Laserworld RTI-Nano Tripan User manual
Manual / Bedienungsanleitung
RTI-Nano Tripan
Please spend a few minutes to read this manual fully
before operating this laser!
Bitte lesen Sie diese Bedienungsanleitung sorgfältig
vor Inbetriebnahme dieses Showlasersystems!
rev. 01/2014
English
Deutsch
Manual: RTI Nano AT Series
page 2 / 25
Rechtlicher Hinweis:
Die Firma Laserworld AG behält sich das
Recht vor, Änderungen an ihren Produkten
vorzunehmen, die der technischen Weiter-
entwicklung dienen. Diese Änderungen wer-
den nicht notwendigerweise in jedem Einzel-
fall dokumentiert.
Diese Betriebsanleitung und die darin ent-
haltenen Informationen wurden mit der ge-
botenen Sorgfalt zusammengestellt. Die Fir-
ma Laserworld AG übernimmt jedoch keine
Gewähr für Druckfehler, andere Fehler oder
daraus entstehende Schäden.
Die in dieser Bedienungsanleitung genann-
ten Marken und Produktnamen sind Waren-
zeichen oder eingetrageneWarenzeichen der
jeweiligen Titelhalter.
Legal notice:
Thank you for purchasing this Laserworld
product. Due to continual product develop-
ments and technical improvements, Laser-
world (Switzerland) AG reserves the
right to make modications to its products.
This manual and its content have been made
with due care but Laserworld (Switzerland)
AG cannot however, take any responsibility
for any errors, omissions or any resulting
damages forthwith.
The brands and product names mentioned
in this manual are trade marks or registered
trade marks of their respective owners.
Manual: RTI Nano AT Series
page 3 / 25
Content:
1. Product and package contents
2. Preliminary warning notices
3. Steps for setup, safety instructions
4. Safety instructions for work on the device
5. Service notes
6. Warnings and other notices on the device
7. Device connections
8. Operation
9. Remote Control Pad
10. Cleaning
Final statement
Technical data sheet
Laser specications
Manual: RTI Nano AT Series
page 4 / 25
1. Product and package contents
Please check if all listed parts are included and undamaged. Included in delivery:
1 x laser projector 1 x key for (key-) switch
1 x power cable 1 x patch cable
1 x manual
1 x detachable remote pad with cable
3. Initial operations, safety instructions
1. Make sure to use correct voltage; see in-
formation on device & in this manual.
2. Make sure that the device is not connec-
ted to mains during installation.
3. Installation has to be done by technical
experienced and qualied persons ac-
cording to safety regulations of the res-
pective country.
4. Always ensure that maximum permis-
sible exposure (MPE) is not exceeded
in areas accessible to the public or
members of sta.
5. In some countries an additional ins-
pection by technical control institutes
could be necessary.
6. The power supply should be easily acces-
sible.
7. When installing the laser mount it with
a minimum distance of 15 cm from walls
and objects.
8. For safe setup e.g. on walls or ceilings
please use a safety cord. The safety cord
should be able to withstand tenfold the
weight of the device. Please follow the
accident prevention regulations of pro-
fessional associations and/or comparable
regulations for accident prevention.
9. If the device has been exposed to great
temperature changes, do not switch it
on immediately.
2. Preliminary warning notices
1. Please use this device only according to these operating instructions.
2. Do not use the device if there are any visible damages on housing, connector panels,
power supplies or power cords.
3. Never look directly into the light source of a laser projector. Danger of damage to the
eyes or even blindness in extreme circumstances!
Any warranty claims are void if the warranty label is removed or tampered
with in any way.
Manual: RTI Nano AT Series
page 5 / 25
10. Never use dimmer, RC or other electroni-
cally switched sockets. Whenever possib-
le, do not use the laser projector together
with large appliances (especially fog ma-
chines) on the same mains!
11. Ensure sucient ventilation and do not
place the device on any warm or heat ra-
diating surface. Especially the ventilati-
on openings must not be covered!
12. Ensure that device does not get over-
heated. Make sure that the device is not
exposed to spotlights (especially moving
heads). Heat of spotlights could overheat
laser in a little while and leads to a degra-
dation of performance.
4. Working on the device
1. This product has no user serviceable parts inside and should only
be maintained and serviced by a qualied engineer.
2. Take o all reecting things like rings, watches etc. before
starting to work with or at the projector.
3. Only use non-reecting tools to work on device.
4. Wear protective clothing (like goggles, gloves etc.) accor-
ding to laser power and wavelength of the laser.
5. Service notes
• Moisture and heat can reduce lifetime of
the laser system dramatically and expires
any warranty claim.
• Quick on/o switching of this device will
reduce durability of the laser diode dra-
matically.
• Avoid sharp knocks and shocks to this
device and ensure sucient protection
during transportation. Look after your La-
serworld product.
• To increase durability of your laser,
protect device against overheating:
-Always ensure sucient ventilation.
-Do not face spotlights (especially mo-
ving heads) to the device.
-Check temperature after approx. 30
minutes with each new installation.
If necessary install the projector at a
place with dierent temperature.
-the device is according IP65 water-
proof. Nevertheless please make sure,
that water can‘t get into the device,
or the power or data connections.
Please check the connections.
-Switch o device when it is not nee-
ded. Diodes are switched on and can
wear out even if there is no visible la-
ser output.
