side pockets of the fabric fit on the frame (see
Figure 4). Then place the base mat inside the trolley. Figure 5 shows fabric and mat in
place.
5. Secure the hook & loop straps on edge of the trolly (see Figure 6)
6. Using the supplied four bolts, secure the fabric in place via the corners (Figure 7 & 8).
7. To extend the handle, press on both sides of the latch and pull the handle once it locks
into place.
Fig. 4
Fig. 7
Fig. 1
Fig. 5
Fig. 2
Fig. 6
Fig. 3
Folding the Trolley for Storage
Cleaning & Maintenance
Health & Safety Guidelines
To fold the trolley, first remove the fabric and then reverse
the steps to fold the trolley. Then fold the fabric and base
mat into the carry bag.
Use a clean and damp cloth to wipe clean both the fabric
and frame.
• This product is not a toy. Please keep children supervised at all times when using the
product.
• Avoid getting fingers trapped in the frame when unfolding the product.
• Keep the fabric away from naked flames
