SET UP GUIDE

MODEL NUMBER C79790V2

WIRELESS WEATHER

STATION

Table of Contents

Initial Setup

Power Up

Note: It may take up to 10 minutes for your sensor data to appear on your

station’s screen.

BASICS

1. Install 3 “AA” batteries into the Battery

Compartment of your Breeze Pro

Sensor.

2. Insert the 5V Power Adapter into

an outlet, and then plug it into the

Power Jack on the back of the

station. Next, remove the Insulation

Tab from the station’s Battery

Compartment.

Bottom of Breeze Pro Sensor

Model No. LTV-WSDTH03

Back of Station

Model No. C79790v2

WINDBASICS

TEMP. & HUMIDITY (TH)

LA CROSSE VIEW

FORECAST PRESSURE

APPENDIXEXTRA SENSORS SUPPORT

Viewing Your Wind Data

History Records

Wind Speed Alert

Initial Setup

Station Settings

Buttons

LCD Display Brightness

Auto-Dim Settings

Positioning Your Sensor

Basic Installation Options

Viewing Your TH Data

History Records

“Feels Like” Temp.

Connecting to the App

Connecting Your Station

Connecting Your Sensor

Seasonal Trees

Standalone Forecast Icons

Enhanced Forecast Data

Daily/Hourly Forecast

Relative Pressure

Speciﬁcations

Warranty/Patents

Recycling & Disposal

Cautions/Statements

Add-On TH Sensor

Add-On Sensor Info

Adding an Extra Sensor

Support Information

Factory Reset

Stay in Touch

20-22

03 04

Connecting to the App Connecting Your Station

LA CROSSE VIEW LA CROSSE VIEW

Connecting to Your Wi-Fi Network

Download the La Crosse View

Visit the App Store or Google Play Store to download the free La Crosse View

app onto your mobile device. Having troubles connecting? Make sure your mobile device is connected to your router’s

separate 2.4GHz Wi-Fi network, and that you’ve correctly entered your Wi-Fi password.

Stay connected to your home anytime, anywhere

with the La Crosse View app.

Monitor home conditions and set alerts so your home

can get ahold of you when something seems o.

Connecting your station is optional and the display

will function as a standalone unit without the Wi-Fi

connection. However, we recommend connecting

during the initial setup, as it will save you time and

unlock all of the advanced features right away.

Launch the App

Open the La Crosse View app and follow the on-screen setup instructions.

Stay Connected to Your Home

Anytime, Anywhere.

Checking Your Station’s Wi-Fi Status

Press the SET button on the top of the station to view your Wi-Fi Status.

• ALL OK CONNECTED: Your station is

connected to your Wi-Fi and its data should

be available on the station and in the app.

• SEE APP TO CONNECT: Check your La Crosse

View app for notiﬁcations.

• NO WEATHER SERVICE: Your Internet weather

and time services are not connecting. These

should resolve on their own, please be patient.

• LOST WIFI: Check your router and network

connections.

For more troubleshooting tips and support, scan the QR code or visit:

www.lacrossetechnology.com/lacrosseviewsupport

Now that you’ve created your La Crosse View account, it’s time to connect your

station to your home router using the La Crosse View app.

Ensure your station’s Wi-Fi Indicator

is ﬂashing. This is located on

the bottom of the station’s LCD

and indicates that the station is

searching for your Wi-Fi network.

If the icon isn’t ﬂashing, press and

hold the +/- buttons down together

until it begins to ﬂash.

When connected, the indicator

will become solid.

Station Settings

BASICS

* The default pressure reading is 29.92 INHg (1013 hPa). The station will acclimate on it’s own if the pressure

number is not set. Learn more on page 15

Use the +/- buttons on the

top of the station to adjust

the values.

Press the SET button to

conﬁrm selection and move

to next step.

You may exit the Settings

Menu at any time by pressing

the LIGHT button.

Settings Menu Order

Language • Greeting • 12/24 Hour Time • Hour • Minutes • Year • Month

Date • Fahrenheit/Celsius • Pressure Units (InHg/hPa) • Pressure Number

Setting* • Wind Speed Units (MPH or KMH) • Wind Direction (Letters or Degrees)

When the station is ﬁrst power on, it will begin searching for your outdoor

sensor, which should connect shortly.

To manually set your time, date, and other settings, hold the SET button to

enter the Settings Menu.

Notes: Weekday will set automatically after year, month, & date settings are adjusted.

If you’re connected to the Wi-Fi, the time and date will automatically update from the

Internet. See pages 3-4 for more information.

