ASPEN-32UFX Quick Start (P/N: 2900-300942QS REV 2)
P/N:
2900- 300942QS
Rev:
2
Scan for full manual
ASPEN-32UFX Quick Start Guide
This guide helps you install and use your ASPEN-32UFX for the first time.
Go to www.kramerav.com/downloads/ASPEN-32UFX to download the latest user manual and check if
firmware upgrades are available.
Step 1: Check what’s in the box
ASPEN-32UFX Programmable 32 port 12G SDI Router
1 Set of rack ears
1 Quick start guide
1 Power adapter and cord
4 Rubber feet
Step 2: Get to know your ASPEN-32UFX
#
Feature
Function
1
RS-232 (G,Rx,Tx) Terminal Block Connector
Connect to a PC or remote controller.
2
POWER 12V DC Terminal Block Connector
Dual power supply for redundancy:
PS 1 –primary power connector
PS 2 –redundant power connector (optional).
Connect each power adapter into a separate branch circuit employing a
separate service ground.
3
RESET Button
Press briefly to restart the system.
Press for 5 seconds to reset IP settings to factory default values.
The device powers up and loads the factory default values:
IP address: 192.168.1.39; Mask: 255.255.255.0; Gateway 192.168.1.1.
4
ETHERNET RJ-45 Connector
Connect to a PC via LAN and also used for firmware upgrade.
5
LOOP BNC Connector
Connect to the GENLOCK connector of the next unit in the daisy chain or
terminate with 75Ω.
6
GENLOCK BNC Connector
Connect to the GENLOCK source.
7
PORTS BNC Connectors (32)
Connect to sources and acceptors.
Step 3: Install ASPEN-32UFX
Install ASPEN-32UFX using one of the following methods:
•Remove the three screws from each side of the unit, reinsert those screws through the
rack ears and mount on a 19" rack.
•Attach the rubber feet and place the unit on a flat surface.
Step 4: Connect the inputs and outputs
Each ASPEN-32UFX port can be defined as an input or an output, enabling flexible configurations such as 1x31distribution
amplifiers, 31x1 routers or any other possible input-output combination. By default, the ASPEN-32UFX is set to operate as a 16x16
router: PORT 1 to PORT 16 as the inputs, and PORT 17 to PORT 32 as the outputs.
Always switch OFF the power on each device before connecting it to your ASPEN-32UFX.
Optionally, daisy-chain the ASPEN-32UFX by looping the genlock source to the next machine.
RJ-45 Pinout:
PIN EIA /TIA 568B
PIN
Wire Color
1
Orange / White
2
Orange
3
Green / White
4
Blue
5
Blue / White
6
Green
7
Brown / White
8
Brown
Step 5: Connect the power
Connect the 12V DC power supply to ASPEN-32UFX and plug it into the mains electricity. You can add a second power supply (not
supplied in the package) for backup.
Safety Instructions
Caution:
There are no operator serviceable parts inside the unit.
Warning:
Use only the Kramer Electronics power supply that is provided with the unit.
Warning:
Disconnect the power and unplug the unit from the wall before installing.
See www.KramerAV.com for updated safety information.
Step 6: Control ASPEN-32UFX
Web Pages:
RS-232 and Ethernet:
RS-232
Protocol 3000
Baud Rate:
115,200
Stop Bits:
1
Data Bits:
8
Parity:
None
Command format example (define
port 1 as an input port):
#PORT-DIRECTION 1,IN
~01@PORT-DIRECTION 1,IN
TCP/IP Parameters
IP Address:
192.168.1.39
UDP Port #:
50000
Subnet mask:
255.255.0.000
Maximum UDP Connections:
20
Default gateway:
192.168.0.1
TCP Port #:
5000
Maximum TCP Connections:
Unlimited
Full Factory Reset
Web Page:
Device Settings Web page.
Protocol 3000:
Use “Factory” command: #FACTORY<CR>
Rear panel
RESET button:
Press RESET for 5 seconds while the machine is on. The device
automatically resets and powers up again, loading factory default
values.
Authentication
User:
Admin
Password:
Admin
Configure the ports via the Video Switching Web page:
•Define each port as an input or output by clicking a port number.
•Toggle Mute (M) on each output.
•Click a white button in the matrix to switch an input to an output.
= current input to output routing state
= optional input to output routing
Technical Specifications
Ports
32 12G HD-SDI/HD-SDI/SDI
Video
75Ω on BNC connectors (by default, 1 to 16 are set as inputs and
17 to 32 are set as outputs)
1 Genlock
75Ω on a BNC connector
1 Genlock Loop
Passive loop output on a BNC connector
SMPTE Standards
12G-SDI
SMPTE ST-2082-1
3G HD-SDI
SMPTE 424M
HD-SDI
SMPTE 292M
SDI
SMPTE 259M/344M
Video
Max Resolution
4K@60Hz (4:2:2)
Max Bandwidth
12Gbps
Controls
Remote
RS-232
Ethernet
Web pages
Reach
SD Signals
Up to 300m
HD Signals
For 1.5GHz, up to 200m
For 3GHz, up to 100m
For 6GHz, up to 100m
UHD Signals
For 12GHz, up to 80m
Coupling
DC
Power
Consumption
12V DC, 2A
Source
12V DC, 5A
Environmental
Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory
Compliance
Safety
CE
Environmental
RoHs, WEEE
Enclosure
Size
19”, 1U
Type
Aluminum
Cooling
Fan ventilation
General
Net Dimensions (W, D, H)
43.64cm x 10cm x 4.36cm (17.18" x 4" x 1.72")
Shipping Dimensions (W, D, H)
55cm x 27.6cm x 10.7cm (21.7" x 10.87" x 4.21")
Net Weight
1kg (2.2lbs)
Shipping Weight
1.9kg (4.2lbs) approx.
Accessories
Included
Power cord
Specifications are subject to change without notice at www.kramerav.com
