Kärcher CVS 65/1 User manual
QUICKSTART CVS 65/1
5.969-851.0 05/21
WARNING
These are brief instructions and do not replace the original operating instructions enclosed with the device! Before
using or servicing the device, read the operating instructions supplied with the device.
If the operating instructions and safety instructions are not observed, the device can be damaged and dangers
could arise for users and other persons.
Start up
1ABCTurning on the Appliance
A Adjust the push handle.
B Insert the battery and click into place, to do
this press down until it is in the latching posi-
tion.
C Switch on the device (switch in position I).
Note: LED lights up green
2A B Adjusting the roller brush
A Lift the twist grip and turn it clockwise to in-
crease the contact pressure.
- Increase the contact pressure until the LED
lights up red.
B Turn back one position until the LED lights up
green. Then let go of the twist grip and click
into place.
- Recommended operation: "Maximum con-
tact pressure with green LED display".
QUICKSTART CVS 65/1
5.969-851.0 05/21
Sweeping operation
1A B Sweeping mode
A Work direction is exclusively forwards.
B To pick up coarse dirt, press the device down
on the push handle at the rear and thereby
raise the device at the front. Pick up coarse
dirt by pushing the device.
2A B c Sweeping with a side brushes (in the
area near the edge)
A Press lowering the side brushes and lower
the side brushes (foot control).
B Adjust the contact pressure using the rotary
knob of the side brushes.
C Use the rotary knob to lift the side brushes to
clean open areas.
Shutting down the device
1ABCTurn off device
A Bring the roller brush to the top position with
the rotary knob.
B Switch off the device (switch in position 0).
C Raise the side brushes by pulling the rotary
knob.
2ABCEmpty the waste container
A Release the lock by pressing the yellow bar.
B Tilt the waste container down and pull it out to
the rear.
C Completely drain the waste container.
D Insert waste container.
2
3
D A Charging the battery
A Remove the battery, insert it into the charging
station and charge.
QUICKSTART CVS 65/1
5.969-851.0 05/21
Maintenance and care
1A B Service (weekly)
A Visually check the roller brush/side brush-
es for damage and wear.
B Visually check the filter for damage.
C Clean the pre-filter and main filter.
- Pull out the pre-filter and clean it.
- Knock out the dirt in the main filter in the
cartridge or remove it and vacuum it (every
10 operating hours)
D Clean the unit using a damp cloth, wetted
with a mild washing lye
1C D
Troubleshooting
1ABCDevice does not start
A Check battery charge.
B Check whether the cover is closed (contact
switch cover).
C Check whether the battery is correctly en-
gaged.
2AB C Device overloaded - LED flashes red
A Switch off the device (switch in position 0).
B Raise roller brush.
C Switch on the device (switch in position I).
3ABCRoller brush does not sweep properly
A Check the roller brush for wear and wrapped
belts.
B Check/readjust sealing strips for wear and
tear.
C Increase the contact pressure.
4ABCDust generation
A Empty waste container.
B Remove the filter box and check the filter
cleaning function.
C Check/clean the filter system (filter box, pre-
filter and HEPA filter).