Connecting Your Sensor to La Crosse View App

LA CROSSE VIEW

•About ten minutes after connecting your station to

the app you should recieve an app notiﬁcation to

add the sensor.

•If this does not appear you can manually add the

sensor to your app.

Scan Sensor ID:

1. Open your La Crosse View app. On the Main Menu

go to “ADD/EDIT” and select “DEVICES”.

2. On the Devices page select “ADD DEVICE”.

3. Scan the Bar Code on your Breeze Pro Sensor or

add the ID number manually.

4. Conﬁrm the sensor image and device ID and add a

Device Name and Location Name. Select “DONE”.

In a few minutes you will receive sensor data in your

La Crosse View App.

123456-ABC

Buttons

BASICS

1. WIND ALERTS

Hold to enter Wind Alert

Settings. Press to turn Wind

Alert on/o.

2. WIND

Press to view Wind Speed

History. While viewing, hold the

MINUS button to delete the

history reading.

3. TEMP.

Press to view Temperature

and Humidity History. While

viewing, hold MINUS button

to delete the history reading.

6. EXTRA

Press to toggle through extra

sensors and pressure. Hold to

add sensors. While viewing,

hold the MINUS button delete

the sensor.

9. DAILY/HOURLY

Press to see Daily or Hourly

Forecast*

4. SET

Press to view Wi-Fi status.

Hold to enter Settings Menu.

7. SENSOR

Press to view sensor ID

numbers. While viewing, hold

the MINUS button delete the

sensor.

5. PLUS/MINUS (+/-)

Use to adjust values. Hold both

together to search for Wi-Fi

signal.

8. LIGHT

Press to adjust backlight. Hold

to enter Auto-Dim settings.

6 8

Side View

* Your display must be connected to Wi-Fi to receive Daily/Hourly forecast information. 07 08

LCD Display Brightness

Adjusting the LCD Display Brightness

Auto-Dim Settings

Press the LIGHT button to adjust the backlight intensity.

There are 4 brightness levels, plus an o option.

Hold the LIGHT button to enter

the Auto-Dim Settings Menu.

Program your display to automatically

dim during preselected times.

Press the +/- buttons to turn the

Auto-Dim feature on or o. Press

LIGHT to conﬁrm.

Press the +/- buttons to adjust the

starting hour. Press LIGHT to conﬁrm.

Press the +/- buttons to adjust the

stopping hour. Press LIGHT to

conﬁrm and exit.

The icon will appear on the LCD when the Auto-Dim feature activated.

BASICS

09 10

U-bolt Adapters

Tripod Setup

Chimney Mount

1B Pole Adapter

1A Adjustable Base

Basic Assembly

Basic Installation Options

Advanced Installation Options

Some advanced installation options include tripods, wall mounts, eave cross mounts, chimney mounts,

and many others. Any of these can be combined with U-bolts for attachment onto a tall cylindrical conduit

using our Adjustable Base. Please note that these advanced options will require additional equipment and

possibly professional help for best results.

The illustrations above are not to scale and are for informative purposes only.

La Crosse Technology is not responsible for any damages or injury that may occur during installation.

BASICS

Positioning the Breeze Pro Sensor

For Accurate Measurements

Included Mounting Accessories

•Ensure the sensor is mounted level with the Solar Panel facing

directly to the south. This will help optimize battery life and transmit

correct wind direction readings.

•Ideally, the Breeze Pro Sensor should be mounted on the tallest

object in your area. Avoid positioning the sensor in line or below

eaves, rooﬂines, trees, or other objects that may obstruct wind

readings.

•Make sure all screws on the Mounting Bracket, Winds Cups, and

Wind Vane, are securely fastened.

•The sensor should be mounted with the Wind Cups on top.

Mast

The horizontal conduit where the sensor

attaches. This piece will connect to either

the Adjustable Base or Pole Adapter.

Adjustable Base

The main bracket used for mounting onto ﬂat surfaces or with

added U-bolts (not included). The grooves and Hand Screw allow

the bracket to secure to angled surfaces while still ensuring the

Mast and sensor are level.

Hand Screw

Used to lock down and secure the Mast

to the Adjustable Base or Pole Adapter.

Alignment Arrows

Provide exact 90 or 180 degree

angles when aligned with the arrow

on the Mast.

Pole Adapter

Used in place of the Adjustable Base

for mounting on top of cylindrical

conduits.

1-Inch Maximum Pole Diameter

Wind Speed History and Alerts

WIND

Viewing Wind Speed History Records

Activate/Deactivate Wind Speed Alert Important Notes:

Press the WIND button to toggle

through wind speed history records

with time and date stamps.

