JVC KD-G821 User manual
ENGLISHDEUTSCH
РУCCKИЙ
CD RECEIVER
CD-RECEIVER
РЕСИВЕР С ПРОИГРЫВАТЕЛЕМ КОМПАКТ-ДИСКОВ
KD-G821
For installation and connections, refer to the separate manual.
Für den Einbau und die Anschlüsse siehe das eigenständige Handbuch.
Указа ия по уста овке и выпол е ию соеди е ий приводятся в отдель ой и струкции.
INSTRUCTIONS
BEDIENUNGSANLEITUNG
ИНСТРУКЦИИ ПО ЭКСПЛУАТАЦИИ
GET0362-006A
[EY]
For canceling the display demonstration, see page 6.
Zum Abbrechen der Displaydemonstration siehe Seite 6.
И формацию об отме е демо страции фу кций дисплея см. а стр. 6.
Cover_KD-G821_006A_1.indd 2Cover_KD-G821_006A_1.indd 2 15/12/05 5:25:50 pm15/12/05 5:25:50 pm
2
ENGLISH
How to forcibly eject a disc
“Please Eject” appears on the display.
• If this does not work, reset your unit.
• Be careful not to drop the disc when it ejects.
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your co plete understanding and to
obtain the best possible perfor ance fro the unit.
IMPORTANT FOR LASER PRODU TS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to bea .
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
How to reset your unit
Your preset adjustments will also be erased.
How to use the MODE/SEL button
If you use MODE or SEL (select), the display
and so e controls (such as the nu ber buttons,
4/¢ buttons, 5/∞ buttons, and the
control dial) enter the corresponding control
ode.
Ex.: When you press nu ber button 1 after
pressing MODE, to operate the FM tuner.
Works as time countdown indicator.
To use these controls for original functions
again, wait for 15 seconds without pressing any
of these buttons until the control is cleared.
• Pressing MODE again also restores original
functions. However, pressing SEL akes the
unit enters a different ode.
aution:
If the te perature inside the car is below 0°C, the ove ent of ani ation and text scroll will be
halted on the display to prevent the display fro being blurred. appears on the display.
When the te perature increases, and the operating te perature is resu ed, these functions will
start working again.
EN02-05KD-G821[EX_EU]f.indd 2EN02-05KD-G821[EX_EU]f.indd 2 22/12/05 6:53:55 pm22/12/05 6:53:55 pm
ENGLISH
3
CONTENTS
Control panel ................................... 4
Remote controller — RM-RK50 ................. 5
Getting started ................................. 6
Basic operations ................................................... 6
Radio operations .............................. 7
FM RDS operations ............................
Searching for your favorite FM RDS programme ....... 10
Disc/USB memory operations ............. 12
Playing a disc in the unit ...................................... 1
Playing discs in the CD changer ............................ 1
Playing a USB memory ......................................... 13
Sound adjustments ........................... 17
General settings — PSM ................... 1
Title assignment ............................... 28
iPod®/D. player operations ................ 28
Other external component operations ... 30
DAB tuner operations ........................ 31
More about this unit ......................... 35
Maintenance .................................... 3
Troubleshooting ............................... 40
Specifications ................................... 43
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• Stop the car before performing any
complicated operations.
Temperature inside the car...
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
For security reasons, a numbered ID card is provided with this unit, and the same ID number is
imprinted on the unit’s chassis. eep the card in a safe place, as it will help the authorities to identify
your unit if stolen.
How to read this manual
• Button operations are mainly explained with
the illustrations in the table below.
• Some related tips and notes are explained in
“More about this unit” (see pages 35 – 39).
Press briefly.
Press repeatedly.
Press either
one.
Press and hold until your
desired response begins.
Press and hold both
buttons at the same time.
The following marks are used to indicate...
: Built-in CD player operations.
: External CD changer operations.
: External USB memory operations.
Warning:
If you need to operate the unit while driving,
be sure to look ahead carefully or you may be
involved in a traffic accident.
Caution on volume setting:
Discs produce very little noise compared
with other sources. Lower the volume
before playing a disc to avoid damaging
the speakers by the sudden increase of the
output level.
EN02-05KD-G821[EY]f.indd 3EN02-05KD-G821[EY]f.indd 3 12/28/05 10:52:34 AM12/28/05 10:52:34 AM
4
ENGLISH
1 BAND button
2 • Control dial
• (standby/on attenuator) button
3 DISP (display) button
4 Re ote sensor
• DO NO expose the remote sensor to
strong light (direct sunlight or artificial
lighting).
