Kurzweil HUB7 - REV A User manual
© Young Chang Co., Ltd. 2002. All rights reserved. Kurzweil ® is a product line of
Young Chang Co., Ltd. Young Chang®, Kurzweil ®, V. A. S. T. ®, KDFX®,
Pitcher®, and LaserVerb®, RSP8 ™, HUB7 ™, KSP8 ™, K2600™, K2500™, and
K2000™ are trademarks of Young Chang Co., Ltd. SmartMedia™ is a trademark
of Toshiba Corporation. ADAT® is a registered trademark of Alesis Corporation.
All other products and brand names are trademarks or registered trademarks of
their respective companies. Product features and specifications are subject to
change without notice.
Part Number: 910366 Rev. A
Young Chang International Contacts
Contact the nearest Young Chang office listed below to locate
your local Young Chang/ Kurzweil representative.
Young Chang America, Inc.
P.O. Box 99995
Lakewood, WA 98499-0995
Tel: 1-253-589-3200
Fax: 1-253-984-0245
Young Chang Co., Ltd.
178-55 Gajwa-Dong
Seo-Ku, Inchon, Korea 404-714
Tel: 011-82-32-570-1380
Fax: 011-82-32-570-1218
Young Chang America, Inc. (Canadian Division)
3650 Victoria Park Ave. Suite 105
Toronto, Ontario Canada M2H 3P7
Tel: 1-416-492-9899
Fax: 1-416-492-9299
World Wide Web Home Page
http://www.kurzweilmusicsystems.com
IMPORTANT SAFETY & INSTALLATION INSTRUCTIONS
INSTRUCTIONS PERTAINING TO THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS
WARNING
- When using electric products, basic precautions should always be
followed, including the following:
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any of the ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat regis-
ters, stoves, or other apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. When
the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched, particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with apparatus. When a cart is used, use cau-
tion when moving the cart/apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is re-
quired when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or ob-
jects have fallen into the apparatus, the apparatus has been ex-
posed to rain or moisture, does not operate normally, or has been
dropped.
15) Do not expose this apparatus to dripping or splashing and ensure
that no objects filled with liquids, such as vases, are placed on the
apparatus.
16) WARNING: To reduce the risk of fire or electric shock do not expose
this apparatus to rain or moisture.
SAVE THESE INSTRUCTIONS
RADIO AND TELEVISION INTERFERENCE
Warning:
Changes or modifications to this instrument not expressly approved by
Young Chang could void your authority to operate the instrument.
Important:
When connecting this product to accessories and/or other equipment
use only high quality shielded cables.
Note:
This instrument has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This instrument generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this instrument does cause harmful interference to radio or television reception,
which can be determined by turning the instrument off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the instrument and the receiver.
• Connect the instrument into an outlet on a circuit other than the one to which the
receiver is connected.
• If necessary consult your dealer or an experienced radio/television technician for
additional suggestions.
NOTICE
This apparatus does not exceed the Class A limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
AVIS
Le present appareil numerique n’emet pas de bruits radioelectriques depassant
les limites applicables aux appareils numeriques de la class A prescrites dans le
Reglement sur le brouillage radioelectrique edicte par le ministere des
Communications du Canada.
The lightning flash with the arrowhead symbol,
within an equilateral triangle, is intended to alert
the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompan
y
in
g
the product.
