Lab.gruppen C Series C 16 4 User manual

Voltage Peak Limiter Load vs Power Tables

C Series C 68:4, C 48:4, C 28:4, C 16:4: Dedicated Installation Ampliﬁers

C Series ampliﬁers include the user-deﬁnable Voltage Peak Limiter (VPL) function. Rear-panel DIP-switch settings allow the output voltage

to be adjusted and consequently the output power available. The following tables provide information, for the listed C Series models, about

resultant output power at typical loads (single-channel and bridged operation) with the available VPL settings.

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 141 100 650 1200 1700 1200 1600

118 V 118 84 440 880 1700 1200

100 V 100 70 315 630 1250 1200 1600

85 V 85 60 220 440 890 1200

71 V 71 50 155 310 630 1200 1200

59 V 59 42 110 220 440 890

50 V 50 35 80 160 310 630

42 V 42 30 55 110 220 440

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 282 200 2400 3400 2400 3200

118 V 236 168 1760 3400 2400

100 V 200 140 1260 2500 2400 3200

85 V 170 120 880 1780 2400

71 V 142 100 620 1260 2400 2400

59 V 118 84 440 880 1780

50 V 100 70 320 620 1260

42 V 84 60 220 440 880

Output power bridged per two channels (W)

Load

Voltage Peak Limiter

Output power per channel (W)

Load

C 68:4

Voltage Peak Limiter

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 141 100 625 1000 1200 600 900

118 V 118 84 440 880 1200 600

100 V 100 70 315 630 1200 600 1200

85 V 85 60 220 440 890 600

71 V 71 50 155 310 630 600 630

59 V 59 42 110 220 440 600

50 V 50 35 80 160 310 600

42 V 42 30 55 110 220 440

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 282 200 2000 2400 1200 1800

118 V 236 168 1780 2400 1200

100 V 200 140 1260 2400 1200 2400

85 V 170 120 880 1780 1200

71 V 142 100 620 1260 1200 1260

59 V 118 84 440 880 1200

50 V 100 70 320 620 1200

42 V 84 60 220 440 880

C 48:4

Output power bridged per two channels (W)

Load

Voltage Peak Limiter

Output power per channel (W)

Load

Voltage Peak Limiter

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 141 100 600 700 700 300 700

118 V 118 84 440 700 600 300

100 V 100 70 310 700 600 300 700

85 V 85 60 220 440 600 300

71 V 71 50 160 310 600 300 600

59 V 59 42 110 220 440 300

50 V 50 35 80 160 310 300

42 V 42 30 55 110 220 300

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 282 200 1400 1200 600 1400

118 V 236 168 1400 1200 600

100 V 200 140 1400 1200 600 1400

85 V 170 120 1260 1200 600

71 V 142 100 880 1200 600 1200

59 V 118 84 620 880 600

50 V 100 70 440 620 600

42 V 84 60 320 440 600

Output power bridged per two channels (W)

Load

Voltage Peak Limiter

C 28:4

Voltage Peak Limiter

Output power per channel (W)

Load

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 141 100 400 400 300 n.r. 400

118 V 118 84 300 400 300 n.r.

100 V 100 70 300 400 300 n.r. 400

85 V 85 60 220 400 300 n.r.

71 V 71 50 155 310 300 n.r. 400

59 V 59 42 110 220 300 n.r.

50 V 50 35 80 160 300 n.r.

42 V 42 30 55 110 220 n.r.

VPL Setting V peak Vrms

16 !8 !4 !2 !Hi Z

141 V 282 200 800 600 n.r. 800

118 V 236 168 800 600 n.r.

100 V 200 140 800 600 n.r. 800

85 V 170 120 800 600 n.r.

71 V 142 100 620 600 n.r. 620

59 V 118 84 440 600 n.r.

50 V 100 70 320 600 n.r.

42 V 84 60 220 440 n.r.

Output power per channel (W)

Load

C 16:4

Voltage Peak Limiter

Output power bridged per two channels (W)

Load

Voltage Peak Limiter

Item no. VPL-CS_V4

C Series C 68:4, C 48:4, C 28:4, C 16:4: Dedicated Installation Ampliﬁers. Voltage Peak Limiter Load vs Power Tables

Lab.gruppen ab •Sweden

internationaL contact • [email protected] | uS contact • [email protected]

www.labgruppen.com
