Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 R2 - LOG MANAGEMENT ADMINISTRATION GUIDE REV... User manual

Juniper Networks, Inc.

1194 North Mathilda Avenue

Sunnyvale, CA 94089

USA

408-745-2000

www.juniper.net

Part Number: 530-027301-01, Revision 1

Security Threat Response Manager

Managing Sensor Devices

Release 2008.2 R2

2

Networks Inc. in the United States and other countries. All other trademarks, service marks, registered trademarks, or registered service marks in this

document are the property of Juniper Networks or their respective owners. All specifications are subject to change without notice. Juniper Networks

assumes no responsibility for any inaccuracies in this document or for any obligation to update information in this document. Juniper Networks reserves

the right to change, modify, transfer, or otherwise revise this publication without notice.

FCC Statement

The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. The equipment generates, uses, and can radiate radio-frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. The following

information is for FCC compliance of Class B devices: The equipment described in this manual generates and may radiate radio-frequency energy. If it

is not installed in accordance with NetScreen’s installation instructions, it may cause interference with radio and television reception. This equipment has

been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in part 15 of the FCC rules. These

specifications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Consult the dealer or an experienced radio/TV

technician for help. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

Caution: Changes or modifications to this product could void the user's warranty and authority to operate this device.

Disclaimer

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET

THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE

SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR JUNIPER NETWORKS REPRESENTATIVE FOR A COPY.

Managing Sensor Devices

Release 2008.2 R2

Revision History

September 2008—Revision 1

The information in this document is current as of the date listed in the revision history.

CONTENTS

ABOUT THIS GUIDE

Conventions 1

Audience 1

Technical Documentation 1

Contacting Customer Support 2

1MANAGING SENSOR DEVICES

Configuring STRM Log Management to Receive Events 3

Managing Sensor Devices 4

Adding a Sensor Device 4

Editing Sensor Devices 6

Enabling/Disabling Sensor Devices 9

Deleting a Sensor Device 9

Configuring Protocols 10

Adding a Protocol 10

Editing a Protocol 17

Deleting a Protocol 17

Grouping Sensor Devices 18

Viewing Sensor Devices Using Groups 18

Creating a Group 18

Editing a Group 19

Copying a Sensor Device to Another Group 20

Removing a Sensor Device From a Group 20

2CREATING ADEVICE EXTENSION

About Device Extensions 23

Creating a Device Extension Document 24

Viewing Device Extensions 24

Adding a Device Extension 25

Editing a Device Extension 27

Copying a Device Extension 28

Deleting a Device Extension 29

Enabling/Disabling a Device Extension 30

Reporting a Device Extension 30

Managing Sensor Devices Guide

ABOUT THIS GUIDE

The Managing Sensor Devices Guide provides you with information for configuring

sensor devices (DSMs) in the STRM Log Management interface and integrating

the DSMs with STRM Log Management.

Conventions Table 1 lists conventions that are used throughout this guide.

Audience This guide is intended for the system administrator responsible for setting up

STRM Log Management in your network. This guide assumes that you have

STRM Log Management administrative access and a knowledge of your corporate

network and networking technologies.

Technical

Documentation

You can access technical documentation, technical notes, and release notes

directly from the Juniper Networks support web site at https://juniper.net/support.

Once you access the Juniper Networks support web site, locate the product and

software release for which you require documentation.

Your comments are important to us. Please send your e-mail comments about this

guide or any of the Juniper Networks documentation to:

documentation@juniper.net

Table 1 Icons

Icon Type Description

Information note Information that describes important features or

instructions.

Caution Information that alerts you to potential loss of data

or potential damage to an application, system,

device, or network.

Warning Information that alerts you to potential personal

injury.

Managing Sensor Devices Guide

2ABOUT THIS GUIDE

Include the following information with your comments:

•Document title

•Page number

Contacting

Customer Support

To help you resolve any issues that you may encounter when installing or

maintaining STRM Log Management, you can contact Customer Support as

follows:

•Log a support request 24/7: https://juniper.net/support/

For access to the Juniper Networks support web site, please contact Customer

Support.

