LawnMaster NPTBSP2609A User manual
Instruction Manual / Manuel d'instructions
26cc NO PULL Brush Cutter NPTBSP2609A
Débroussailleuse 26cc NPTBSP2609A-02
Read all safety instructions carefully before assembling and operating
this machine. Ensure the machine has been assembled correctly and safely. Keep the
instructions safe and pass them on to any subsequent user so that the information is always
available.
Original Instructions / Manuel d'instructions original
WARNING:
lire attentivement toutes les instructions de sécurité avant d'assembler et
d'utiliser cette machine. S’assurer que la machine a été assemblée correctement et en toute
sécurité. Conserver les instructions en lieu sûr et les transmettre à tout utilisateur .
AVERTISSEMENT:
32 33
37 38 39 40 41
34 35
36
31
2
3
4
5
6
7
8
9
10
11
12
13
14
25
26
27
28
29
30
15
18
19
20
21
22
23
24
1
16
17
Oil
1:40
100
600
Gas
586.36
500
400
300
200
4
63
Fig.6 Fig.7
Fig.12 Fig.13 Fig.15
Fig.19
Fig.16
Fig.8 Fig.9 Fig.10
Fig.14
Fig.5
Fig.11
Fig.2
Ⅰ
Ⅱ
Fig.3 Fig.4Fig.1
Fig.17
Fig.20 Fig.22Fig.21
2
1
5
7
7
6
Ⅱ
Ⅰ
Ⅱ
Ⅰ
Fig.18
4
4
TABLE OF CONTENTS
Section Page
Symbols
Safety Information
In the Box
Assembly
Operation
Maintenance
Troubleshooting
Technical Data
Recycling and Disposal
Warranty
5-7
8-21
22
23-25
26-33
34-39
40-41
42-43
43
44
5
SYMBOLS
SYMBOL DESIGNATION/EXPLANATION
Caution
Read the instruction manual and follow all warnings and safety instructions.
The product complies with the applicable European directives and an evaluation
method of conformity for these directives was followed.
Wear ear protection, safety helmet and eye protection.
Wear respiratory protection.
Wear face protection.
Wear gloves with saw protection.
Wear safety footwear.
Wear protective clothing.
Wear non-slip safety footwear when using this product.
To avoid potential electric shock, do not use the unit in humid or wet conditions.
Beware of blade thrust: Continued movement of blade after cutting through log.
Keep all bystanders at least 15 m away.
Thrown objects can ricochet and result in personal injury or property damage.
Risk of re / ammable materials.
Hot surface, do not touch. The high temperatures on the product's surfaces and
structural parts could cause burns if touched. The product can also remain hot
for a long period of time after operation!
This product produces noxious exhaust fumes. If the product is not used properly,
these fumes can lead to poisoning, a loss of consciousness or death!
The following warning symbols appear on the product and throughout this manual
and indicate the appropriate safety measures you should take when operating and
maintaining the appliance.
6
SYMBOLS
SYMBOL DESIGNATION/EXPLANATION
2 stroke engine. Only use petrol/oil mixture with a ratio of 40:1. Do not use any
other mixture ratio. Always use a high quality 2 stroke engine oil. Always switch
the product off and let it cool down, before refueling it.
Naked ames in the work area, around the product and in the vicinity of
ammable materials are prohibited!
Do not smoke in the work area, around the product and in the vicinity of
ammable materials!
Maximum rotational frequency of the spindle, in min-1.
Cutting width of grass trimmer.
Cutting width of brush cutter.
Inspect the area where the product is to be used and remove all objects which
can be thrown by the product. If objects are hidden while operating stop the
engine and remove the object.
Do not touch the cutting device until it stops completely.
Noise level specication LWA in dB(A).
Do not use saw blades.
Use unleaded petrol intended for motor vehicle use with an octane rating of 87 [(R
+ M) / 2] or higher. This product is powered by a 2-cycle engine and requires pre-
mixing petrol and 2-cycle lubricant.
Choke control “CHOKE” position (choke closed) for cold start.