5 Display window
6 5 (up) / ∞ (down) buttons
Parts identification
Control panel
7 T/P (traffic progra e/progra e type)
button
8 0 (eject) button
9 USB (Universal Serial Bus) input ter inal
p SRC (source) button
q (control panel release) button
w SEL (select) button
e MODE button
r Nu ber buttons
t 4/¢ buttons
How to detach/attach the control panel
Detaching... Attaching...
Lever CAUTION:
The lever co es out if you pressed the 0 button while
the panel is detached. If this happens, push the lever back
into lock position before attaching the panel.
EN02-05KD-G821[EX_EU]2.indd 4EN02-05KD-G821[EX_EU]2.indd 4 9/12/05 3:51:48 pm9/12/05 3:51:48 pm
ENGLISH
5
Remote controller — RM-RK50
Installing the lithium coin battery
( R2025)
Aim the remote controller directly at the
remote sensor on the unit. Make sure there is
no obstacle in between.
aution:
Main elements and features
1 (standby/on/attenuator) button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
2 5 U (up) / D (down) ∞ buttons
• Changes the FM/AM/DAB bands with 5 U.
• Changes the preset stations (or services)
with D ∞.
• Changes the folder of the MP3/WMA/
USB.
• While playing an MP3 disc on an
MP3-co patible CD changer:
– Changes the disc if pressed briefly.
– Changes the folder if pressed and held.
• While listening to an Apple iPod® or a
JVC D. player:
– Pauses/stops or resu es playback with
D ∞.
– Enters the ain enu with 5 U. (Now
5 U/D ∞/2 R/F 3 work as the enu
selecting buttons.)*
3 VOL – / VOL + buttons
• Adjusts the volu e level.
4 SOUND button
• Selects the sound ode (i-EQ: intelligent
equalizer).
* 5 U: Returns to the previous menu.
D ∞: Confirms the selection.
Warning:
• Do not install any battery other than
CR2025 or its equivalent; otherwise, it ay
explode.
• Store the battery in a place where children
cannot reach to avoid risk of accident.
• To prevent the battery fro over-heating,
cracking, or starting a fire:
– Do not recharge, short, disasse ble,
heat the battery, or dispose of it in a fire.
– Do not leave the battery with other
etallic aterials.
– Do not poke the battery with tweezers or
si ilar tools.
– Wrap the battery with tape and insulate
when throwing away or saving it.
Continued on next page...
EN02-05KD-G821[EX_EU]2.indd 5EN02-05KD-G821[EX_EU]2.indd 5 9/12/05 3:51:49 pm9/12/05 3:51:49 pm
6
ENGLISH
5 SOURCE button
• Selects the source.
6 2 R (reverse) / F (forward) 3 buttons
• Searches for stations (or services) if
pressed briefl .
• Searches for ensembles if pressed and
held.
• Fast-forwards or reverses the track if
pressed and held.
• Changes the tracks if pressed briefl .
• While listening to an iPod or a D. pla er
(in menu selecting mode):
– Selects an item if pressed briefl . (Then,
press D ∞ to confirm the selection.)
– Skips 10 items at a time if pressed and
held.
The unit is equipped with the steering wheel
remote control function.
• See the Installation/Connection Manual
(separate volume) for connection.
Getting started
Basic operations
~ Turn on the power.
Ÿ
* You cannot select these sources if they
are not ready or not connected.
!
• For FM/AM tuner
• For DAB tuner
⁄ Adjust the volume.
@ Adjust the sound as you want. (See
pages 17 19.)
To drop the volume in a moment (ATT)
To restore the sound, press it
again.
To turn off the power
Basic settings
• See also “General settings — PSM” on pages
19 – 22.
1
2-1 Canceling the display
demonstrations
Turn the control dial to set “Demo/Link”
to “Off.”
EN06-17KD-G821[EX_EU]2.indd 6EN06-17KD-G821[EX_EU]2.indd 6 9/12/05 3:58:16 pm9/12/05 3:58:16 pm
7
ENGLISH
2-2 Setting the clock
1 Press number button 4 ( ).
“Clock Hr” (hour) appears. Then,
turn the control dial to adjust the
hour.
2 Press ¢ to select “Clock Min”
(minute). Then, turn the control
dial to adjust the minute.
3 Press ¢ to select “ 4H/1 H.”
Then, turn the control dial to select
“ 4Hours” or “1 Hours,” time
display mode.