•Access Juniper Networks support and Self-Service support using e-mail:

support@juniper.net

•Telephone assistance: 1-800-638-8296

Managing Sensor Devices Guide

1MANAGING SENSOR DEVICES

You can configure STRM Log Management to log and correlate events received

from external sources such as security equipment (for example, firewalls and

IDSs) and network equipment (for example, switches and routers). Sensor devices

allow you to integrate STRM Log Management with these external devices. This

chapter provides information on configuring sensor devices to the system

including:

•Configuring STRM Log Management to Receive Events

•Managing Sensor Devices

•Configuring Protocols

•Grouping Sensor Devices

Configuring STRM

Log Management to

Receive Events

STRM Log Management allows you to automatically discover sensor devices in

your deployment that are sending syslog messages. Any sensor devices that are

automatically discovered by STRM Log Management appear in the Sensor

Devices window. Automatic discovery of sensor devices can be configured on a

per Event Collector basis using the Auto Detection Enabled parameter in the Event

Collector configuration. For more information, see the STRM Log Management

Administration Guide, Using the Deployment Editor.

To configure STRM Log Management to receive events from devices, you must:

Step 1 Configure the device to send events to STRM Log Management.

For information on configuring DSMs, see the Configuring DSMs Guide and your

vendor documentation.

Step 2 Configure STRM Log Management to receive events from specific devices. See

Managing Sensor Devices.

Note: You must have administrative privileges to configure sensor devices in

STRM Log Management. For more information on accessing the Administration

Console, see the STRM Log Management Administration Guide.

Step 3 Configure the necessary protocols. See Configuring Protocols.

Managing Sensor Devices Guide

4MANAGING SENSOR DEVICES

Managing Sensor

Devices

A sensor device provides events to your deployment through DSMs. Using the

Administration Console, you can:

•Add a sensor device. See Adding a Sensor Device.

•Edit an existing sensor device. See Editing Sensor Devices.

•Enable or disable a sensor device. See Enabling/Disabling Sensor Devices.

•Delete a sensor device. See Deleting a Sensor Device.

Adding a Sensor

Device

To add a sensor device to your deployment:

Step 1 In the Administration Console, click the SIM Configuration tab.

The SIM Configuration panel appears.

Step 2 Click the Sensor Devices icon.

The Sensor Devices window appears.

Step 3 Click Add.

The Add a sensor device window appears.

Step 4 Enter values for the parameters:

Managing Sensor Devices Guide

Managing Sensor Devices 5

Table 1-1 Add a Sensor Device Parameters

Parameter Description

Device Name Specify the desired name of the device.

Sensor Device Type Using the drop-down list, select the type of sensor

device you wish to add.

Protocol Configuration Using the drop-down list box, select the protocol you

wish to use for this sensor device. If the device uses

syslog, a default syslog configuration is automatically

applied. For more information on configuring protocols,

see Adding a Protocol.

Device Description Specify a description for the sensor device (optional).

Device Hostname/IP Specify the hostname or IP address for the device. If

you wish to add the device using the hostname, please

note that you must enter the hostname as it exactly

appears in the logs sent to STRM Log Management.

Otherwise, STRM Log Management will not process

the events.

Credibility Specify the credibility of the device. The range is from 0

to 10. The credibility indicates the integrity of an event

or offense as determined by the credibility rating from

source devices. Credibility increases if multiple sources

report the same event. The default is 5.

Target Event Collector Using the drop-down list box, select the Event Collector

you wish to use as the target for this device.

Coalescing Events Enables or disables the ability of a sensor device to

coalesce (bundle) events. The default is Yes.

By default, all auto detected sensor devices use the

value configured in the Coalescing Events parameter in

the STRM Settings window. However, when you create

a new sensor device or update the configuration for an

auto detected sensor device, the value configured in

the individual sensor device is the value used by the

sensor device. For more information, see the STRM

Log Management Administration Guide.

Store Event Payload Enables or disables the ability for a sensor device to

store event payload information. The default is Yes.

By default, all auto detected sensor devices use the

value configured in the Store Event Payload parameter

in the STRM Settings window. However, when you

create a new sensor device or update the configuration

for an auto detected sensor device, the value

configured in the individual sensor device is the value

used by the sensor device. For more information, see

the STRM Log Management Administration Guide.

Managing Sensor Devices Guide

6MANAGING SENSOR DEVICES

Step 5 Click Save.

The Sensor Devices window appears.

Editing Sensor

Devices

To edit a sensor device:

Step 1 In the Administration Console, click the SIM Configuration tab.

The SIM Configuration panel appears.

Step 2 Click the Sensor Devices icon.

The Sensor Devices window appears.

Step 3 Select the sensor device you wish to edit.

Step 4 Click Edit.

The Edit a sensor device window appears.