The wind speed records include:

past 24 hours, 7 days, 1 month, & 1 year.

Press and release the WIND ALERTS button to

activate/deactivate the alert. WIND SPEED ALERT

ON or OFF will appear on the bottom of the LCD.

•The alert is defaulted to be o.

•When the armed alert value is reached, the station

will beep and the icon will ﬂash. Press any button

to stop the alert sound.

•The Alert Icon will remain ﬂashing until out of the

alert range.

•This Wind Speed Alert is for the station only

and will not aect the app.

1. Hold the WIND ALERTS button for to enter the Alert Settings Menu.

2. Use the +/- buttons adjust the on/o and wind speed settings. Press the

WIND ALERTS button to conﬁrm your selection.

3. Your wind speed alert is active when the icon on.

Setting the Wind Speed Alert Monthly Wind Speed Record Example

Viewing Your Wind Data

WIND

1. WIND SPEED TREND

INDICATOR

Shows wind speed trends

over the past 60 minutes

2. COMPASS ROSE

Displays cardinal direction

with animated arrows

(16 directions total)

5. RECEPTION INDICATOR

Indicates if the station is

receiving data from the

sensor

8. TOP WIND SPEED

The top wind speed in

the past 60 minutes

3. LOW BATTERY ICON

Appears when the sensor

battery needs to be

replaced

6. “NOW” WIND SPEED

The top wind speed in the

past 31 seconds

4. WIND DIRECTION

Choose between cardinal

points (letters) or degrees

in the Settings Menu

7. WIND SPEED ALERT

Appears if a wind speed

alert is set & active 11

2 3

7. INDOOR TEMPERATURE

Current Indoor Temperature

8. INDOOR HUMIDITY

Current Indoor Humidity

1413

Current Temperature: When the temperature is between 51°F and 79°F the reading

Viewing Your Forecast Data

FORECAST

Forecast Icons

Please Note: The Forecast Icons may not represent your current weather. They are a future prediction

of the weather to come over the next 12 hours.

When using as a standalone station, the display

will use changes in barometric pressure to predict

your weather to come in the next 12 hours. This is

represented by the 6 forecast scenes below.

However, when connected to Wi-Fi, the station

will receive additional weather icons, chance of

precipitation values, and future forecast information.

These enhanced Internet features are powered by

AccuWeather.*

Seasonal Trees

Foliage Scenes

The foliage scene in the forecast section changes

seasonally. The dates are pre-programmed.

*Your display must be connected to Wi-Fi to receive AccuWeather forecast data.

Available Forecast Icons on Standalone Station

Sunny Clouds T-StormPartly Sunny Rain Snow

Spring (March 20th to June 20th)

Summer (June 21st to Sept. 20th)

Fall (Sept. 21st to Dec. 20th)

Winter (Dec. 21st to March 19th)

Viewing Your Forecast Data

FORECAST

Daily & Hourly Forecast Buttons

When connected to Wi-Fi, use the DAILY & HOURLY buttons on the side of the station to view

future forecast information.

Tip: The icon will appear in the top right corner of the forecast section when your display is

connected and receiving AccuWeather forecasts.

Sunny

Light Snow

Clouds

Wintry Mix

Rain

Ice

Partly Sunny

Snow

Light Rain

Windy

T-Storm

Fog

Available Forecast Icons when Connected*

Daily Forecast: Press the DAILY

button on the side of the station to

automatically scroll through 7 days

of forecast data, including forecast

icons and highs and lows.

Hourly Forecast: Press the

HOURLY button to view 12 hours

of future forecasts, including

forecast icons and forecasted

temp. & humidity with time stamps.

Relative Pressure

Add-On Temperature & Humidity Sensor

PRESSURE

EXTRA SENSORS

•Your Relative Pressure reading will come from your

station’s internal barometer.

•Please allow up to 10 days for automatic calibration, or

program your local pressure value in the Settings Menu.

•The arrows located to the left of the values represents

Pressure Tendency (rising/falling).

2. Hold the MINUS (-) button to delete these

Temperature & Humidity readings.

3. Press the SENSOR button until this Outdoor

Temp. and Humidity section lights up again.

Then hold the PLUS (+) button until the blue

Sensor Reception Indicator starts to animate.

Adding a Separate Temperature & Humidity Sensor

Pressure Reading Example

If you feel the temperature & humidity is not reading correctly from your

Breeze Pro Sensor, you can add a separate sensor to your system.

Visit: www.lacrossetechnology.com/view to learn more.