• As for troubleshooting, please check the
FAQ on our website www.laserworld.com
• Removal of the warranty label as well
as damages to the device caused by
improper handling, neglect of the sa-
fety instructions and service notes will
void the warranty.
Manual: RTI Nano AT Series
page 6 / 25
6. Warnings and other notices on the device
Laser radiation!
Laser radiation!
Avoid exposure to beam
Laser class 4
Caution of radiation if cover is
removed. Don‘t look into the beam.
7. Device connections
connection for power supply
ILDA in
detachable
remote
control pad
ILDA out* Control
Emission LED
LAN* DMX*
* optional features
ILDA through
key switch
touchscreen
Emergency stop
Emission LED
Manual: RTI Nano AT Series
page 7 / 25
8. Operation
Please note that when the ‘Emission LED’ is on, the laser is enabled and may emit laser light.
There is one LED on the remote control pad, one on the rear side and one on the front side of
the device. The LED on the device ashes if the device is connectect to the power supply. The
LED on the control pad ashes if the device is switched on.
8.1 Power supply
Please make sure that the power supply is connected to an overload and a ground fault (earth
leakage) protection. Make sure to use correct voltage; see information at the end of this ma-
nual.
8.2 ILDA control
To control your device connect it via ILDA cables to an interface/controller. The pinout and
maximum voltages for the ILDA standard Sub-D connectors can be found on the following site
8.3 External Interlock
The Remote Control Pad has a built-in emergency stop. If there is the need for an external
interlock, please disconnect the Remote Control Pad and use the ‚Control‘ connection (RJ-48
connector) to connect it with an external interlock. Pins 7 and 8 are the emergency stop.
Manual: RTI Nano AT Series
page 8 / 25
Pin Signal
1 x-axis scanner, positive signal. Dierence of 10V
2 y-axis scanner, positive signal. Dierence of 10V
3 intensity/brightness, positive signal. Dierence of 5V
4 & 17 Interlock. Linking of both enables output
5 red intensity, positive signal. Dierence of 5V
6 green intensity, positive signal. Dierence of 5V
7 blue intensity, positive signal. Dierence of 5V
9 yellow intensity, positive signal. Dierence of 5V (depending on the version)
10 cyan intensity, positive signal. Dierence of 5V (depending on the version)
OR: DMX512 IN; positive signal (Showeditor and Phoenix interfaces).
11 DMX512 OUT; positive signal (depending on the version)
13 Shutter. Dierence of 5V
14 x-axis scanner, negative signal. Dierence of 10V
15 x-axis scanner, positive signal. Dierence of 10V
16 intensity/brightness, negative signal. Dierence of 5V
18 red intensity, negative signal. Dierence of 5V
19 green intensity, negative signal. Dierence of 5V
20 blue intensity, negative signal. Dierence of 5V
22 yellow intensity, negative signal. Dierence of 5V
23 cyan intensity, negative signal. Dierence of 5V
OR: DMX512 IN; negative signal
24 DMX512 OUT; negative signal
25 Ground
After connecting select„LASER ON - ILDA IN“ on the Remote Control Pad.
DB-25 ILDA connector
Manual: RTI Nano AT Series
page 9 / 25
9. Remote Control Pad
Your device is equipped with a detachable remote control pad. The following images explain
the use of the pad. Touch the screen to change the settings.
Starting sequence
Emergency Stop
button:
Press button to inter-
rupt laser output
Emission Laser on button:
The device is enabled if the
diode is lit.
Touchscreen
Key switch with key:
Insert key and turn it to
‚on‘ to start the device.
Laser on / o:
Device is enabled /
disabled
Version and tempera-
ture display
Laser status, amperage
& interlock status
display
Laser on / internal:
The internal access
to an e.g. SD-card is
enabled
Laser on / ILDA in:
The external access
through ILDA is ena-
bled
Color & Scan Setup:
Use these buttons for co-
lor or scan settings
DMX, Adv. and Setup:
Use these buttons for the
color or scan settings.
Adv. Setup only for factory
defaults!
Back:
Use this button to return
back.
Status display
Main Menu
Manual: RTI Nano AT Series
page 10 / 25
9.2 Color Settings:
9.3 Scanner Settings:
9.2 Color Settings:
9.3 Scanner Settings:
+ / -:
Use these buttons to
change the color inten-
sity
Colors:
Please note that
only implemented laser
sources can be changed in
their itensity. If there is e.g.
no yellow laser source in-
stalled in your device you
can‘t change the itensity
of the yellow color.
The intensity change
only applies per single
laser source and does
not change mixed colors.
Please use your software
to change mixed color in-
tensities.
X Size horizontal:
Use these buttons to
change the horizontal
size of the output
Y Size vertical:
Use these buttons to
change the vertical size of
the output
Y Shift up/down:
Use these buttons to
change the vertical shift
of the output
X Shift left/right:
Use these buttons to
change the horizontal
shift of the output
Table of contents
Languages:
Other Laserworld Projector manuals
Laserworld
Laserworld MK3 Series User manual
Laserworld
Laserworld CS-1500 RGB User manual
Laserworld
Laserworld RTI FEMTO Series User manual
Laserworld
Laserworld RTI Nano Series User manual
Laserworld
Laserworld Ecoline Series User manual
Laserworld
Laserworld Ecoline Series User manual
Laserworld
Laserworld ES-100G User manual
Laserworld
Laserworld EL-200S DMX User manual
Laserworld
Laserworld RTI-Piko Series User manual
Laserworld
Laserworld EL 200 LED User manual
