KRAFTWERK 32020 User manual
www.KRAFTWERKtools.com
Rechargable lamp
CREE 2 W + COB LED 2 W
3.6 V
2200 mAh
Li-ion
Art. 32020
0 0C - 45 0C
EN
Instruction Manual
3.5-4 h
IP67
3-4 h
180-210 Lumen
COB 2W
3-4.5 h
120-150 Lumen
CREE 2W
lamp.
BASIC PARAMETERS
1. APPLICATION
1.1 Included are 2 Li-ion batteries. The lamp has 2 lightning functions: Torch-light with CREE-Power LED
and wide-angle COB LED on the side.
1.2 Operation with 2 press switches
Switch 1: Press to switch on the top CREE LED. Press again to switch off.
Switch 2: Press to switch on the side COB LED. Press again to switch off.
Switch 1 and switch 2 are independent of each other and can be used together.
1.3 Working time
Top CREE LED: 3 - 4.5 h
Side COB LED: 3 - 4 h
CREE + COB LED together: 1.5 - 2 h
2
Battery Built-In 3.6 V 2200 mAh Li-ion rechargeable battery
Charge-Discharge Cycles >800
Ingress Protection Grade IP67
Full Charging Time 3.5-4 h
Working Time (CREE LED 2W) 3-4.5 h
Working Time (COB LED 2W) 3-4 h
LED Lifetime 100,000 hrs
LED Light Intensity (CREE LED 2W) 120-150 Lm
LED Light Intensity (COB LED 2W) 180-210 Lm
Luminous flux (from 1 m) 350-380 Lux
LED Color Temperature 6500 K (Cool white)
Battery Storage Time (Unload) 2 Years
Charging Temperature -5°C - 45°C
Discharging Temperature -20°C - 50°C
Storage Temperature -20°C - 80°C
Transformer DC 5.5 V / 1000 mA
Net Weight 0.26 kg
Dimensions ( Ø x L ) 37 mm x 295 mm
Switch 2: control the side COB LED
Switch 1: control the top CREE LED
WARRANTY
We do not take responsibility for any damage caused by misuse or any use that is not in compliance with
the safety standards described herein.
CUSTOMER SERVICES
Contact your local importer of your specialized dealer to obtain address of our service department.
You find our partners under www.KRAFTWERKtools.com
From date of purchase receipt
2 YEARS GUARANTEE
on material- or production-defects
3
2. CHARGER
2.1 Structure
indicator light port 1 port 2
The charger can charge 2 pieces of 18650 Li-ion batteries together. The indicator light shows the
charging condition.
3. FUNCTIONS
3.1 Each port has an indicator light
3 indicator LED lights are permanently on: battery is fully charged.
2 indicator LED lights are permanently on: battery is still 60% charged.
1 indicator LED light is permanently on: battery is only 30% charged.
3.2 2 independently working charging ports for separate and/or common charging.
3.3 Charging time:
NOTE: Before disposing of damaged goods, check with your state Environmental Protection
Agency to find out about special restrictions on the disposal of the lamp and batteries or return
them to a certified service center for recycling.
Battery Quantity Charging time
1 piece 3.5-4 hours
2 pieces 8 hours
KRAFTWERK Europe AG
Mettlenbachstrasse 23
CH-8617 Mönchaltorf/Switzerland
Tel. +41-44 949 40 50
KRAFTWERK Sàrl.
25, rue du Stade
F – 67870 Bischoffsheim
Tel. +33-388 46 64 50
www.KRAFTWERKtools.com
