Kramer PSE-2 User manual

USER MANUAL

MODEL:

PSE-2

10Gb POE Injector

P/N: 2900-300452 Rev 1 www.kramerAV.com

This page is intentionally left blank

PSE-2 – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Shielded Twisted Pair/Unshielded Twisted Pair 3

2.4Recycling Kramer Products 3

3Overview 4

3.1 About HDBaseT™ Technology 4

4Defining the PSE-2 10Gb POE Injector 5

5Connecting the PSE-2 6

5.1 Wiring the RJ-45 Connectors 7

6Technical Specifications 8

Figures

Figure 1: PSE-2 Front Panel 5

Figure 2: PSE-2 Rear Panel 5

Figure 3: Connecting the PSE-2 10Gb POE Injector 6

Figure 4: TP PINOUT 7

PSE-2 – Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer PSE-2 10Gb POE Injector. This

product, which incorporates HDMI™ technology, is ideal for:

Home theater, presentation and multimedia applications

Boardrooms and classrooms

PSE-2 - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to www.kramerav.com/downloads/PSE-2 to check for up-to-date user

manuals, application programs, and to check if firmware upgrades are

available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often associated

with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighbouring electrical appliances that may adversely

influence signal quality

Position your PSE-2 away from moisture, excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics power supply that is

provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

PSE-2 – Getting Started

2.3 Shielded Twisted Pair/Unshielded Twisted Pair

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; the Kramer BC-HDKat6a (CAT 6 23 AWG) HDBaseT

certified, and the Kramer BC-DGKat7a23 (CAT 7a 23 AWG) cables. These

specially built cables significantly outperform regular CAT 6 and CAT 7a cables.

2.4 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims

to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country go

to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

PSE-2 - Overview

3 Overview

The PSE-2 is a PoE (Power-over-Ethernet) injector.

The PSE-2 provides power remotely over Ethernet to any device capable of acting

as a PoE acceptor, (for example, a wallplate where it may be difficult to connect an

external power supply). This allows a single HDBT LAN cable to provide both data

and electrical power to compatible devices.

In particular, the PSE-2 features:

A total range of up to 100m (328ft) @ 4K on shielded BC-HDKat6a cable (or

equivalent)

4K support

48V DC power

A Kramer MegaTOOLS 

®enclosure

3.1 About HDBaseT™ Technology

HDBaseT™ is an advanced, all-in-one connectivity technology (supported by the

HDBaseT Alliance). It is particularly suitable in the ProAV –and also the home –

environment as a digital networking alternative, where it enables you to replace

numerous cables and connectors by a single LAN cable used to transmit, for

example, uncompressed, full high-definition video, audio, IR, as well as various

control signals.

The products described in this user manual are HDBaseT certified.

PSE-2 – Defining the PSE-2 10Gb POE Injector

4 Defining the PSE-2 10Gb POE Injector

Figure 1 defines the front panel of the PSE-2.

Figure 1: PSE-2 Front Panel

Feature

Function

POE 1 STATUS LED

Lights green when the device provides power over the first

Ethernet connection to a remote device

POE 2 STATUS LED

Lights green when the device provides power over the

second Ethernet connection to a remote device

ON LED

Lights green when the device is powered on

Figure 2 defines the rear panel of the PSE-2.

Figure 2: PSE-2 Rear Panel

Feature

Function

LAN + POE 1 RJ-45

Connector

Connect to the first Ethernet/HDBT LAN which is to be

LAN + POE 2 RJ-45

Connector

Connect to the second Ethernet/HDBT LAN which is to be

48V DC

2-pin terminal block for connecting the +48V DC power

supply

PSE-2 - Connecting the PSE-2

5 Connecting the PSE-2

Always switch off the power to each device before connecting it to

your PSE-2. After connecting your PSE-2, connect its power and

then switch on the power to each device.

Figure 3: Connecting the PSE-2 10Gb POE Injector

To connect the PSE-2, as illustrated in the example in Figure 3:

1. Connect the HDBT transmitter, (for example, the WP-5VH2) to the LAN +

POE 2 RJ-45 connector on the rear panel of the PSE-2.
