Kikusui PAN 16-10A User manual

Part No. Z1-002-322, IA003474

Apr. 2009

PAN 16-10A

PAN 60-3A

PAN 110-1.5A

PAN 35-5A

PAN 70-2.5A

PAN 160-1A

PAN 16-18A

PAN 60-6A

PAN 110-3A

PAN 35-10A

PAN 70-5A

PAN 160-2A

PAN 16-30A

PAN 60-10A

PAN 110-5A

PAN 250-2.5A

PAN 35-20A

PAN 70-8A

PAN 160-3.5A

PAN 16-50A

PAN 60-20A

PAN 110-10A

PAN 250-4.5A

PAN 600-2A

PAN 35-30A

PAN 70-15A

PAN 160-7A

PAN 350-3.5A

175W MODEL

350W MODEL

700W MODEL

1000W MODEL

OPERATION MANUAL

Regulated DC Power Supply

PAN-A Series

About This Manual

If you ﬁnd any incorrectly arranged or missing pages in this manual, they will be

replaced. If the manual gets lost or soiled, a new copy can be provided for a fee. In

either case, please contact Kikusui agent/distributor, and provide the "Part No." given

on cover.

This manual has been prepared with the utmost care; however, if you have any ques-

tions, or note any errors or omissions, please contact Kikusui agent/distributor.

All or any parts of this manual may not be reproduced in any forms, without express

written permission of Kikusui Electronics Corporation.

The contents of this manual are subject to change without notice.

PAN-A I

Power Requirements of this Product

Power requirements of this product have been changed and the

relevant sections of the Operation Manual should be revised

accordingly. (Revision should be applied to items indicated by a

check mark .)

Input voltage

The input voltage of this product is _______________ VAC,

______________ VAC.

and the voltage range is __________ to

___________ A, ___________ .___________ VAC, and

Use the product within this range only.

Input fuse

The rating of this product's input fuse is

WARNING

To avoid electrical shock, always disconnect the

AC power cord or turn off the switch on the

switchboard before attempting to check or replace

the fuse.

Use a fuse element having a shape, rating, and

characteristics suitable for this product. The use of

a fuse with a different rating or one that short

circuits the fuse holder may result in fire, electric

shock, or irreparable damage.

•

II PAN-A

PAN-A III

Safety Symbols

For the safe use and safe maintenance of this product, the

following symbols are used throughout this manual and on

the product. Understand the meanings of the symbols and

observe the instructions they indicate (the choice of sym-

bols used depends on the products).

Indicates that a high voltage (over 1000 V) is used here.

Touching the part causes a possibly fatal electric shock. If

physical contact is required by your work, start work only

after you make sure that no voltage is output here.

DANGER

Indicates an imminently hazardous situation which, if

ignored, will result in death or serious injury.

WARNING

Indicates a potentially hazardous situation which, if

ignored, could result in death or serious injury.

CAUTION

Indicates a potentially hazardous situation which, if

ignored, may result in damage to the product and other

property.

Shows that the act indicated is prohibited.

Indicates a general danger, warning, or caution.

When this symbol is marked on the product, see the rele-

vant sections in this manual.

Protective conductor terminal.

Chassis (frame) terminal.

On (supply)

Off (supply)

In position of a bi-stable push control

Out position of a bi-stable push control

IV PAN-A

Safety Precautions

The following safety precautions must be observed to avoid

ﬁre hazard, electrical shock, accidents, and other failures.

Keep them in mind and make sure that all of them are

observed properly.

Using the product in a manner that is not speciﬁed in this

manual may impair the protection functions provided by the

product.

Users

• This product must be used only by qualified

personnel who understand the contents of this

operation manual.

• If it is handled by disqualified personnel, personal

injury may result. Be sure to handle it under

supervision of qualified personnel (those who

have electrical knowledge.)

• This product is not designed or produced for

home-use or use by general consumers.

Purposes of use

• Do not use the product for purposes other than

those described in the operation manual.

Input power

• Use the product with the specified input power

voltage.

• For applying power, use the AC power cord

provided. For details, see the relevant page of this

operation manual.

Fuse

• With products with a fuse holder on the exterior

surface, the fuse can be replaced with a new one.

When replacing a fuse, use the one which has

appropriate shape, ratings, and specifications.

Operation

Manual

Line

Voltage

PAN-A V

Cover

• There are parts inside the product which may

cause physical hazards. Do not remove the

external cover.

Installation

• When installing products be sure to observe "1.3

Precautions for installation" described in this

manual.

• To avoid electrical shock, connect the protective

ground terminal to electrical ground (safety

ground).

• When applying power to the products from a

switchboard, be sure work is performed by a

qualified and licensed electrician or is conducted

under the direction of such a person.

Relocation

• Turn off the power switch and then disconnect all

cables when relocating the product.

• Use two or more persons when relocating the

product which weights more than 20 kg. The

weight of the products can be found on the rear

panel of the product and/or in this operation

manual.

• Use extra precautions such as using more people

when relocating into or out of present locations

including inclines or steps. Also handle carefully

when relocating tall products as they can fall over

easily.

• Be sure the operation manual be included when

the product is relocated.

VI PAN-A

Operation

• Check that the AC input voltage setting and the

fuse rating are satisfied and that there is no

abnormality on the surface of the power cord. Be

sure to unplug the power cord or stop applying

power before checking.

• If any abnormality or failure is detected in the

products, stop using it immediately. Unplug the

power cord or disconnect the power cord from the

switchboard. Be careful not to allow the product to

be used before it is completely repaired.

• For output wiring or load cables, use connection

cables with larger current capacity.

• Do not disassemble or modify the product. If it

must be modified, contact Kikusui distributor/

agent.

Maintenance and checking

• To avoid electrical shock, be absolutely sure to

unplug the power cord or stop applying power

before performing maintenance or checking.

• Do not remove the cover when performing

maintenance or checking.

• To maintain performance and safe operation of

the product, it is recommended that periodic

maintenance, checking, cleaning, and calibration

be performed.

Service

• Internal service is to be done by Kikusui service

engineers. If the product must be adjusted or

repaired, contact Kikusui distributor/agent.

Check?

PAN-A VII

Arrangement of this manual

This Operation Manual is made up of the following sections.

Preface

Describes all the models covered by this manual, as well as out-

lines the features of each model.

Chapter 1 "Setup"

This chapter describes the necessary procedure from unpacking

to preparation before use. Since details on installation location

and power supply are provided, be sure to read this chapter

before using the unit for the ﬁrst time.

Chapter 2 "Before Using the Unit"

Before using the power supply, users are requested to thoroughly

understand the following units.

Chapter 3 "Basic Operation"

Describes the unit’s start-up function, protection circuit, and the

basic operations managed from the front panel of the unit.

Chapter 4 "Applied Operation"

Explains the remote control of the unit, and use of multiple num-

ber of power supply in combination to increase output capacity.

Chapter 5 "Names and Functions of Controls"

Provides an outline of the switches and terminals on the panels,

including their names and functions.

Read this chapter to learn the meanings of the caution

marks indicated on the panels of the unit.

Chapter 6 "Maintenance"

Describes the daily inspection procedures and the adjustment

conducted when necessary. To remote-control the unit, such

adjustment is necessary. Follow the adjustment procedures

detailed in this chapter. The chapter also describes some symp-

toms of possible problems encountered during use of the unit,

along with appropriate remedies.

VIII PAN-A

Chapter 7 "Speciﬁcations"

Describes the electrical, mechanical and general speciﬁcations of

the unit.

This manual suits for next models
