■Operation
After installation is complete, turn on the power of the Cascom-S. Wait for 10 minutes until cooling water
circulates completely. After cooling water circulates completely, water level of the optional chiller will lower.
Pour water in accordance with the instruction manual of the Cascom-S.
The installation is finished. The machine is ready to cast.
■Deterioration of the cooling function
When the water overheating error is displayed, the cooling function may be deteriorating.
Make sure the following.
・Keep the machine away from other equipment.
・Remove the filter as indicated below and clean the dust with an air gun.
Note) If an air gun is used without removing the filter, the dust filled in the machine may cause malfunction.
・The cooling fans work with fans of the optional chiller. When the cooling fans do not work, contact our support
team for repair.
■Specifications
Dimensions & Weight 304(W)×396(H)×212(D) 9kg
Power Requirement AC220-240V±10% 50/60Hz
Power Consumption 50VA and less
Cooling Method Air Cooling Radiator
Environment Temperature 10～40℃ Humidity 30～90% (Non condensing)
24-3 Kisshoin Ishiharakyomichi-cho, Minami-ku, Kyoto, 601-8356, JAPAN
TEL：81-75-672-2124 E-mail：info@denken-highdental.co.jp
Expanded Chiller
HPC-40 Instruction Manual
We recommend you to follow these instruments for proper use of the unit.
The safety precautions contained herein and the accompanying icons are provided for the safe use of
this machine and to prevent injuries and loss on material resources. Please read them carefully prior to
your actual machine operation. It is recommended that use of this unit should not be attempted by anyone
who is not well informed of the precautions necessary for machine operation.
Failure to follow or ignorance of the directions may
cause severe injury or death.
Failure to follow or ignorance of the directions may
cause injuries or damages to material properties.
In the event when there is smoke, abnormal odors or sounds, unplug
immediately and contact the dealer for repairs.
Continued use may cause electric shock or fire.
In the event when water or debris enters the machine, unplug
Immediately and contact the dealer for advice.
Continued use may cause electric shock or fire.
In the event when the machine is dropped or the exterior frame is
dented, unplug immediately and contact the dealer for advice.
Continued use may cause electric shock or fire.
Do not remove the panels or parts uninstructed or modify them in
any manner. Some of the parts inside contain high voltage and
contact with them may cause fire or electric shock. We recommend
you to contact the dealer for repairs or machine maintenance.
Plug to the power outlet of the designated voltage described in the
main specifications. Use of any other voltage may cause fire or
electric shock.
W1015200-3
Unplug
Not Designated
Volt. Prohibited
Do Not Disassemble
WARNING
CAUTION
WARNING
Unplug
Unplug
