Kohler VOLT VK4X1E User manual
Owners Manual
MODEL-VK4X1E
OPEROR'S MANUAL
4 In 1
We want to thank you for your purchase of our state of
the Multi-Functional 4 in 1 Machinery. This manual will
tell you how to use and maintain. Please read the
manual carefully before operating the machine.
Operating the machine in the best conditions will
increase the lifetime of the unit.
If you have any suggestions for the manual please
contact your local dealer. We as a company are
striving to make constant upgrades to our equipment to
provide our customer base with the best units possible.
The specifications for each unit may vary from machine
to machine.
Catalogue
1.Safety…………………………………………..1
2.Specifications…………………………………4
3.Component Identification…………………...5
4.Preparation……………………………….…..9
5.Starting……………………………………….12
6.Operation…………………………………....13
7.Engine Shut down…........………………….14
8.Maintenance…………………………………15
9.Common Faults and troubleshooting…....23
10.Schematic Diagram………………………26
1．Safety Instruction
Please read the manual before operation, failure to comply
with the manual could lead to danger of operator, others and
the machine.
1.1.Protect yourself and others. Welding can make you and
others in danger of many risk factors: Make sure to never weld
without a welding mask. This goes for not only the operator, but
all other bystanders as well. The damages to eyes include:
electric arc, dazzle reflections, dazzle flicker, sparking molten,
metal splashing. Looking at welding arc without eye protection
can inflict great pain and even temporary blindness. Therefore,
this products
owner/operator should ensure the welding machine
operated by a user with prior welding knowledge. Use these
professional protective equipment when operating.
-Face shield
-dedicated heat resistant gloves
-Protective clothing and shoes
1.2. Do not use machine in area where dust pollution,
flammables or explosives are present.
1.3 Power supply and welding current can cause shock
damage. Please do not touch inside or face plate of welding
machine at any time. Make sure operator and all other have
protection. Do not let your body touch the ground and the
electrode at that same time.
1.4 Welding fumes and gasses can cause serious harm to
operator and all other by standards. Please keep your head
away from a place you could possibly breathe in fumes and
make sure to use the machine in a well ventilated area.
1.5 To prevent any fire hazards do not have any residue of
gasoline or kerosene on your person, cylinder or piping you
may be welding.
1.6 Do not operate machinery if you have a pacemaker. This
includes being anywhere near the machine even if someone
else is operating. The magnetic field produced by the
welding machine could have adverse effects on a
pacemaker.
1.7 Welding splatter can cause fire and explosions. Do not
weld in dangerous situations such as around flammables,
explosives, a closed barrel or pipe.
1.8 There is extreme heat produced by the exhaust pipe,
engine, air compressor and muffler. Please do not touch
these parts or have flammables anywhere near the unit. The
high temperature produced by the exhaust is capable of
igniting any flammables or explosives.
1.9. It is important that this unit is installed, used and
maintained by professionals. Do not tamper or remove any
safety or warning signs located on the unit.
1.10. The engine operates on gasoline. It is important to
keep in mind this unit cannot be run indoors. Carbon
Monoxide has no odor and can be fatal in a short period of
time.
1.11. Gasoline is highly flammable and is capable of causing
a large explosion. Please shut down the machine before
ever adding fuel or oil. When adding fuel or oil make sure it
is done in a well ventilated area. When filling the fuel tank be
sure you always leave enough space for natural fuel
inflation. Make sure to not smoke near fuel supply. Keep
away from all other flames, sparks, etc. Make sure to wipe
all leaked fuel on the unit before starting.
1.12 Take care when attaching your welding leads. Ensure
a solid connection at the lead terminals at all times. Inspect
your welding leads for damage before each use and never
allow them to sit in a damp environment. Avoid dragging
your welding leads, as this may cause the insulation to
become damaged.
1.13 Check the oil level prior to each use by removing the oil
dipstick. Do not operate the unit if it has become overfilled
with oil, as this can affect normal operations. In addition
make sure to change the oil on a regular basis.
1.14 Refrain from using the air compressor when welding.
Also, it is recommended that you disconnect all sources
from the generator as well when welding.
Lighting
Engine
Working voltage(V)
Lamp power(W)
Solenoid valve
Lifting gear pressure(MPa)
Lift height(mm)
AC120V/240V ±5%
LED/4×100W
2pcs/DC12V/5W
0.8 ±0.1
1800-4500
50A-200A
Welding
AC120/240V, 60Hz
2.Specifications
168KG
3.
Note: Do not attempt to modify the control panel in any
way. This will void your warranty and could present the
potential for equipment failure and personal injury.
Component Identification
1．Main Switch
2．Air compressor switch
3．Display meter
4．Oil alarm
5．key switch
6．Welding adjustor
7. Socket for welding
8．lighting control switch
9．Push botton for lighting
10．Socket
11．Groud bolt
1. Engine Cover Plate 2. Fuel Tank 3. Fuel Petcock
4. Engine Pull-Start Assembly 5. Engine Choke Lever
6. Air Filter Assembly 7. Handle 8. Water Drain Valve
9. Muffler Assembly 10. Frame
1. Air Compressor Oil Drain Plug 2. Oil Sight Glass
3. AVR Cover Plate 4. Control Panel Case
5. Exhaust Port 6. Oil Fill Port
7. Air Compressor Cylinder Head 8. Air Filter
9. Air Supply Hose 10. Cover Plate
1. Engine Oil Drain Plug 2. Oil Fill Dipstick
3. Air Pressure Relay 4. A/C Switch
5. Safety Valve
1. Pressure Gauge 2. Air Pressure Regulator
3. Air Outlet Connectors 4. Pressure Gauge
5. Air Tank 6. Air Hose
7. Air Valve 8. Wheel Axle
9. Wheel
