La Crosse Technology VA1 User manual
SET UP GUIDE
Wi-Fi PROJECTION ALARM CLOCK
with Outdoor Temperature & Humidity
MODEL NUMBER VA1
Table of Contents
BASICS LA CROSSE VIEW
WEATHER
APPENDIX SUPPORT
Initial Setup
Alarm Clock Settings
Buttons & Ports
LCD Display Brightness
Auto-Dim Settings
Mounting Your Sensor
Connecting to the App
Connecting Your Alarm
Clock
Viewing Your Data
Forecast & Moon Phase
Icons
Forecasted HIs & LOs
and Indoor Comfort
Mounting Your Sensor
Specifications
Warranty
Recycling & Disposal
Cautions/Statements
Patents
Support Information
Factory Reset
Stay in Touch
02
05
06
07
07
11
ALARM
Setting Your Alarm
Activating/Deactivating
Your Alarm
Snooze Duration
Countdown
08
08
08
14
15
15
14-16
16
EXTRA SENSORS PROJECTION
Adding Extra Sensors
Viewing Your Sensor
Data: LCD
Viewing Your Sensor
Data: Projection
Adjusting Projection Image
Tilting Projection Tube
Rotating Projection Image
Viewing Your Sensor Data/
Alternate Projection Mode
12
12
12
13
13
13
12
17
17
17
03
04
09-11
10
11
11
02
Initial Setup
Power Up
Note: It may take up to 10 minutes for your sensor data to appear on your Alarm
Clock’s screen.
BASICS
Back of Alarm Clock
Thermo-Hygro
Sensor
Alarm Clock
Insert the 5V Power Adapter into an outlet, and then plug it into the Power Jack on the back
of the Alarm Clock. Next, remove the Insulation Tab from the Battery Compartment located on
the bottom of the Alarm Clock.
Thermo-Hygro (TH) Sensor
Install 2 fresh “AA” batteries according to polarity and replace battery cover. The blue LED light will
flash when transmitting.
03
Connecting to the App
LA CROSSE VIEW
Download the La Crosse View App
Visit the App Store or Google Play Store to download the free La Crosse View
app onto your mobile device.
Stay connected to your home anytime, anywhere
with the La Crosse View app.
Monitor home conditions and set alerts so your home
can get ahold of you when something seems o.
Connecting your alarm clock is optional and the
display will function as a standalone unit without
the Wi-Fi connection. However, we recommend
connecting during the initial setup, as it will save you
time and unlock all of the advanced features right
Launch the App
Open the La Crosse View app and follow the on-screen setup instructions.
Stay Connected to Your Home
Anytime, Anywhere.
For more information, scan the QR code or visit:
www.lacrossetechnology.com/view
04
Connecting Your Alarm Clock
LA CROSSE VIEW
Connecting to Your Wi-Fi Network
Checking Your Alarm Clock’s Wi-Fi Status
Press the SET button on the top of the Alarm Clock to view your Wi-Fi Status.
ALL OK CONNECTED: Your Alarm Clock is connected to
your Wi-Fi and its data should be available on the Alarm
Clock and in the app.
SEE APP TO CONNECT: Check your La Crosse View
app for notifications.
NO WEATHER SERVICE: Your Internet weather and time
services are not connecting. These should resolve on
their own, please be patient.
LOST WIFI: Check your router and network
connections.
Now that you’ve created your La Crosse View account, it’s time to connect your Alarm Clock
to your home router using the La Crosse View app.
The La Crosse View app is required to connect the Alarm Clock to your Wi-Fi network. Download,
install, and log into your La Crosse View account first.
New User Initial Setup: When first setting
up your Alarm Clock, the app it will lead you
through a series of instructions to help get
your Alarm Clock added into your account and
connected to your home Wi-Fi network.
Manually Add & Connect Display: After the
initial walk-through, Alarm Clocks can be
added and connected via the Devices tab
in the app’s main menu. Simply tap the Add
Device or Plus (+) button at the bottom of the
Devices page in the app.
1.
Follow the initial app instructions or manually add the display into your account.2.
When connected, the indicator on the display will become solid.3.
Alarm Clock Settings
BASICS
Use the +/- buttons on the
top of the Alarm Clock to
adjust the values.
Press the SET button to
confirm selection and move
to next step.
You may exit the Settings
Menu at any time by pressing
the SNOOZE/LIGHT button.
