Kodak KE85 Zoom User manual
Consumer Imaging
EASTMAN KODAK COMPANY
Rochester, NY 14650
KE85 Zoom
© Eastman Kodak Company, 2002
Pt. No. 20207742
This device complies with part 15 of the FCC Rules. Operation is subject to the
follow-ing two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interfer-
ence that may cause undesired operation.
NOTE: Your model camera has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits provide
reasonable protection against interference in residential use. The camera generates,
uses and can radiate radio frequency energy and, if not used in accordance with the
instructions, may cause interference to radio communications. There is no guarantee
that interference will not occur. If this camera does cause interference to radio or
television reception, which can be determined by turning the camera off and on, you
may reduce the interference by the following:
— Reorient or relocate the receiving antenna.
— Increase the separation between the camera and the receiver.
— Consult the dealer or an experienced radio/television technician for help.
Changesormodificationsnotapprovedbythepartyresponsibleforcompliancecould
void the user’s authority to operate the equipment.
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
View front and back cover flaps to see camera diagrams.
ENGLISH/ESPAÑOL/FRANÇAIS
35 mm Camera
Kodak
CAMERA IDENTIFICATION LCD PANEL
1
23
45
6
7
8
910
11
12
13
14
15
16
17
18
19
20
21
24
25
26 27
22
23
28
29 30
31
32
33
34
35
36
AUTO
1
NEED HELP WITH YOUR CAMERA?
Visit our Web sites at http://www.kodak.com (for US) or
http://www.kodak.ca (for Canada) or call:
Kodak (USA only) from 9:00 a.m. to 7:00 p.m. (Eastern time) Monday
through Friday at 1-800-242-2424.
Kodak (Canada only) from 8:00 a.m. to 5:00 p.m. (Eastern time) Monday
through Friday at 1-800-465-6325, ext. 36100; for the Toronto area,
call 416-766-8233, ext. 36100.
When you call, please have your camera available.
For warranty purposes, please keep your sales receipt as proof
of the date of purchase.
ENGLISH
ENGLISH
Kodak KE85 Zoom
35 mm Camera
2
CONTENTS
CAMERA IDENTIFICATION ............... 3
ATTACHING THE STRAP ................. 4
LOADING THE BATTERY................. 5
Low-batteryindicator .................... 6
Auto power off .............................. 6
Battery tips................................... 7
ATTACHING THE LCD LABEL.......... 8
LOADING THE FILM ......................... 8
TAKING PICTURES ..........................11
Using the focus lock .................... 12
Tips for better pictures ................ 13
USING THE ZOOM LENS................ 14
TAKING FLASH PICTURES ............ 15
Flash-to-subject distance ............ 16
FLASH MODES ............................... 17
Auto flash.................................... 18
Fill flash ...................................... 18
Flash off ...................................... 18
Selecting the flash modes ........... 18
Nightview with or without flash .... 19
USING THE SELF-TIMER ............... 20
MODE BUTTON............................... 21
Red-eye reduction ...................... 22
Portrait mode .............................. 22
UNLOADING THE FILM ................... 24
Automatic rewind ........................ 24
Manualrewind ............................ 24
CARING FOR YOUR CAMERA ....... 25
TROUBLESHOOTING ..................... 26
SPECIFICATIONS ........................... 28
3
CAMERAIDENTIFICATION
Unfold the front and back flaps of
manual to view camera diagrams
1Shutter button
2Auto-focus windows
3Self-timer bulb/
red-eye-reduction bulb
4Light sensor
5Flash
6Viewfinder
7Lens/lens cover
8Strap post
9Film-door latch
10 Flash-ready/camera-warning light
11 Viewfinder eyepiece
12 Zoom dial
13 Film-door-lock indicator
14 LCD panel
15 Self-timer button
16 Mode button
17 Tripod socket
18 Exposure button
19 On/off button
20 Film-rewind button
21 Battery door
22 Film-guide rails
23 DX/DXN code sensors
24 Film chamber
25 Film door
26 Film window
4
ATTACHING
THE STRAP
1. Insert one end
of the strap
under the
strap post (8)
and pull
it through.
2. Thread the
longer end
of the strap
through the
shorter loop.
3. Pull the strap
strap tight.
LCD panel
27 Frame counter
28 Nightview symbol
29 Fill-flash/flash symbol
30 Flash-off symbol
31 Portrait symbol
32 Battery symbol
33 Self-timer symbol
34 Red-eye-reduction indicator
35 Auto-flash indicator
36 Film-motion indicator
5
LOADING THE BATTERY
This camera uses one 3 volt lithium
KODAK KCR2 (or equivalent) Battery
that supplies power for all camera
operations.
1. Slide the battery door (21) and lift
to open.
•Before you remove the old
battery, turn off the camera.
2. Insert the battery into the
battery chamber.
3. Snap the battery door closed.
6
Low-battery indicator
It is time to replace the battery when —
•the battery symbol (32) appears on
the LCD panel (14), or
•none of the indicators appear on
the
LCD
panel and the shutter
button (1) cannot be operated.
Auto power off
This camera automatically turns off
after approximately 4 minutes to
conserve the battery life. To awaken
the camera, press the on/off
button (19).
•Turn the camera off when the
camera is not going to be used for
an extended length of time.
7
•Remove the battery from the
camera when the camera is not
going to be used for an extended
length of time.
•In the unlikely event that battery
fluid leaks onto your skin, contact
Kodak Health, Safety and
Environment Information at
1-716-722-5151 in the U.S.
•In the unlikely event that battery
fluid leaks inside the camera, U.S.
customers can contact the Kodak
Information Center (KIC) at 1-800-
242-2424. Customers outside the
U.S. can contact their local Kodak
Customer Service representative.
Battery tips
•Dispose of the battery according to
local and national regulations.
•Keep a spare battery with you at all
times.
•Read and follow all warnings
and instructions supplied by the
battery manufacturer.
•Keep batteries away from children.
•Do not try to take apart, recharge
or short circuit the battery, or
subject it to high temperature
or fire.
•Store batteries in their original
packaging prior to use.
8
LOADING THE FILM
If in sunlight, turn your back to the
sun and load the film in the shade of
your body. The unique easy load
feature of this camera makes film
loading simple.
1. Slide the film-door latch (9)
in the direction of the arrow to open
the film door (25).
ATTACHING THE
LCD LABEL
English text references for the LCD
control buttons are printed below the
LCD panel (14). You can replace the
English text with Chinese,
Arabic, Thai, Polish,
French, Spanish,
Portuguese, or Russian
with one of the
eight supplied
labels. Simply
remove the peel-off
label of your choice and place it over
the English text. The label is
removable if you want to reposition it
or replace it with a different one.
OPEN
RETAR-
DATEUR
POINT
MISE AU
POSE
BINAGE
REMBO-
Exposure
Mode
Timer
Rewind
