Kodak KE30 - 35 Mm Camera User manual
KodakKE30
ENGLISH/ESPAÑOL/FRANÇAIS
35 mm Camera
CameraIdentification
1
2
345
6
7
8
9
10
12 11
13 14 15 16
17
18
19
20
21
22
23
24
1
ENGLISH
ENGLISH
NEED HELP WITH YOUR CAMERA?
Visit our Web sites at http://www.kodak.com (for US) or
http://www.kodak.ca (for Canada) or call:
Kodak (USA only) from 9:00 a.m. to 7:00 p.m. (Eastern time) Monday
through Friday at 1-800-242-2424.
Kodak (Canada only) from 8:00 a.m. to 5:00 p.m. (Eastern time) Monday
through Friday at 1-800-465-6325, ext. 36100; for the Toronto area,
call 416-766-8233, ext. 36100.
When you call, please have your camera available.
For warranty purposes, please keep your sales receipt as proof
of the date of purchase.
Kodak KE30 35 mm Camera
2
CONTENTS
CAMERA IDENTIFICATION.............. 3
ATTACHING THE STRAP ................. 4
LOADING THE BATTERIES ............. 4
Low-batteries warning.................. 5
Auto power off ............................. 5
Battery tips .................................. 6
LOADING THE FILM ......................... 7
TAKING PICTURES .......................... 10
Tips for better pictures ................. 11
TAKING FLASH PICTURES ............. 12
Flash-to-subject distance ............. 12
Using fill flash and flash off .......... 14
Using red-eye reduction............... 15
SELF-TIMER ..................................... 15
UNLOADING THE FILM .................... 17
Using mid-roll rewind ................... 17
CARING FOR YOUR CAMERA ........ 18
TROUBLESHOOTING ...................... 19
SPECIFICATIONS ............................ 21
3
CAMERAIDENTIFICATION
1SHUTTER BUTTON
2PICTURE COUNTER
3VIEWFINDER
4VIEWFINDER LIGHT DIFFUSER
5FLASH
6SELF-TIMER BULB /
RED-EYE-REDUCTION BULB
7LIGHT SENSOR
8FLASH-OFF BUTTON
9FILL-FLASH BUTTON
10 LENS
11 LENS-COVER SWITCH
12 STRAP POST
13 FILM-DOOR LATCH
14 VIEWFINDER EYEPIECE
15 FLASH-READY LIGHT
16 SELF-TIMER SWITCH
17 FILM-DOOR-LOCK INDICATOR
18 TRIPOD SOCKET
19 FILM-REWIND SWITCH
20 BATTERY DOOR
21 FILM-GUIDE RAILS
22 FILM CHAMBER
23 FILM DOOR
24 FILM WINDOW
Unfold cover flaps of manual
to view camera diagrams.
4
ATTACHING THE STRAP
1. Insert one end of the
strap under the
STRAP
POST
(12) and pull
it through.
2. Thread the longer
end of the strap
through the
shorter loop.
3. Pull the strap tight.
LOADING THE BATTERIES
This camera uses 2 AAA-size alkaline
1.5 V KODAK K3A (or equivalent)
Batteries.
1. Open the
BATTERY
DOOR
(20).
•Before you remove the old
batteries, turn off
the camera
by sliding the
LENS
-
COVER
SWITCH
(11) to
the off position.
5
2. Insert the
batteries into
the chamber
as shown.
3. Snap the
battery door
closed.
Low-batteries warning
It is time to replace the
batteries when —
•the
FLASH
-
READY
LIGHT
(15) takes
longer than 30 seconds to turn on.
•the camera motor slows down or
will not run.
•the film will not advance.
6
Auto power off
This camera automatically turns off
after approximately 4 minutes to
conserve the life of the batteries. To
awaken the camera, close and open
the
LENS
COVER
(11) .
• Close the lens cover when the
camera is not used for an
extended time.
Battery tips
•Dispose of batteries according to
local and national regulations.
•Keep spare batteries with you
at all times.
•Read and follow all warnings and
instructions supplied by
the battery manufacturer.
•Keep batteries away
from children.
•Do not try to take apart, recharge
or short circuit the batteries, or
subject them to high temperature
or fire.
7
LOADING THE FILM
If in sunlight, turn your back to the
sun and load the film in the shade of
your body. The unique easy load
feature of this camera makes
film loading simple.
1. Slide the
FILM
-
DOOR
LATCH
(13)
in the direction
of the arrow
to open the
FILM
DOOR
(23).
•You can load
film into the
camera with
the lens cover
opened or closed.
•Store batteries in their original
packaging prior to use.
•Remove batteries from the camera
when the camera is not going to
beusedforanextendedlengthoftime.
•In the unlikely event that battery
fluid leaks onto your skin, contact
Kodak Health, Safety and
Environment Information at
1-716-722-5151 in the U.S.
•In the unlikely event that battery
fluid leaks inside the camera, U.S.
customers can contact the Kodak
Information Center (KIC) at 1-800-
242-2424. Customers outside the
U.S. can contact their local Kodak
Customer Service representative.
OPEN
