KALOS KLEH122 User manual

Universal Electric Lantern

Heater – 65cm & 80cm

KLEH122/KLEH123-0300

Assembly Instructions

Feb 2022

IMPORTANT

PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE.

THIS IS IMPORTANT INFORMATION REGARDING THE USE AND

CARE OF YOUR OUTDOOR HEATER.

Important Information

Important advice beforeyou begin:

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a

safe way and understand the hazards involved.

Children should not play with theappliance.

Cleaning and user maintenance should not be

made by children withoutsupervision.

Do not use any other tools other than those

recommended to build this product.

Please do not use substitute parts. Use only

additional or replacement parts supplied byKettler.

In the unlikely event that this product has missing

or damaged parts, please visit our website

www.kettler.co.uk/shop.

Unpack the outdoor heater making sure that all of the items are present and that

there are no components left in the box and the heater head is free from any

packaging material. Extra packaging is added to some models for transportation

protection which must be removed before assembly.

Using the detailed drawing following the steps to assemble the outdoor heater

(where relevant).

DO NOT connect the outdoor heater to the electrical supply until the assembly is

complete.

DO NOT connect the outdoor heater to the electrical supply if any of the

components or power cord is damaged in any way.

CAUTION - Risk of Electric Shock. DO NOT open or try to repair the heater yourself.

For Your Safety

1. Site the heater outside or in a large

open area and well away from any

obstructions such as branches or where

the heater is near any objects that can

be aected by heat, such as furniture,

curtains or other inammable objects

(minimum distance 1 metre).

2. DO NOT use this heater in the immediate

surroundings of a bath, a shower or a

swimming pool. Do not use near water.

3. DO NOT use in unventilated areas.

4. DO NOT use where gas, petrol, paint or

other surely ammable goods are stored.

5. DO NOT push any items through,

obstruct or cover the grill of the heater

head.

6. DO NOT position immediately above or

below an electrical socket.

7. DO NOT move when connected to an

electrical supply and always wait for

the patio heater to cool down before

cleaning / storing away.

8. DO NOT touch the heater head when in

use.

9. DO NOT leave turned on and

unattended especially when children

and or animals are in the vicinity.

10. The indication of the dierent positions

of switches shall be visible from a

distance of 1M.

11. The marking concerning covering should

be visible after the heater has been

installed. It shall not be placed on the

back of portable heaters.

Warning

• This heater is not equipped with a device

to control the room temperature. DO NOT

use this heater in small rooms when they

are occupied by persons not capable of

leaving the room on their own, unless

constant supervision is provided.

• Children of less than 3 years should be

kept away unless continuously supervised.

• Children under 8 years shall not plug

in, regulate and clean the appliance or

perform user maintenance.

Caution

• Some parts of this product can become

very hot and cause burns. Particular

attention must be given where children,

vulnerable people and animals are

present.

• For oor mounted heaters only use

the heater on a rm solid horizontal

area where all the feet on the base are in

contact with the oor. (Should the heater

be tilted or fall over the auto cut o switch

will activate).

• Risk of Electric Shock. DO NOT open or

try to repair the heater yourself.

• Any maintenance or repairs including

replacing the tube(s) should only be

carried out by a qualied electrician or by

a qualied service centre.

For Your Safety

12. The unit must be placed with the

clearance of 100cm to the wall.

13. The unit must be correctly installed

according to the instructions.

14. The unit is at high temperature during

operation. It keeps hot for a period after

shut down. Potential danger would occur

when touching it during this period.

Unplug the unit and wait till it cools

before cleaning.

15. DO NOT place the unit close to curtain

and/or other ammable objects.

Otherwise there will be a danger of

catching re.

16. DO NOT cover the unit with anything

during operation or a short time after it is

shut down.

17. DO NOT wrap the power supply cord on

the unit.

18. The unit must be handled with care, and

avoid vibration or hitting.

19. An apparatus with CLASS I construction

shall be connected to a MAINS socket

outlet with a protective earthing

connection.

20. DO NOT use if the unit or power cable is

damaged.

21. DO NOT attempt to repair or adjust any

electrical or mechanical functions on this

unit. Doing so will void your warranty.

The inside of the unit contains no user

serviceable parts. Servicing / Repair

should only be performed by a qualied

electrician or aqualied service centre.

22. DO NOT use this unit in place where

causticity or volatile air exists, i.e. dust,

steam, gas, etc.

23. DO NOT use this unit as a cloth drier or

towel drier.

24. DO NOT use this unit as a sauna heater.

25. DO NOT use this unit as a room heater.

26. DO NOT use this unit in place of animal

propagating and raising.

27. DO NOT immerse this unit into water for

cleaning.

28. The unit should be plugged in a socket,

which is easily visible and reachable.

29. DO NOT use this heater with a

programmer, timer or any other

device that switches the heater on

automatically, since a re risk exists

if the heater is covered or positioned

incorrectly.

30. Children should be supervised to ensure

that they do not play with the appliance.

31. When assembling, keep clear from any

board or ammable material.

32. DO NOT insert or allow foreign objects

to enter any ventilation or exhaust

opening as this may cause an electric

shock or re, or damage the heater.

