Keymile SUPM1 User manual
User Manual
SUPM1
supm1_r2b
POTS, TDM services
XMC20
XMC20
SUPM1 User Manual
Copyright and Confidentiality Copyright in this document vests in KEYMILE. This document contains confi-
dential information which is the property of KEYMILE. It must be held in con-
fidence by the recipient and may not be used for any purposes except those
specifically authorised by contract or otherwise in writing by KEYMILE. This
document may not be copied in whole or in part, or any of its contents dis-
closed by the recipient to any third party, without the prior written agreement
of KEYMILE.
Disclaimer KEYMILE has taken reasonable care in compiling this document, however
KEYMILE accepts no liability whatsoever for any error or omission in the
information contained herein and gives no other warranty or undertaking as
to its accuracy.
KEYMILE reserves the right to amend this document at any time without
prior notice.
Document PEC EN/LZTBU 372 129/1 RC
Document release XMC20 R4C/R6B | 9 December 2015
Published by KEYMILE
http://www.keymile.com
User Manual
SUPM1
page 3 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
Content
1 Preface 6
1.1 Precautions and Safety 6
1.2 Symbols and Notations 6
1.3 Interfaces and Circuit Categories 7
1.4 Document History 7
2Introduction 8
2.1 General 8
2.2 Unit View 9
3 Functions and Specifications 10
3.1 Feature Licences 10
3.2 Main Functions and Specifications 10
3.3 User Ports 13
3.4 Voice Transmission Specification 14
3.5 Signalling Specification 16
3.6 Thermal Management 21
3.7 Line Test 22
3.8 Length of Subscriber Lines 24
3.9 Power Consumption 25
4 Installation 27
4.1 Prerequisites 27
4.2 Slots and Deployment Scenarios for the SUPM1 Unit 28
4.3 Splitters 30
4.4 Jumpers 30
4.5 Protection 30
4.6 Compatibility 31
4.7 Connections and Cables 32
User Manual
SUPM1
page 4 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
5 Functional Description 35
5.1 V5CAS Mode of Operation 35
5.2 Mercury CAS Modes of Operation 36
5.3 Phone-Exchange Mode of Operation 39
5.4 Phone-Phone Mode of Operation 41
5.5 Port States 43
5.6 PSTN Maintenance 45
5.7 Line Impedance Selection 47
5.8 Input and Output Level 48
5.9 Line Feeding 49
5.10 Signalling 50
5.11 Line Test 52
5.12 Thermal Management 58
5.13 Power Management 59
5.14 Special Features 60
6 Commissioning 61
6.1 Commissioning of a PSTN Port 61
7 Operation 66
7.1 Unit Optical Indicators 66
7.2 Maintenance 67
8 User Interface Reference 68
8.1 Introduction 68
8.2 AP: / unit-x: SUPM1 70
8.3 AP: / unit-x / port-y 82
9Annex 93
9.1 Associated XMC20 Documents 93
9.2 Technical Support 94
9.3 Product Training 94
User Manual
SUPM1
page 5 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
Figures
Figure 1: SUPM1 applications with and without local exchange 8
Figure 2: SUPM1 unit view 9
Figure 3: XMC25subrack with 19 SUPM1 units and 1 STM14 unit 28
Figure 4: XMC23 subrack with 6 SUPM1 units and 1 SELI8 unit 28
Figure 5: XMC25 subrack with 19 SUPM1 units and 1 VOIP1 unit 29
Figure 6: Pin-out of the SUPM1 front connectors, front view 32
Figure 7: Side view of the cable tray and the cable in XMC25 33
Figure 8: V5CAS routing in XMC20 35
Figure 9: MCAS routing in XMC20 36
Figure 10: Phone-Exchange mode 39
Figure 11: Phone-Phone mode 41
Figure 12: Digital test loop for voice signals 46
Figure 13: a/b impedance 47
Figure 14: Level configuration on input and output directions 48
Figure 15: Test adapter 54
Figure 16: Finite state machine for the line-test procedure 56
Figure 17: Thermal management thresholds 58
Figure 18: Power management for normal priority subscribers 59
Figure 19: Fault indication LEDs on the SUPM1 unit 66
Figure 20: MOM (managed object model) of the SUPM1 unit 68
User Manual
SUPM1
page 6 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
Preface
1Preface
1.1 Precautions and Safety
Before you handle any equipment you must comply with the safety advices.
