KitchenAid KFGS306VSS00 User manual

COOKTOP, BURNER AND GRATE PARTS

For Models: KFGS306VSS00

(Stainless)

03−08 Litho in U.S.A (amd) Part No. W10184103 Rev. B

30" GAS COOKTOP

COOKTOP, BURNER AND GRATE PARTS

For Models: KFGS306VSS00

(Stainless)

W10184103

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8286867 Installation

Instructions

8304571 Undercounter,

Installation

8286868 Use & Care Guide

Safe Cooking Tips

3191638 English

9759133 French

8287002 LP Conversion

Instructions

W10163405

Cooktop

3 Cap, Burner

8286816 LR

8286817 RR, LF

8286818 RF

4 Grate, Burner

8286661 Right

8286659 Left

5 8287048 Grate, Center

W10132174

Knob, Control (4)

7 Holder, Orifice

W10140570

8286820 LR

W10140569

8286821 LF

8 Head, Burner

8286813 LR

8286814 RR, LF

8286815 RF

10 8287059 Screw

11 Orifice

W10151349

W10151348

W10151350

W10151347

12 Electrode Wiring

8286722 LF

8286723 LR

8286724 RF

8286725 RR

14 8286819 Assembly, Burner

Base

W10137306

Orifice, External

W10137303

Orifice, Simmer

17 8286863 Clip, Electrode

18 Gasket, Orifice

8286930 LR

8286931 RR, LF

8286932 RF

8304603SS

Badge

W10132175

Knob, Special

Burner (1)

21 8287304 Knob, Grommet (5)

W10163407

Spreader, Inner

W10153033

Spreader, Outer

24 8287072 Cross Ring, Burner

25 8287075 Beauty Ring,

Burner

BURNER BOX, GAS VALVES, AND SWITCHES

For Models: KFGS306VSS00

(Stainless)

W10184103

BURNER BOX, GAS VALVES, AND SWITCHES

For Models: KFGS306VSS00

(Stainless)

W10184103

Illus. Part

No. No. DESCRIPTION

1 8286753 Rail, Left Burner

2 8287309 Pipe, Manifold

3 Valve, Gas Burner

8286916 LR

8286919 RR, LF

8286920 RF

8286917 Center

4 8287055 Bracket, Single

Valve (4)

5 8286765 Rail, Center

6 8286691 Transformer

7 8286921 Screw

8 8286858 Bracket, Mainfold

9 3196160 Screw

11 4455917 Bracket, Mounting

W10140947

Tubing, Gas

Burner (RF)

W10140946

Tubing, Gas

Burner (LF)

14 8287306 Tubing, Gas

Burner (RR)

15 8287305 Tubing, Gas

Burner (LR)

16 8286771 Shield, Heat (2)

17 8287102 Insulation,

Reignition Module

18 8286763 Burner Box

19 8286828 Reignition Module

20 8287101 Cover, Reignition

Module

W10132345

Regulator,

Pressure

22 8287056 Bracket, Dual

Valve

23 8287057 Screw (5)

W10140944

Tubing, External

Crown

W10140945

Tubing, Inner

Crown

26 8286728 Rail, Burner Right

W10141511

Plate, Center

Burner

W10140571

Seal, Switch Shaft

29 8286740 Cover Plate, Front

Front Burner Box

OPTIONAL PARTS (NOT INCLUDED)

For Models: KFGS306VSS00

(Stainless)

W10184103

Illus. Part

No. No. DESCRIPTION

Following Parts Not Illustrated

8286692 Cord, Power

3177991 Screw

8286861 Insulation

W10140953

Gasket, Rubber

930mm

W10132168

Gasket, Rubber

1608mm

Miscellaneous

8287082 Spud Kit

8287106 Clip, Wire

W10163327

Assembly, Mounting

Hardware

WIRING HARNESS PARTS

8286698 Harness, Main Wire
