Kitronik MI:pro 56103 User manual
V1.0
WE’VE GOT YOU COVERED WITH THE
Mountable case for the
New BBC micro:bit
BUILD INSTRUCTIONS
2
1
Stack each layer as shown onto the screws,
then tighten the nuts. The micro:bit will sit,
display towards the front panel, between the
dividers in the middle.
Push Large Screws through
part number 1 and lay flat
with text facing down.
Please place your
micro:bit in here
1
MOUNTING INSTRUCTIONS
Hook over your
mounting screws.
2Push case down
to lock in place on
mounting screws.
*mounting screws not included
For more information on RoHS and CE please visit kitronik.co.uk/rohs-ce. Children
assembling this product should be supervised by a competent adult. The product
contains small parts so should be kept out of reach of children under 3 years old.
TOOLS REQUIRED: STOCK CODE
56103
• Flat Head Screwdriver
CONTENTS
Designed & manufactured
in the UK by
T: +44 (0) 115 970 4243
W: www.kitronik.co.uk
kitronik.co.uk/twitter
kitronik.co.uk/facebook
kitronik.co.uk/youtube
kitronik.co.uk/instagram
For more information on RoHs and CE please visit kitronik.co.uk/rohs-ce. Children
assembling this product should be supervised by a competent adult. The product
contains small parts so should be kept out of reach of children under 3 years old.
WARNING: Contents may inspire creativity
x4
x4
Other Kitronik Enclosure manuals