33. Use only for intended household use as

described in this manual. Any other use

not recommended by the manufacturer

may cause re, electric shock, or injury

to persons. The use of attachments not

recommended or sold by unauthorized

dealers may cause hazards.

For Your Safety & Technical Specication

34. The unit is for household use only. It

is not safe to use on a building site,

greenhouse, barn or stable where there’s

ammable dust.

35. Avoid the use of an extension cord

because the extension cord may

overheat and cause a risk of re.

However, if you must use an extension

cord, the cord shall be rated to 13A

(Minimum conductor size 1.5mm2) and

if the cord is on a reel it must be fully

unwound before use.

36. Disconnect the power cable from the

electrical supply when the heater is

not in use. If the power cord becomes

damaged, it must be replaced by a

qualied electrician.

37. This appliance is not intended for use

by a person (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning

use of the appliance by a person

responsible for their safety.

38. One dark point may exist on the surface

of the heating elements during the

rst few minutes after it is turned on.

This is normal, and will not aect the

performance of the unit.

39. To avoid re or shock hazard, plug the

unit directly into a 220-240 Vac and 13A

electrical socket outlet.

Technical Specication

• Power supply 220-240V~ 50Hz

• Wattage 1500W

• Insulation class I

This warning symbol

indicates that the surface is

hot and caution is required.

This warning symbol

indicates that the heater

should not be covered.

Heater Handle

Heater Lamp

Heater Base

Power Switch

Protection Mesh

Touch Switch

0/1200W

Operation Instructions

Trouble Shooting

If the heater will not operate, please check the following before seeking repair of service:

• Check if the power cord is plugged into an electrical outlet, if not plug in.

• Check if electricity to the main fuse isworking.

• Make certain the power switches are turned on. If not, choose a setting.

• Connect the power cable to a 13 amp

supply that is located in a safe, dry area.

• Press the power switch on the heater when

the plug had been connected.

• Press the touch switch one time to operate

the heater on 1500W.

• Press the touch switch second time for o.

• Although the patio heater is shower

proof, do not use when raining or in

wetconditions.

• Always disconnect the power cable from

the electrical supply, when the patio

heateris not in use.

0/1500W

Notes

Maintenance and Care Instructions

• When disconnected from the electrical supply, clean the outside of the patio heater with a

damp cloth. Never use corrosive or solvent cleaners or immerse in water.

• Any maintenance or repairs including replacing the halogen tube should only be carried out by

a qualied electrician or by a qualied service centre.

• Check all components regularly for correct function, damage and loose connections especially

at the start of the season and at 1-2 month intervals dependent on use.

• Damaged components may endanger your safety or shorten the life of the product. Replace all

damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to

purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop

• Kettler will not be responsible for damaged caused by improper use.

Storage

• If the heater will not be used for a long period of time, store it in a cool, dry location when not

in use. To prevent dust and dirt build-up, use the original packaging to repack the unit.

Warranty For Home Use

This product is covered by a 12 month

warranty against manufacturing faults.

This warranty applies to domestic use

only. It does not cover commercial use,

mis-use or accidental damage.

To validate your warranty, register

at www.kettler.co.uk and quote

the product code from the front of

this booklet.

12Mth

Warranty

www.kettler.co.uk

The symbol indicates that the

product should not be discarded as

unsorted waste but must be sent

to separate collection facilities for

recovery and recycling.

This manual suits for next models

Table of contents

Other KALOS Heater manuals

KALOS

KALOS KLEH161-0600 User manual

KALOS

KALOS KLEH160-0600 User manual

KALOS

KALOS KLEH143-0400 User manual

KALOS

KALOS KLEH122 User manual

KALOS

KALOS KLEH143-0400 User manual

KALOS

KALOS KLEH121-0300 User manual

KALOS

KALOS KLEH152-0500 User manual

KALOS

KALOS KLEH124-0300 User manual

KALOS

KALOS KLEH125-0300 User manual

KALOS

KALOS KLEH162-0600 User manual

KALOS

KALOS KLEH152-0500 User manual

Popular Heater manuals by other brands

oventrop

oventrop Regucor Series quick start guide

Blaze King

Blaze King CLARITY CL2118.IPI.1 Operation & installation manual

ELMEKO

ELMEKO ML 150 Installation and operating manual

BN Thermic

BN Thermic 830T instructions

KING

KING K Series Installation, operation & maintenance instructions

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Installation instructions and owner's manual

Well Straler

Well Straler RC-16B user guide

EUROM

EUROM 333299 instruction manual

Heylo

Heylo K 170 operating instructions

Eterna

Eterna TR70W installation instructions

Clarke

Clarke GRH15 Operation & maintenance instructions

IRSAP

IRSAP The Radiator Company Ovali Fitting instructions

Empire Heating Systems

Empire Heating Systems WCC65 Installation and owner's instructions

Wetekom

Wetekom 92 86 43 Original instructions

Desa

Desa SPC170-F owner's manual

Watlow

Watlow Watrod Electric Tubular Heaters Specifications

Haverland

Haverland ECO-DRY GPS Series Instruction & installation manual

Stelpro

Stelpro ASILVC2060 Series user guide
