Kyocera KS10 User manual

Model KS10

KS10

MULTICRYSTAL

PHOTOVOLTAIC

MODULE

TYPICAL OUTPUT 10 Wp

HIGHLIGHTS OF KYOCERA PHOTOVOLTAIC MODULES

Kyocera´s advanced cell processing technology and automated production facilities have produced a highly

efficient multicrystal photovoltaic module.

These cells are encapsulated between a tempered glass cover and an EVA pottant with PVF back sheet to

provide maximum protection from the severest environmental conditions.

The entire laminate is installed in an anodized aluminium frame to provide structural strength and ease of

installation.

APPLICATIONS

Microwave / radio repeater stations Pumping systems for irrigation, rural

Electrification of villages in remote areas water supplies and livestock watering

Medical facilities in rural areas Aviation obstruction lights

Power source for summer vacation homes Cathodic protection systems

Emergency communication systems Desalination systems

Water quality and environmental data monitoring Recreational vehicles

systems Railroad signals

Navigation lighthouses, and ocean buoys Sailboat charging systems

SPECIFICATIONS

Electrical Specifications Physical Specifications

Maximum Power

10 Watts

Length

304 mm

Maximum Power Voltage

16.9 Volts

Width

352 mm

Maximum Power Current

0.60 Amps

Depth

22 mm

Open Circuit Voltage

21.5 Volts

Weight

1.9 kg

Short-Circuit Current

0.62 Amps

Note: The electrical specifications are under test conditions of Irradiance of

1 kW/m2, Spectrum of 1.5 air mass and cell temperature of 25ºC

SOLARTEC S.A.

Méjico 2145 – 1640 Martínez

Buenos Aires – Argentina

Tel: 54-11-4836-1040

Fax: 54-11-4836-0808/1381

[email protected]

www.solartec.com.ar

The contents of this catalogue are subject to change without prior notice for further improvement.