1. Press the SENSOR button until you see the

Outdoor Temperature and Humidity section light

up on screen. “ID WTH 123” and “TWH SENSOR”

will appear below.

Install new batteries into the add-on sensor

and press the TX button inside its battery

compartment. The LED light on the sensor

will ﬂash.

The sensor should connect almost instantly

with its data appearing on screen. The

icon will appear when an add-on TH sensor

is being used.

Additional Add-On Sensors

EXTRA SENSORS

Rain Data Example

Whether you choose to connect with the La Crosse

View app or not, this station can display data for up

to 4 extra sensors. This data will appear in the green

EXTRA SENSOR section on the LCD, and in your

La Crosse View app if connected.

Scan the QR code above or visit:

www.lacrossetechnology.com/R3RainSensor

www.lacrossetechnology.com/view

Model Number

LTV-R3

To learn about all of your

add-on sensor options,

scan the QR code or visit:

2. Install batteries into your sensor. If the sensor

has a TX button, press it to force a transmission

signal. This button is usually located in or near

the sensor’s battery compartment. The LED

light on the sensor will ﬂash once.

3. Your sensor should connect within the next 3

minutes, brieﬂy displaying its ID and type on

the LCD. The Sensor Reception Indicator will

show solid on the screen when a sensor is

connected.

Adding Sensors to Your StationWould you like backyard rain data as well?

1. Hold the EXTRA button until you see the Sensor

Reception Indicator start to animate.

Note: When ﬁrst powering up, or after a factory

reset, extra sensors should automatically connect

to your station.

4. Press the EXTRA button to cycle through the

data you’d like displayed on the LCD. The

Auto Scroll Icon ( ) will appear if activated.

Table of contents

Other La Crosse Technology Weather Station manuals

La Crosse Technology

La Crosse Technology WS-9119U User manual

La Crosse Technology

La Crosse Technology Wireless Weather Station User manual

La Crosse Technology

La Crosse Technology V21-WTH Configuration guide

La Crosse Technology

La Crosse Technology 327-1418BW User manual

La Crosse Technology

La Crosse Technology WS-9025U Manual

La Crosse Technology

La Crosse Technology WS-9160UV2 Dimensions

La Crosse Technology

La Crosse Technology WS-9014 User manual

La Crosse Technology

La Crosse Technology V10-TH User manual

La Crosse Technology

La Crosse Technology S86842 Operating and maintenance manual

La Crosse Technology

La Crosse Technology Wireless Weather Station User manual

La Crosse Technology

La Crosse Technology WS-7032U User manual

La Crosse Technology

La Crosse Technology WS-2308AL User manual

La Crosse Technology

La Crosse Technology Wireless Weather Station Dimensions

La Crosse Technology

La Crosse Technology TX231RW User manual

La Crosse Technology

La Crosse Technology CA76669 User manual

La Crosse Technology

La Crosse Technology WS-8035 User manual

La Crosse Technology

La Crosse Technology WS-3502 User manual

La Crosse Technology

La Crosse Technology S88785 User manual

La Crosse Technology

La Crosse Technology C85845V2 User manual

La Crosse Technology

La Crosse Technology 328-47577 User manual

La Crosse Technology

La Crosse Technology 616146V4 Dimensions

La Crosse Technology

La Crosse Technology CA87092 Operating and maintenance manual

La Crosse Technology

La Crosse Technology WS-7394U User manual

La Crosse Technology

La Crosse Technology V15 User manual

Popular Weather Station manuals by other brands

Auriol

Auriol AHFL 433 A1 operating instructions

NexSens

NexSens G2-HYDROMET quick start

Hyundai

Hyundai WS 2202 instruction manual

IROX

IROX HBVR761 UV-X user manual

ADE

ADE WS 1711 operating instructions

Auriol

Auriol z29592 Operation and safety notes

Auriol

Auriol 296289 Operation and safety notes

Hyundai

Hyundai WS 2266 instruction manual

Ventus

Ventus W177 owner's manual

National Geographic

National Geographic VA Colour RC instruction manual

Renkforce

Renkforce 1208067 operating instructions

Levenhuk

Levenhuk Discovery Report WA40 quick start guide

Instant Transmission

Instant Transmission MA 10410 instruction manual

Lutron Electronics

Lutron Electronics PHB-318 Operation manual

WAREMA

WAREMA EWFS Weather station eco Operating and installation instructions

TFA

TFA 30.3013.IT instruction manual

Alecto

Alecto WS-1200 user manual

Oregon Scientific

Oregon Scientific RMR966PA instruction manual
