Kinetico Premier Plus User manual
visit www.kinetico.eu
Installation and User Manual
Installation et Guide d’utilisation
Manual de instalación y de usuario
Water Softener
Adoucisseur d’eau / Descalcificador
ENG FR
PREMIER PLUS
ES
Kinetico Premier Plus Water Softener Installation and User Manual
2
For more information about Kinetico:
Pour plus de renseignements sur Kinetico :
Para obtener más información sobre Kinetico:
visit www.kinetico.eu
www.kinetico.eu
3
Original Version
Contents
Safety information 4
Contents of box 6
Specifications 6
How to set the XP 7
Getting to know the softener 9
Pre-installation check list 10
Installation instructions 12
Review 14
Commissioning instructions 15
Useful information 16
Sommaire
Informations de sécurité 18
Contenu de la boîte 20
Caractéristiques 20
Comment régler la dureté (système XP) 21
Se familiariser avec l’adoucisseur 23
Vérifications préalables 24
Instructions d’installation 26
Inspection 28
Instructions de mise en service 29
Informations utiles 30
ENG
FR
ES Contenido
Información de seguridad 32
Contenido de la caja 34
Especificaciones 34
Como ajustar el regulador XP 35
Primeros pasos con el descalcificador 37
Lista de comprobación previa a la instalación 38
Instrucciones de instalación 40
Revisión 42
Instrucciones de puesta en marcha 43
Información útil 44
Kinetico Premier Plus Water Softener Installation and User Manual
4
Safety information
Read all information carefully prior to installing and using the
water softener.
Qualified Installer
Kinetico recommends that a qualified
installer performs the installation. Failure
to install the system as instructed could
invalidate the Limited Warranty.
Water Temperature
Do not install the Kinetico softener in
an area where the water temperature
can exceed 49°C or cause the unit
to freeze. Freezing temperatures will
damage the system.
Water Pressure
Do not install if the supply water pressure
exceeds 6 BAR (87 psi), unless a suitable
pressure regulating valve has been
installed on the softener water supply.
Overflow
VERY IMPORTANT:
Where a cabinet overflow could cause
damage, you must install a 1/2” I.D.
hose to the barbed fitting on the
cabinet and run to a suitable outlet
that is visible and capable of taking the
overflow (i.e. through the outside wall).
Make sure the hose does not go higher
than the barbed fitting as the water
will flow away using gravity.
INSTALLER
1
2
34
5
6
0bar
www.kinetico.eu
5
Original Version
Copper/Plastic Pipework
Where copper/plastic pipework is
used, Kinetico advises adherence to
the regulatory requirements to ensure
adequate earth bonding is provided.
Intended Use
Not intended to be used for treating
water that is micro-biologically unsafe
or water that has an unknown quality,
without adequate disinfection before or
after the system.
Conform to Regulations
You must ensure that the installation
conforms to local plumbing codes and
regulations.
Plumbing Schematic
Please refer to the plumbing schematic
on page 10 before commencing an
installation.
1
2
34
5
6
0bar
Kinetico Premier Plus Water Softener Installation and User Manual
6
Contents of box
Identify the following parts before proceeding.
Meter Disc A B C D E F G H I * J * K * L * M *
PPM 207 221 238 256 279 305 337 376 426 456 490 531 578 635 686 770 878 1020
˚f 21 22 24 26 28 30 34 38 43 46 49 53 58 64 69 77 88 102
˚D 12 12 13 14 16 17 19 21 24 26 27 30 32 36 38 43 49 57
Litres between
regenerations 1583 1480 1377 1274 1171 1068 965 862 759 708 656 605 553 502 450 399 347 224
Cabinet dimensions (h x w x d) 645 x 480 x 396 mm
Salt used per regeneration 0.56 kg
Regeneration time 11 minutes
Flow rate @ 1 bar pressure drop 22.7 l/min
Pipe connections - in/out ¾” BSP
Min/max operating pressure 1.8 - 6 bar
Min/max operating temperature 2 - 49˚C
Specifications
Max
hardness
1 x in/out retaining
bracket and pin
4 x o-ring
1 x 2cc silicone tube 2 x 3/4” washers 2 x 3/4” BSP in/out adaptor
By-pass valve
(included with the Premier Plus HE ALT BP only)
www.kinetico.eu
7
Original Version
How to set the XP
Unlock the XP:
Manually initiate a regeneration
until the XP meter is in the home
position. This is identified by the
XP arrow at the 6 o’clock position
on the valve.
1
Select the setting
using the chart:
Determine the XP meter setting
from the chart on previous page:
a: find your unit
b: read across to hardness level
c: read to the top for setting.
For applications containing iron,
use the highest (certified where
applicable) salt dosage.
2
Set the XP meter:
Adjust the XP meter setting by
using a 3/16” or smaller flat-head
screwdriver to push down and
rotate the hardness adjustment
knob.
3
Kinetico Premier Plus Water Softener Installation and User Manual
8
Release the XP
adjuster:
Release adjuster, making sure
knob returns to an up position.
5
Notes:
NEVER set XP with the arrow
aligned anywhere in the black
section of the meter disc. The
softener will not meter properly.
6
Confirm the setting:
Set the arrow to the desired
position. The arrow points to
the centre of the box for whole
figure settings. For 1/2” settings,
the arrow points to the line
between boxes.
4
Set to K in this
example
www.kinetico.eu
9
Original Version
Getting to know the softener
Salt compartment
Top lid
Front lid
Kinetico Premier Plus Water Softener Installation and User Manual
10
Air gap:
Local regulations
must be adhered to
Pre-installation check list
When determining the location of the softener, the following
should be considered:
To home
To drain
Cold water supply
Optional extra:
Pressure regulating
valve
Non-return valve:
Local regulations
must be adhered to
Optional extra:
Non-return valve, local regulations
must be adhered to
Overflow