Settings Menu Order
Greeting • Language • 12/24 Hour Time • Hour • Minute • Year • Month
Date • Calendar Order (Month/Date or Date/Month) • Fahrenheit/Celsius
Thank You
1.
2.
When the Alarm Clock is first powered on, it will begin searching for your
outdoor sensor, which should connect shortly.
To manually set your time, date, and other settings, hold the SET button to
enter the Settings Menu.
Notes: Weekday will set automatically after year, month, & date settings are adjusted.
If you’re connected to the Wi-Fi, the time and date will automatically update from the
Internet. See pages 3-4 for more information. 05
Buttons & Ports
BASICS
1. ALARM
Press to activate/deactivate
alarm. Hold to enter Alarm
Settings Menu.
3. PROJECTION ( )
Press to adjust projection
intensity.
5. SNOOZE/LIGHT
Press to snooze sounding alarm,
adjust backlight, or hold to enter
Auto-Dim Settings.
7. SET
Press to view Wi-Fi status.
Hold to enter Settings Menu.
2. EXTRA SENSOR
Press to toggle between alarm
time, nap timer duration, internet
outdoor temperature*, or add-
on sensor data. Hold to add
additional sensors.
4. PROJ INFO
Press to toggle through
projection options. Hold to
alternate projection between
available options.
6. PLUS/MINUS (+/-)
Use to adjust values, hold to
change values quickly. Hold
+/- buttons together to clear
and search for a new Wi-Fi
connection.
8. NAP 9. USB CHARGING PORT
Press to start Nap Countdown
Timer. Hold to set Nap Timer
duration.
Using your own USB cable,
conveniently charge 1 Amp
devices.
06
1
23
4
5
6
7
8
*Your Alarm Clock must be connected to Wi-Fi to receive Internet data. Internet data updates 4-6 times a day.
Back of Alarm Clock
9
LCD Display Brightness
Adjusting the LCD Display Brightness
Auto-Dim Settings
Press the SNOOZE/LIGHT button to adjust the
backlight intensity. There are 4 brightness levels,
plus an o option.
1.
2.
3.
4.
Hold the SNOOZE/LIGHT button to
enter the Auto-Dim Settings Menu.
Program your Alarm Clock to automatically
dim during preselected times.
Press the +/- buttons to turn the
Auto-Dim feature on or o. Press
SNOOZE/LIGHT to confirm.
Press the +/- buttons to adjust
the starting hour. Press SNOOZE/
LIGHT to confirm.
Press the +/- buttons to adjust the
stopping hour. Press SNOOZE/
LIGHT to confirm and exit.
AUTO DIM will appear on the LCD when the Auto-Dim feature activated.
BASICS
07
08
4. Your sound alarm is now activated,
indicated by the icon on the LCD.
1. Hold the ALARM button on the
top of the alarm clock to enter the
Alarm Settings Menu.
2. Use the +/- buttons to set your
desired time. Press ALARM to
confirm.
3. Next, use the +/- buttons to set your
desired snooze duration (5 to 120
minutes). Press ALARM to confirm
and exit the Alarm Settings Menu.
Time Alarm
Activating & Deactivating the Alarm
Setting the Alarm
1.
2.
Press the ALARM button to activate/deactivate the alarm and to view
your alarm time.
The icon will appear on the LCD when the alarm is active.
ALARM
Snooze Duration Countdown
When your alarm sounds, tap the SNOOZE/LIGHT button to snooze your alarm for your
preselected snooze duration. A countdown will appear on screen. When the snooze time
reaches “00,” the alarm will sound again. The snooze feature can be repeated as many
times as desired.
09
1
24
5
1. FORECAST ICONS (or Moon Phase)
Represent a future prediction of the weather
to come over the next 12 hours*
2. CHANCE OF PRECIPITATION
Predicted chance of rainfall in the next 12
hours. Displayed as a percentage.*
4. SENSOR RECEPTION INDICATOR
Indicates if the alarm clock is receiving data
from the sensor
6. INDOOR TEMPERATURE & HUMIDITY
Current Indoor Temperature and Humidity
3. OUTDOOR TEMPERATURE & HUMIDITY
Current Outdoor Temperature and Humidity
*Your Alarm Clock must be connected to Wi-Fi to receive AccuWeather data. If unconnected, forecast scene will be
replaced by Moon Phase icons and daily highs and lows will be replaced with Indoor Comfort Level.
Viewing Your Data
WEATHER
5. FORECASTED HIs and LOs*
(or Indoor Comfort Level)
Daily Forecasted Highs and Lows from
AccuWeather*
3
6