3 Exit from the setting.
To check the current clock time when the
power is turned off
Changing the display pattern
Ex.: When tuner is selected as the source
Source operation display
“SMALL” (CD jac et image) graphic*1 is displayed.
“LARGE” (full display size) graphic*1 is displayed.
Audio level meter is displayed (see “LevelMeter” on page 20).
Goes bac to the initial display pattern.
*1 You can use your edited file for graphic screen
(see pages 23 – 26).
Depending on a downloaded file, it may take
a longer time to show it on the display.
* he information bar will disappear if no
operation is performed for five seconds.
Radio operations
~
Ÿ
! Start searching for a station.
When a station is received, searching
stops.
• When receiving an FM stereo broadcast
with sufficient signal strength,
lights up on the display.
To stop searching, press the same button
again.
*
Continued on next page...
EN06-17KD-G821[EX_EU]f.indd 7EN06-17KD-G821[EX_EU]f.indd 7 21/12/05 5:36:32 pm21/12/05 5:36:32 pm
8
ENGLISH
To tune in to a station manually
In step ! on page 7...
1
2 Select a desired station frequency.
When an FM stereo broadcast is hard to
receive
1
2
3 Exit from the setting.
lights up on the display.
Reception improves, but stereo effect will
be lost.
To restore the stereo effect, select “Mono Off”
in step 2. goes off.
Storing stations in memory
ou can preset six stations for each band.
FM station automatic presetting —
SSM (Strong-station Sequential
Memory)
1 Select the FM band (FM1 – FM ) you
want to store into.
2
3 Select “SSM.”
4
Local FM stations with the strongest signals are
searched and stored automatically in the FM
band.
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset
number 4 of the FM1 band.
Using the number buttons
1
2
3
Using the reset Station List
• When appears on the display, you can
move back to the previous display by pressing
number button 3.
EN06-17KD-G821[EX_EU]f.indd 8EN06-17KD-G821[EX_EU]f.indd 8 22/12/05 6:55:16 pm22/12/05 6:55:16 pm
9
ENGLISH
Listening to a preset station
Using the number buttons
1
2 Select the preset station ( – 6) you
want to listen to.
Using the Preset Station List
1 Display the Preset Station List, then
select the preset station you want to
listen to.
2 Change to the selected station.
FM RDS operations
What you can do with RDS
RDS (Radio Data System) allows FM stations
to send an additional signal along with their
regular programme signals.
By receiving the RDS data, this unit can do the
following:
•
Programme Type (PTY) Search (see page 10)
• TA (Traffic Announcement) and PTY
Standby Receptions (see page 11)
•
Tracing the same programme automatically
—Network-Tracking Reception (see page 1 )
• Programme Search (see page 1)
1 Follow steps 1 and 2 of “Using the
number buttons” on page 8.
• By holding 5 / ∞, the Preset Station List
will appear (go to step 4).
2
3 Display the Preset Station List.
4 Select the preset number you want to
store into.
• You can move to the lists of the other FM
bands by pressing number button 5
() or 6 ( ) repeatedly.
5 Store the station.
Continued on next page...
EN06-17KD-G821[EX_EU]f.indd 9EN06-17KD-G821[EX_EU]f.indd 9 21/12/05 5:36:43 pm21/12/05 5:36:43 pm
10
ENGLISH
⁄ Start searching for your favorite
programme.
If there is a station broadcasting a
programme of the same PTY code as you
have selected, that station is tuned in.
Storing your favorite
programme types
You can store six favorite programme types.
• When appears on the display, you can
move back to the previous display by pressing
number button .
1
2 Select “Memory.”
3 Select a preset number (“Preset1”–
“Preset6”) you ant to store into.
4 Select one of the PTY codes.
Searching for your favorite
FM RDS programme
You can tune in to a station broadcasting your
favorite programme by searching for a PTY
code.
• When appears on the display, you can
move back to the previous display by pressing
number button .
~
Ÿ Select “Search.”
The PTY Preset List including six preset
PTY codes appears on the display.
! Select a PTY code (see page 12).
• You can select one from 5 PTY codes
including the first 6 preset codes
which can be preset as you like (see the
following).
• To display the other PTY Preset Lists,
press number button 5 ( ) or 6
() repeatedly.
EN06-17KD-G821[EX_EU]2.indd 10EN06-17KD-G821[EX_EU]2.indd 10 16/12/05 11:20:55 am16/12/05 11:20:55 am
Other manuals for KD-G821
4
Table of contents
Languages:
Other JVC Car Receiver manuals
