LEAD FLUID YZ Series User manual
OPERATING MANUAL
YZ，YT Series Easy-Load Pump Head
保定雷弗流体科技有限公司
BAODING LEAD FLUID TECHNOLOGY CO.,LTD.
YZ，YT Series Easy-Load Pump Head
1
TEL
：
0312-3250677 3250877 3250977 FAX
：
0312-3250877-804
Safety Caution
Important Information
Be sure to read the instructions carefully before operation.
Dangerous
Turn driver off before removing or installing tubing, don't get close to the
rotation of wheel parts prevent fingers and clothing were involved in
machinery agency!
Warning
About the chemistry compatibility problems of the tubing & pump head
material and transmission liquid, if choose undeserved, can cause
abnormal damage. Therefore before use the pump head and tubing,
please consult our engineers.
The tubing is belong to consumables, please pay attention to check. The
pump head is damaged caused by tubing broken, especially including the
poisonous and harmful and precious liquids leak, our company is not
responsible for that!
Warning: This product is cannot be used in medical care
Warning
Please choose the suitable tube for the pump head, with reference to "pump
head suitable for tubes and tubing flow rate.
The operation manual provides tubing flow rate, distribution volume and
other technical parameter is under atmospheric pressure with water as a
medium of the test data, test line length are 0.5 meters of import and
export and import and export at the same level. When liquid, viscosity,
BAODING LEAD FLUID TECHNOLOGY CO.,LTD.
Mail
：
leifu@leadfluid.net WEB
：
www.leadfluid.net
2
tubing length, import and export pressure using conditions change, please
consult our engineers.
If long time no use the peristaltic pump, please lift the briquetting of pump
head, release the tubing, to prevent the tube inner surface adhesion.
For extending the service life of the tubing, can move the tubing on a
regular basis, 200-300 - mm, will be alternating roller extrusion tubing
continue to use after partial replacement of the new location.
if the tubing burst in using, please timely clean up the spilled liquid, before
the use should check again whether the head roller pump running flexible,
if it is found that roller operation is not flexible, please relate our company.
If forced to use will fuel tubing wear and damage the pump head.
At the top knob of the pump head YT15, YT25, YZ35 t can adjust the
pressure, such as can't conveying liquid or the output pressure is not
enough, can be appropriately clockwise to normal output liquid.
YZ，YT Series Easy-Load Pump Head
3
TEL
：
0312-3250677 3250877 3250977 FAX
：
0312-3250877-804
Catalogue
Brief Introductions ..................................................................................4
Part name and function..........................................................................5
Method of application.............................................................................5
Install YZ15/YZ25/YT15/YT25 pump head ............................................5
Install YZ35 pump head .........................................................................6
Loading tubing for YZ15/YZ25/YT15/YT25 pump head.........................8
Loading tubing for YZ35 pump head......................................................9
Unloading tubing ..................................................................................11
Using the matters needing attention ....................................................11
Fault and maintenance.........................................................................12
The warranty and after-sales ...............................................................12
Daily maintenance................................................................................12
Fault handling.......................................................................................13
Pump head suitable tubes and tube flow rate......................................14
Apperance dimensions.........................................................................16
Technical parameters...........................................................................18
BAODING LEAD FLUID TECHNOLOGY CO.,LTD.
Mail
：
leifu@leadfluid.net WEB
：
www.leadfluid.net
4
Brief Introductions
● YZ, YT series pump heads are suitable for a variety of specifications tubes.
Simple and easy to replace the tubing, compact structure and reasonable,
which can realize multiple pump heas. PPS material of pump shell is resistance
to organic solvents and other corrosive liquids, strong and durable. The ways
between pressure tube have fixed and adjustable, flexible choice.
Suitable for tubes
●YZ15：wall thickness 1.6mm
●YZ25: wall thickness 2.4mm
●YT15：wall thickness1.6mm
●YT25：wall thickness 2.4mm
●YZ35：wall thickness 3.3mm
1
YZ，YT Series Easy-Load Pump Head
5
TEL
：
0312-3250677 3250877 3250977 FAX
：
0312-3250877-804
Part name and function
1. Flat shaft end: used to connect the drive coupling and cascade the pump
heads.
2. Pull rod: when install tubing need to use it .
3. Sliding block: after press it, squeeze the tubing together with the roller
device.
4. Tubing clamp: after the sliding block down, the tubing gets stuck, make the
tubing can't move.
5. Mounting hole: with the screw, the pump head is fixed on the drive.
6. Coupling : Using to cascade pump heads.
7. Upper Slide Block: Pulling the pull rod to drive the slider move up and down,
convenient to replace the tubing.
8. Adjust press knob (YZ35、YT15、YT25) fine-tuning between pressure tube.
Method of application
Install YZ15 / YZ25 / YT15 / YT25 pump head
●Put one side of the pump head flat shaft towards to drive, push on the
groove of coupling in front of drive. Make the pump head in suitable
position through the two position column of pump head support, put the
pump head cling to the drive.
●Insert the 2 pieces of pump head nails to mounting holes, tighten pump
head nails.
YZ，YT Series Easy-Load Pump Head
7
TEL
：
0312-3250677 3250877 3250977 FAX
：
0312-3250877-804
●Put one side of the pump head flat shaft towards to drive, push on the groove
of coupling in front of drive. Make the pump head in suitable position, put the
pump head cling to the drive.
●Insert the 2 pieces of screws and 3 pieces of pump head nails to mounting
holes, tighten pump head nails.
YZ35 pump head assembly drawing
Point out
In tightening the screws and fixed pump head nail shall ensure that the degree
of the same, and not too tight.
BAODING LEAD FLUID TECHNOLOGY CO.,LTD.
Mail
：
leifu@leadfluid.net WEB
：
www.leadfluid.net
8
Loading tubing for YZ15/YZ25/YT15/YT25 pump head
1. Be sure the pump drive is turn off.
2. Pull the pull rod to the horizontal position, left the sliding block.
Loading the suitable tube.
●YT15, YT25 pump heads only in the first installation tube need to a fine tuning
knob adjustment. First put the pressure tube clearance knob to the loose state
by counterclockwise.YZ15, YZ25 pump heads pressure tube clearance is
cannot adjust.
●Throw up on one side of the tubing clamp, put tubing in, then pull another side
tubing clamp, put the tubing into the other side.
●Tension with both hands on both ends of the tube, make it natural stretch, no
distortion, no deviation.
YZ，YT Series Easy-Load Pump Head
9
TEL
：
0312-3250677 3250877 3250977 FAX
：
0312-3250877-804
●Pull the pull rod to the horizontal position on the right side, to the sliding block
down in place.
●YT15 / YT25 pump head tuning knob adjustment methods: adjust the pump
speed within1-5rpm, slowly adjust the fine tuning knob clockwise to a
continuous conveying liquid, when stop the pump without reflow. If you want
to transfer the fluid with the high pressure, need to fine-tune knob clockwise
again.
Loading tubing for YZ35 pump head
1. Be sure the pump drive is turn off.
2. Pull the pull rod to the horizontal position, left the sliding block.
3. Loading the suitable tube.
Each time install the tube for the YZ35 pump heed needs to adjust the pressure
tube clearance, First put the pressure tube clearance knob to the loose state by
counterclockwise
Press on one side of the spring tubing clamp, put tubing in, then press another
side spring tubing clamp, put the tubing into the other side.