Adherence to the safety instructions ensures compliance with the safety
requirements as defined in EN 60950 (Safety of Information Technology
Equipment).
Please refer to the following document:
[202] Safety Instructions “Precautions and safety”.
1.2 Symbols and Notations
This User Manual uses the following symbols:
WARNING
Non-observance can lead to death or injury. Non-observance could result in death or serious injury.
Indicates a hazard with a medium level of risk which, if not avoided, could
result in death or injury to the user.
→ Possible actions are given.
NOTICE
Non-observance could result in equipment damage.
Failing to comply with this may result in physical damage.
→ Possible actions are given.
Risk of operating trouble!
Indicates that an action may lead to operating trouble or loss of data.
→ Possible actions are given.
Please note:
Shows significant information.
→ Possible actions are given.
User Manual
SUPM1
page 7 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
Preface
1.3 Interfaces and Circuit Categories
1.4 Document History
Table 1: Electrical interfaces and circuit categories
SUPM1 interface Circuit category according to
EN 60950-1
Max. rating
Voltage Current
Local power supply TNV2 < 72 VDC < 2.5 A
PSTN a/b interface TNV3 < 53 VDC < 45 mA
< 75 VRMS < 120 mA
Table 2: Document history
KEYMILE PEC Date XMC20
release
Changes since previous version
EN/LZTBU 372 129/1 RC November 2015 R6B Revision for the XMC20 system releases R4C and R6B
EN/LZTBU 372 129/1 RB July 2015 R6A HW name for VOIP1 corrected
EN/LZTBU 372 129/1 RA March 2015 R6A Revision for the XMC20 system release R6A
EN/LZTBU 372 129 RC February 2015 R4C First revision for the XMC20 system release R4C
User Manual
SUPM1
page 8 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
Introduction
2Introduction
2.1 General
This document describes the architecture and functions of the SUPM1 unit
and shows, how this unit is commissioned and operated as part of the
XMC20.
The SUPM1 unit is a 1-slot wide service unit of XMC20. It has 16 PSTN user
ports with a telephony bandwidth of 300 Hz to 3.4 kHz. The SUPM1 unit con-
verts the analogue voice signal to a 64 kbit/s digital signal (and vice versa).
This type of user ports is also called FXS interface, 2-wire analogue interface
or a/b-interface.
The SUPM1 unit allows the connection of an analogue telephone set to a
local exchange via a TDM network.
Another application is in a private network where two telephone sets are
directly interconnected without a local exchange.
Figure 1: SUPM1 applications with and without local exchange
The SUPM1 unit is connected to a P12 transport unit, e.g. SELI8, via the
PBUS in the backplane of XMC20.
The SUPM1 unit can also be connected to the Voice over IP (VoIP) media
gateway VOIP1 via the PBUS in the backplane of XMC20.
Where the voice circuits are running in environments with high electrical
interference, e.g. near the rail infrastructure, the high voltage common mode
filter box FIL16 can be deployed between the SUPM1 front ports and the
line. For more information please refer to [458] User Manual “FIL16”.
FXO
P12 transport unit
FXS
TDM
Network
FXO FXS
Analogue
exchange
FXO FXS
TDM
Network
FXO FXS
XMC20 XMC20
SUPM1
TUXA1
SUPM1
SUPM1
XMC20 XMC20
User Manual
SUPM1
page 9 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
Introduction
2.2 Unit View
Figure 2: SUPM1 unit view
Figure 2 "SUPM1 unit view" shows the SUPM1 unit hardware. On the front
plate are two LEDs for the unit- and traffic failure indication and one standard
DIN 41 612 based connector for 16 PSTN signals.
User Manual
SUPM1
page 10 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
Functions and Specifications
3Functions and Specifications
The SUPM1 unit provides the following functions and conforms to the corre-
sponding standards and recommendations (conformance to applicable parts
of the standards).
3.1 Feature Licences
Part of the XMC20 functionality is subject to feature licences. For more infor-
mation on feature licences please refer to [012] Release Note “XMC20” and
to [915] Technical Bulletin “Feature Licences for XMC20”.
3.2 Main Functions and Specifications
NOTICE
Overvoltage. Risk of equipment damage!
Onboard overvoltage protection is only adequate for inhouse connections.
→ For connections leaving the building external primary protection with
gas discharge tubes is mandatory.
