Technical data
The hand power sweeper must be inspected for proper condition and operating
safety before any use. If the condition is not impeccable, the hand power sweeper
must not be used.
The person who operates the device must use it as intended and move it under
consideration of the local situation. The user also must ensure that the device
cannot harm any third parties in operation. Special attention must be paid to
children!
Substances that are toxic, carcinogenic or flammable, such as arsenic, asbestos,
barium, beryllium, lead, pesticides, or other substances harmful to health must
not be cleaned up with this device.
The hand power sweeper is not intended for cleaning up any liquids, flammable
or glowing objects such as cigarettes, matches, ash or similar.
There is a danger of crushing and shearing at the push bar, the waste bin, the side
brushes and the belts. Use resilient gloves. This also applies when removing glass,
metal or other pointed and sharp-edged materials from the waste bin.
Empty the waste bin of the hand power sweeper after every use.
The hand power sweeper must be used in dry conditions. It must not be used or
stored outdoors in wet conditions.
If used in elevated positions where there is a risk of the unit falling to the ground,
it must be secured against rolling away or tipping over.
The hand power sweeper is not designed for use by persons with restricted physi-
cal, sensory or mental abilities (including children)!
Technical data Colly 800
Drive Manual
Area sweeping capacity 2000 m²/h at 2.5 km/h
Side brushes 2 foldable side brushes mit height-adjustable
Drive wheels Ø 300 mm
Sweeper roller Ø 254 mm
Working width 800 mm
Bristles Combined hard/soft star-shaped
Waste bin volume 30 liters
Push bar Adjustable and foldable
Exhaust air filter 2 x 6000 mm², PPI 45 filter
Dimensions L / W / H (with side brushes) 980 mm x 850 mm x 390 mm (push-bar folded in)
Space needed when standing 750 mm x 400 mm
Weight 19 kg
Ord. no. 50079
Safety notes - This is prohibited!
