Kurzweil MP15 User manual

2. Piano Lock ..........................

1. Layering Two Sounds .........

Chapter 4 Selecting Sounds ...............

1. Selecting Sounds ...............

Chapter 5 Layering ............................

Chapter 6 Splitting .............................

Chapter 7 Rhythm ..............................

1. Splitting the Keyboard ........ 15

2. Split Functions ..................... 15

Recording a Performance ....

Chapter 9 Recording ........................

Chapter10DemoSongs.....................

Listening to Demo Songs ......

1. Selecting a Rhythm ............. 16

2. Rhythm Functions ................ 16

Chapter 14 Sound List ........................ 31

Chapter 17 Specifications .................... 34

2. Layer Functions ................... 14

Chapter 8 Functions .......................... 17

1. Function Mode ................... 17

2. Selecting a Function ........... 17

Chapter 15 Setup & Rhythm List ....... 32

Chapter16DemoSongList................ 33

Contents

Main Features ..........................

Main Buttons ............................

1. Piano Assembly ...................

2. Applying Power ....................

3. Setting the Volume .............

Chapter 2 Main Features ...................

Chapter 1 Front Panel ........................

Chapter 3 Piano Assembly .................

Chapter 11 Pedals .................................

1. Pedals ..................................

2. Using the Pedals ................

Chapter 12 MIDI ....................................

1. MIDI Channel ......................

2. Connecting MIDI ................

1. Using Headphones ............

2. Aux In ..................................

3. Aux Out ...............................

Chapter 13 Connection ........................

4. MP3 Aux In .........................

Chapter 1

Main Buttons

(1) Voice selection buttons

Select among the 128 Voices and 64 Setups with the [Voices/Setup] button. Select

Banks, Groups, and individual sounds with the 16 Sound Select buttons.

(2) Rhythm button

Select among the 60 rhythms with the [Rhythm] button. Select groups and individual

rhythms with the 16 Sound Select buttons.

(3) Layer button

You can layer two voices and play them simultaneously to create a thicker

and richer sound.

(4) Split button

For playing different voices on the left-hand and right-hand section of the

keyboard.

(5) Demo songs

Select among the 50 demonstration songs.

(6) Function button

You may set functions like Tune, Rhythm Tempo, Metronome, Tempo, etc.

(7) Record button

For recording your keyboard performance.

(8) Play/Stop button

These control playback of or stop the demonstration songs and your recorded songs.

(9) Transpose buttons

You can shift the pitch of the entire keyboard up or down so that the pitch

will match that of the another instrument or singer.

8Front Panel

■

USB MIDI

■

88 note fully weighted hammer action keyboard

3 Pedals (Sustain, Sostenuto, Soft)

10 Touch sensitivity settings

Stereo Audio Input, Output

2 Headphone jacks

Standard MIDI In, Out

1Line16CharacterLCD

128 Voices + 64 Setups

Layer, Split mode

Transpose, Tune functions

Front panel MP3 Aux In

Recording function

Thank you for purchasing the KURZWEIL's Digital Piano. We recommend that you

read this manual carefully so that you can fully take advantage of the advanced

and convenient functions of the KURZWEIL's Digital Piano.

Main Features

Chapter 2

Main Features 7

■

60 Rhythm patterns

①

⑥

②

⑦

③

⑧

④

678 9 10

⑨

Chapter 3

8Piano Assembly

Check that all of the following items are present.

Keyboard

Side panel of stand (Left)

Side panel of stand (Right)

Pedal box

Screws for side panel and keyboard

Screws for side panel and pedal box

Screws for side panel and rear panel

Screws for rear panel

Please check the quantity of related part number.

Part Name Part Name

Q'ty Q'ty

⑤

EA EA

Rear panel Cord holder

Screws for keyboard

④

Chapter 3

Piano Assembly 9

- Assembly should be carried out by at least two persons.

- Assemble the stand on a hard and flat floor with ample space.

- Be sure to use the included screws, and insert screws of the correct size in the correct

hole locations. Use of incorrect screws can damage the product.

Attach the pedal cord holders to the rear panel

as shown, then clip the cord into the holders

1. Place the pedal box on the left side

panel and use screws to fasten

the side panel.

2. Place the pedal box on the right side

panel and use screws to fasten

the side panel.

3. You can find the pedal cable in the

pedal box . Untie and straighten out

the bundled pedal cable.

1. Fit into the rear panel's hole in the side

panel brackets and then use the screws

to fasten the rear panel.

2. Use the screws to fasten the bottom

of the rear panel.

8Piano Assembly

1. Place the keyboard on the stand and fit into the holes in the

side panel brackets.

2. Fasten the keyboard to the side panel using screws .

3. Fasten the keyboard to the front legs using screws .

4. Insert the pedal cable plug into the pedal jack located on the

bottom of the keyboard.

5. Rotate the pedal adjuster until it comes in firm contact with

the floor surface. If the adjuster is not in firm contact with the

floor, the pedals will wobble and may malfunction.

Insert the pedal

cord plug to the

pedal jack from

the rear.