CAUTION
Table of Contents
v
Using the RSP8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
HUB7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
KSP8 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Setting Up Your RSP8 . . . . . . . . . . . . . . . . . . . . . . . 1-3
Connecting Your RSP8. . . . . . . . . . . . . . . . . . . . . . . 1-4
Aftermarket Cables . . . . . . . . . . . . . . . . . . . . . . . 1-5
Starting Up Your RSP8. . . . . . . . . . . . . . . . . . . . . . . 1-6
Adjusting the RSP8 Display . . . . . . . . . . . . . . . . 1-6
Remote Configuration Menus. . . . . . . . . . . . . . . . . . 1-7
Using the Joystick. . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
The Remote:JOYSTIK Page. . . . . . . . . . . . . . . . 1-10
What the Joystick Transmits. . . . . . . . . . . . . . . . 1-12
Joystick Modes . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Using MIDI to Record Panning Information . . . 1-16
Using MIDI for Effect Modulations . . . . . . . . . . 1-20
Using the Control Knobs . . . . . . . . . . . . . . . . . . . . . 1-23
The Remote:KNOBS Page . . . . . . . . . . . . . . . . . 1-23
Intuitive Entry with Control Knobs or Joystick . 1-28
Using the HUB7. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Which KSP8 Are You Talking To? . . . . . . . . . . 2-2
Configuration Examples . . . . . . . . . . . . . . . . . . . . . . 2-3
HUB7 Connecting Cables. . . . . . . . . . . . . . . . . . . . . 2-6
HUB7 Power Adapter . . . . . . . . . . . . . . . . . . . . . . . . 2-7
RSP8 Diagnostics and Troubleshooting . . . . . . . . A-1
RSP8 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . A-1
Main Diagnostic Menu . . . . . . . . . . . . . . . . . . . . A-2
Burnin Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . A-2
Description of the Individual Diagnostic Tests . A-3
Description of the Controls Diagnostic. . . . . . . . A-6
In Case of Problems . . . . . . . . . . . . . . . . . . . . . . . . . A-9
vi
1-1
Chapter 1
Using the RSP8
The RSP8 is a remote control for Kurzweil’s KSP8 multi-bus
signal processor that provides you convenient access to all of the
KSP8’s front panel functions. The RSP8 also gives you eight
knobs for adjusting effect and other parameters, along with a
joystick for surround panning. You can also configure the knobs
and/or joystick to send MIDI controller values, to either a KSP8
or an external device.
HUB7
Chapter 2 of this manual describes the HUB7 repeater/
concentrator, which lets you use a single RSP8 to control up to
seven KSP8s, and also allows you to extend cable distances
between the RSP8 and KSP8(s).
Using the RSP8
1-2
KSP8 Software
To make use of the RSP8, you need operating system software
version 1.5 or higher running on your KSP8. If the version level of
your KSP8 software (as shown on the KSP8 startup screen) is
lower than 1.5, and you have not been provided with a software
update, contact your Kurzweil dealer, or check for the latest
updates by logging on to our web site:
http://www.kurzweilmusicsystems.com
For Other KSP8 Questions
This manual describes only KSP8 features that pertain to the
RSP8 and HUB7. For information on all other KSP8 functions,
refer to the
KSP8 User’s Guide
.
Setting Up Your RSP8
1-3
Setting Up Your RSP8
The RSP8 lets you access up to seven KSP8s from any location
that’s convenient for you. You can either:
•
set the RSP8 on top of a table or mixing desk (the bottom of
the RSP8 is covered with a soft material that will not scratch
surfaces).
•
attach the supplied microphone stand adapter to the bottom
of the RSP8, then thread the adapter onto the top of a
standard microphone stand, as shown in Figure 1-1. You’ll
probably find this works best if you attach the adapter to the
bottom of the RSP8 before you attach it to the mic stand.
Figure 1-1. Attaching the RSP8 to a microphone stand.
Using the RSP8
1-4
Connecting Your RSP8
Your RSP8 is supplied with a fully-shielded 16 meter (52 foot)
connecting cable. Plug one end of this cable into the Remote
connector on the back of your KSP8, then plug the other end into
the rear of your RSP8. Note that the flat side or arrow marking on
the connector should face up on the RSP8 and down on the KSP8.
The RSP8 is also powered through this cable so there is no
separate power cord or adapter to worry about.
The KSP8 and RSP8 allow “hot plugging,” which means that you
can connect and disconnect the cable at any time, whether or not
the power is on.
There is no power switch on the RSP8; it simply follows the
power status of the connected KSP8. If you want your RSP8 to be
fully off, simply unplug it. You may find it more convenient to
use the standby feature (described in the
KSP8 User’s Guide
),
which reduces power consumption, extends display life, and
allows for near-instant waking.