Choke Control “RUN” Position (Choke Open).
Do not dispose of battery packs in rivers or immerse in water.
Max
-1
430mm
230mm
7
SYMBOLS
To avoid serious personal injury, do not attempt to use this product until you read thoroughly and
understand completely the instruction manual.
If you do not understand the warnings and instructions in the instruction manual, do not use this
product.
WARNING
SYMBOL DESIGNATION/EXPLANATION
Do not dispose of battery packs in re.
Do not subject the battery to direct sunlight over long periods and do not leave it
on or near a heat source (max. 60°C).
Recycle electrical waste products in an environmentally safe way where facilities
exist.
Push to start.
NPTBSP2609A
26cc straight split shaft brush cutter.
8
SAFETY INFORMATION
Read these instructions carefully before operating this tool.
Make sure that you are familiar with the controls and know
how to properly operate the machine. By following these
instructions, you can reduce the risk of re, electric shock
and personal injury.
READ CAREFULLY BEFORE USE. KEEP FOR FUTURE
REFERENCE.
WARNING
WARNING
■ Read the instructions carefully. Be familiar with the controls
and the proper use of the machine.
■ Never allow people unfamiliar with these instructions or
children to use the machine. Local regulations may restrict
the age of the operator.
■ The operator or user is responsible for accidents or hazards
occurring to other people or their property.
■ This product is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the product by a person responsible for their safety.
■ Children should be supervised to ensure that they do not
play with the product.
■ Never operate the product while people, especially children,
or pets are nearby (maintain a safe distance of 15m).
■ Do not expose the machine to rain.
9
SAFETY INFORMATION
Preparation
■ This product can cause serious injuries. Read the
instructions carefully for the correct handling, preparation,
maintenance, starting and stopping of the product. Become
familiar with all controls and the proper use of the product.
■ Dress properly! Do not wear loose clothing or jewellery
which can be caught in moving parts. Use of sturdy gloves,
non-skid footwear and safety glasses is recommended.
■ Always use approved ear protection while you operate the
product. Noise for a long period can cause noise-induced
hearing loss.
■ Take extra care when handling fuel. It is ammable and the
vapours are explosive.
■ The following points should be observed:
- Only use approved containers to store fuel.
- Never remove the fuel tank cap or add fuel with the power
source running. Allow engine and exhaust components to
cool down before refueling.
- Do not smoke when operating, fueling, or starting this
machine.
- Never refuel indoors or in conned spaces.
- Never store the product or fuel container inside where
there is an open ame, such as near a boiler.
- If fuel is spilled, do not attempt to start the product. Move
it away from the area of spillage before starting.
- Always replace and securely tighten the fuel tank cap
after refueling.
- Drain fuel outdoors only.
■ If the cutting mechanism strikes any foreign object or the
product starts making any unusual noise or vibration, shut
10
SAFETY INFORMATION
off the power source and allow the product to stop. Remove
the battery pack and take the following steps:
- Inspect for damage.
- Check and tighten any loose parts
- Have damaged parts repaired or replaced with original or
high quality spare parts, similar from a technical point of
view to the original parts.
Operation
■ This product should not be used for any other purpose than
described. Note that national regulations can restrict the
use of this product.
■ Working with this product is demanding; therefore, ensure
you are physically and mentally t to complete the job
safely. Do not use the product when you are tired, ill or
under the inuence of alcohol or other drugs.
■ Pay attention to your posture; always use the provided
harness and keep your back straight. Do not overwork
yourself. Take regular breaks to ensure concentrated work
and full control over the product.
■ Keep a rm footing and balance during operation. Use
the harness, and always be sure of a safe and secure
operating position, whilst using the product. Never use the
product standing on steps or a ladder.
■ Always wear substantial footwear and long trousers while
operating. Do not operate the product when barefoot or
wearing open sandals. Wear protective glasses or goggles.
■ Thoroughly inspect the area where the product is to be
used and remove all objects which can be thrown by the
product.
■ Before using the product and after any impact, check for
