ENGLISH

| 5

STAND MIXER ATTACHMENT INSTRUCTIONS

TABLE OF CONTENTS

PARTS AND FEATURES��6

Parts and accessories��6

STAND MIXER ATTACHMENT SAFETY��7

Important safeguards ��7

Waste disposal��8

USING THE STAND MIXER ATTACHMENT��9

Assembling the Citrus Juicer attachment ��9

USING THE STAND MIXER ATTACHMENT��10

Attaching the Citrus Juicer to the Stand Mixer��10

Using the Citrus Juicer attachment ��11

CARE AND CLEANING��11

WARRANTY AND SERVICE ��12

W10863936A_01_EN_v11.indd 5 8/17/17 10:19 AM

6 | PARTS AND FEATURES

PARTS AND FEATURES

PARTS AND ACCESSORIES

Reamer

Citrus juicer

housing

Metal drive

shaft

Strainer

W10863936A_01_EN_v11.indd 6 8/17/17 10:19 AM

ENGLISH

STAND MIXER ATTACHMENT SAFETY | 7

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety

precautions should always be followed, including

the following:

1. Read all instructions. Misuse of appliance may result in

personal injury.

2. This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

3. This appliance can be used by children aged 8 years

and above and persons with reduced physical,

sensory, or mental capabilities, or lack of experience

and knowledge if they have been given supervision or

instructions concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision.

STAND MIXER ATTACHMENT SAFETY

W10863936A_01_EN_v11.indd 7 8/17/17 10:19 AM

8 | STAND MIXER ATTACHMENT SAFETY

STAND MIXER ATTACHMENT SAFETY

Disposal of packing material

The packing material is 100% recyclable

and is marked with the recycle symbol

� The various parts of the packing

must therefore be disposed of

responsibly and in full compliance

with local authority regulations

governing waste disposal�

WASTE DISPOSAL

SAVE THESE INSTRUCTIONS

4. Children should be supervised to ensure that they do

not play with the appliance.

5. Never leave the appliance unattended while it is in

operation.

6. Turn the appliance off, unplug from outlet, and detach

the attachment from appliance before cleaning and

when not in use. Turn the appliance off and make sure

the motor stops completely before putting on or taking

off parts.

7. The use of attachments not recommended or sold by

KitchenAid may cause re, electrical shock, or injury.

8. Do not use the appliance outdoors.

9. Avoid contacting moving parts.

10. Also see the Important Safeguards section included in

the Stand Mixer “Instructions” Manual.

11. This appliance is intended to be used in household and

similar applications such as:

- staff kitchen areas in shops, ofces or other

working environments;

- farm houses;

- by clients in hotels, motels and other residential

type environments;

- bed and breakfast type environments.

W10863936A_01_EN_v11.indd 8 8/17/17 10:19 AM

ENGLISH

USING THE STAND MIXER ATTACHMENT | 9

USING THE STAND MIXER ATTACHMENT

ASSEMBLING THE CITRUS JUICER ATTACHMENT

1Insert the round end of the metal

drive shaft into the reamer so that

the pins fit into the slots� 2Next, insert the square end of the

metal drive shaft through the hole in

the Citrus Juicer housing�

3Slide the strainer into the grooves

in the Citrus Juicer housing�

W10863936A_01_EN_v11.indd 9 8/17/17 10:19 AM

10 | USING THE STAND MIXER ATTACHMENT

1Turn Stand Mixer off and unplug�

Insert attachment shaft housing into

the attachment hub, making certain

the power shaft fits into the square

hub socket� If necessary, rotate the

attachment back and forth� The pin

on the attachment housing fits into

the notch of the hub rim when in

the proper position�

Tighten the Stand Mixer attachment

hub knob until the attachment

is completely secured to the

Stand Mixer�

2For Stand Mixers with a hinged attachment hub cover: Flip up to open�

For Stand Mixers with a removable attachment hub cover: Turn the attachment

knob counterclockwise to remove attachment hub cover�

USING THE STAND MIXER ATTACHMENT

ATTACHING THE CITRUS JUICER TO THE STAND MIXER

W10863936A_01_EN_v11.indd 10 8/17/17 10:19 AM

ENGLISH

CARE AND CLEANING | 11

USING THE STAND MIXER ATTACHMENT

USING THE CITRUS JUICER ATTACHMENT

NOTE: The Citrus Juicer attachment is designed to juice only lemons, limes, oranges,

and grapefruit�

1Place a glass or a pitcher under the

Citrus Juicer attachment� 2

Turn the Stand Mixer to Speed 6�

Firmly hold fruit, against the spinning

reamer� Move the fruit in all

directions to extract the juice�

CARE AND CLEANING

1Wash the Citrus Juicer attachment

in warm sudsy water� 2

All plastic parts are dishwasher safe,

top rack only� To avoid damage to the

metal drive shaft, do not wash in the

dishwasher�

CLEANING THE CITRUS JUICER ATTACHMENT

NOTE: Clean pulp from the strainer

as needed while juicing�

W10863936A_01_EN_v11.indd 11 8/17/17 10:19 AM

12 | WARRANTY AND SERVICE

WARRANTY AND SERVICE

CUSTOMER SERVICE

KITCHENAID STAND MIXER ATTACHMENT WARRANTY

KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR INDIRECT

DAMAGES.

Length of Warranty: KitchenAid Will Pay For: KitchenAid Will Not Pay For:

Europe, Middle East

and Africa:

5JE

Two years full

warranty from

date of purchase.

The replacement parts

and repair labour

costs to correct

defects in materials or

workmanship. Service

must be provided by an

Authorised KitchenAid

Service Centre.

A. Repairs when Stand Mixer

attachment is used for

operations other than normal

household food preparation.

B. Damage resulting from

accident, alterations,

misuse, abuse, or installation/

operation not in accordance

with local electrical codes.

the U�S� and elsewhere�

In U.K. and Ireland:

For any questions, or to find the nearest Authorised KitchenAid Service Centre,

please find our contact details below�

NOTE: All service should be handled locally by an Authorised KitchenAid

Service Centre�

Contact number for U�K� and Northern Ireland:

Tollfree number 0800 988 1266 (calls from mobile phones are charged standard

network rate) or call 0194 260 5504

Contact number for Ireland:

Tollfree number +44 (0) 20 8616 5148

E-mail contact for U�K� and Ireland:

Go to www�kitchenaid�co�uk, and click on the link “Contact Us” at the bottom

of the page�

Address for U�K� and Ireland:

KitchenAid Europa, Inc�

PO BOX 19

B-2018 ANTWERP 11

BELGIUM

Number for general questions:

In other countries:

For all product related questions and after sales matters, please contact your dealer

to obtain the name of the nearest Authorised KitchenAid Service/Customer Centre�

For more information, visit our website at:

www.KitchenAid.co.uk

www.KitchenAid.eu

W10863936A_01_EN_v11.indd 12 8/17/17 10:19 AM

W10863936A

08/17

and elsewhere.

W10863936A_19_back.indd 4 8/17/17 11:16 AM