Device Extension Using the drop-down list box, select the device

extension you wish to use for this sensor device.

Device extensions allow you to immediately extend the

parsing routines of specific devices, which ensures

DSMs send valid data to STRM.

For more information on device extensions, see

Creating a Device Extension.

Extension Use Condition Using the drop-down list box, select the extension use

condition that you wish to use for this sensor device:

•Parsing Enhancement - When the DSM is unable

to parse correctly or is unable to retrieve specific

information from the DSM, the selected device

extension overrides the failed parsing by the DSM.

This is the default setting.

•Parsing Override - When the DSM parses correctly

for most fields, but needs either one or two fields

corrected, the incorrectly parsed field values are

enhanced.

Groups Select any groups of which you wish this sensor device

to be a member.

Table 1-1 Add a Sensor Device Parameters

Parameter Description

Other manuals for SECURITY THREAT RESPONSE MANAGER 2008.2 R2 - LOG MANAGEMENT ADMINISTRATION GUIDE REV...

This manual suits for next models

Table of contents

Other Juniper Software manuals

Juniper

Juniper JUNOSE 11.1.X - LINK LAYER CONFIGURATION... User manual

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.3 - M-SERIES AND MX-SERIES DEVICES GUIDE... User manual

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.4 - M-SERIES AND MX-SERIES DEVICES GUIDE REV... User manual

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 - CATEGORY OFFENSE INVESTIGATION GUIDE REV... User manual

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.3 - CONFIGURING INTRUSION DETECTION AND PREVENTION GUIDE... User manual

Juniper

Juniper JUNOSE SOFTWARE 11.2.X - BROADBAND ACCESS CONFIGURATION GUIDE... User manual

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - POLICY MANAGEMENT CONFIGURATION GUIDE... User manual

Juniper

Juniper JUNOS OS 10.4 - S REV 5 Instruction Manual

Juniper

Juniper JUNOSE 11.1.X - COMMAND REFERENCE A TO M... Installation manual

Juniper

Juniper JUNOS SPACE 2.0 - RELEASE NOTES User manual

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - S... Instruction Manual

Juniper

Juniper NETWORK AND SECURITY MANAGER 2010.4 - ADMININISTRATION GUIDE... Instruction Manual

Juniper

Juniper JUNIPER CARE PLUS SERVICES User manual

Juniper

Juniper JUNOS OS 10.4 - FOR EX REV 1 User manual

Juniper

Juniper JUNOSE SOFTWARE 10.2.2 - S 6-4-2010 Instruction Manual

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 R2 - INSTALLATION... User manual

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - POLICY MANAGEMENT CONFIGURATION GUIDE... User manual

Juniper

Juniper TEPM AGENT - RELEASE NOTES 17-12-10 Instruction Manual

Juniper

Juniper NETWORK AND SECURITY MANAGER NSM3000 - REV... User manual

Juniper

Juniper JUNOSE SOFTWARE 11.2.X - LINK LAYER CONFIGURATION GUIDE... User manual

Juniper

Juniper SECURITY THREAT RESPONSE MANAGER 2008.2 - ADAPTIVE LOG EXPORTER... User manual

Juniper

Juniper JUNOSE 11.0.2 RELEASE NOTES Instruction Manual

Juniper

Juniper STRM 2008.2R2 - UPGRADING TO STRM 2008.2R2 REV... Installation and operation manual

Juniper

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - PHYSICAL LAYER CONFIGURATION GUIDE... User manual

Popular Software manuals by other brands

COMPRO

COMPRO COMPROFM manual

Muratec

Muratec OFFICEBRIDGE ONLINE user guide

Oracle

Oracle Contact Center Anywhere 8.1 installation guide

Adobe

Adobe 65007312 - Photoshop Lightroom Programmer's guide

Avaya

Avaya NULL One-X for RIM Blackberry user guide

HP ProLiant BL420c user guide

PS Audio

PS Audio PowerPlay Programming manual

Brady

Brady LOCKOUT PRO 3.0 Administrator's guide

Avaya

Avaya Interaction Center user guide

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Guide book

Novell

Novell GROUPWISE 8 - INTERNET AGENT manual

Oracle

Oracle Application 9i Configuration guide

Acer

Acer RDM user guide

Canon

Canon Vixia HF21 instruction manual

Canon

Canon ZR950 instruction manual

Samsung

Samsung Auto Backup user manual

Polycom

Polycom Vortex EF2201 Application note

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c user manual
