Kogan V10 User manual

STAIN CLEAN WINDOW

VACUUM CLEANER V10

KAVACWIN10A

Warning Symbols

The following warnings are used in this user guide and on the packaging.

Do not use bleach

Do not tumble dry

Do not dry clean

Washable at 60°C

Do not iron

IPX4

Protected against splashing water from

all directions.

General Safety Instructions

•Before using the product, familiarise yourself with all the safety information and

instructions. Retain this user guide for future reference.

•Risk of loss of life or accident to infants and children. Never leave children unsupervised

with the packaging material.

•The packaging material represents a danger of suffocation. Children frequently

underestimate the dangers. Always keep children away from the packaging material.

•This product can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use of the product in a safe

way and understand the hazards involved. The product shall not be left unattended

while it is connected to the supply mains. Keep the product out of reach of children

when it is energised.

•Children shall not play with the product.

•Cleaning and maintenance shall not be made by children without supervision.

•Warning! Misuse may lead to injury. Use this product solely in accordance with these

instructions. Do not attempt to modify the product in any way.

•Attention! Risk of product damage! Do not expose the product to direct sunshine or

heat. The ideal ambient temperature is between +5 and +35 °C. Extreme low or high

temperature may damage the battery or the product.

SAFETY & WARNINGS

Electrical Safety

•Danger! Risk of electric shock! Never attempt to repair the product yourself. In case of

malfunction, cease use immediately and contact help.Kogan.com for support.

•Warning! Risk of electric shock! Do not immerse the product in water or other liquids.

Never hold the product under running water.

•Warning! Never use a damaged product. Disconnect the product from the power,

cease use immediately and contact help.Kogan.com for support.

•Warning! Risk of injury! Switch the product off and disconnect it from the power supply

before cleaning work and when not in use.

•Warning! This product contains a Lithium-long rechargeable battery that is only

replaceable by skilled persons. Do not throw the product into a fire.

•Do not operate the product while it is being charged.

•Always charge the product in an open area away from flammable materials and

liquids. Misuse can cause fire and burns.

•The product is not to be used if it has been dropped if there are visible signs of damage

or if it is leaking.

•Protect the connection cord against damages. Do not let it hang over sharp edges, do

not squeeze or bend it. Keep the connection cord away from hot surfaces and open

flames. Ensure that nobody can pull on or trip over it unintentionally.

OVERVIEW

Release button

Power button

Dirty water

container

Charging socket (with cover)

Vacuum attachment

Suction head

Eject button

Main unit

Spray nozzle

Wiper

Spray bottle

USB-A to USB-C cable

Cleaning pads (x2)

1. Place the vacuum attachment onto the suction head.

2. Prior to attaching the wiper, fill the water container with water and/or cleaning

detergent. Do not exceed the water container's maximum capacity of 360 ml.

Note: Do not use abrasive or aggressive cleaning detergents. These could damage

the product.

3. Screw the wiper onto the water container.

4. Unfasten the hook-and-loop strap on the side of the cleaning pad.

5. Attach a cleaning pad onto the wiper.

6. Fasten the hook-and-loop strap of the cleaning pad.

•Remove all packaging materials. Check if all parts are complete.

•The product's built-in battery is not charged on delivery. Charge the battery completely

before first use.

Charging

1. Always ensure the product is turned off before

charging.

2. Connect the USB cable to the product.

3. Connect the USB cable to a DC 5V (6W max)

USB power adapter (not supplied). The power

button indicator will turn red.

4. When the battery is fully charged, the power

button indicator will turn blue.

5. Disconnect the USB cable.

Notes:

•Do not leave the product permanently connected to the power adapter to avoid

damage to the battery or the product.

•Ensure the charging socket always closed during operation to avoid water ingress.

•Do not obstruct the ventilation slots during operation. Blocked ventilation can result in

overheating and damage to the product.

ASSEMBLY

BEFORE FIRST USE

Power button

Indicator

Status

Solid Blue

Power on. Fully charged (while charging)

Solid Red

Charging

Red flashing (slow)

Low power.

Red flashing (fast)

Battery empty. The product will turn off after 1 minute.

Cleaning Windows

1. Rotate the spray nozzle to the desired setting:

oStream Jet stream

oSpray Water mist stream

oOff No stream

2. Spray the window.

3. Wipe over the sprayed areas with the wiper. This will loosen stubborn dirt.

Turning the product on/off

1. Press the power button, the product will turn on and the indicator turns blue.

2. Press the power button again, to turns the product off. The indicator will turn off.

Vacuuming Windows

1. Turn on the product.

2. Move the blade of the vacuum attachment slowly from top to bottom.

Note: For best cleaning results, briefly dry the rubber wiper of the vacuum attachment

with a clean cloth after each removal.

3. When the MAX marking on the dirty water container is reached, turn off the

product.

4. Remove the dirty water container from the main unit. Remove the protective cap

and empty the dirty water.

5. Replace the dirty water container before resuming operation.

Note: Do not hold the product upside down. Do not move the product sideways.

OPERATION

•Before cleaning, always disconnect the product from the USB cable.

•Warning: Do not immerse the product's electrical components in water or other liquids.

Never hold the product under running water.

•Do not use any abrasive, aggressive cleaners or hard brushes to clean the product and

its accessories.

Cleaning and Storage

•Protect the product against dust and direct sunlight.

•Store the production in a cool, dry place, protected from moisture and out of the reach

of children.

•Product the product against heat. Do not place the product close to open flames or

heat sources such as stoves or heating appliances.

Cleaning the Vacuum Attachment, Suction Head and Main Unit

1. Press the release button to remove the vacuum attachment from the suction

head.

2. Press the eject buttons to remove the suction head from the main unit.

3. Wipe down the parts with a slightly damp cloth.

4. Do not let any water or other liquids enter the product interior.

5. After cleaning, allow all parts to dry completely before reassembling.

Cleaning the Water container, DirtWater Container and Wiper

1. Rinse the parts in water and/or mild detergent.

2. After cleaning, allow all parts to dry completely before reassembling.

CLEANING & CARE

Washing the Cleaning Pads

The cleaning pads can be cleaned in a washing machine.

Do not use bleach

Do not dry clean

Do not iron

Do not tumble dry

Washable at 60°C

1. Clean the cleaning pads on a mild setting, up to 60°C.

2. After cleaning, allow to dry completely before reassembling.

Storage

•Before storing the product ensure the water container and dirty water containers are

empty.

•Regularly charge the battery (for example: monthly) if you do not use the product for a

long period of time. This is necessary to preserve the battery.
