Johnson 40-0915 User manual

Magnetic Torpedo Laser Level

Model No. 40-0915

Instruction Manual

Congratulations on your choice of this Magnetic Torpedo Laser Level.

We suggest you read this instruction manual thoroughly before using

the instrument. Save this instruction manual for future use.

This is a Class IIIa laser tool and is manufactured to comply

with CFR 21, parts 1040.10 and 1040.11 as well as international

safety rule IEC 285.

7523H-English_Manuals 11/19/13 8:34 AM Page 1

able of Contents

1. Kit Contents

2. Features and Functions

3. Safety Instructions

4. ocation/Content

of Warning abels

5. ocation of Parts/Components

6. Using the Product

7. Technical Specifications

8. Application Demonstrations

9. Care and Handling

10. Product Warranty

1. Kit Contents

Description for Model 40-0915 Qty.

Magnetic Torpedo aser evel 1

“AAA” Alkaline Batteries 2

Instruction Manual 1

2. Features and Functions

• Able to project laser point

• Able to project a horizontal laser line

• Able to project a vertical laser line

• Magnetic bottom allows unit to be attached to metal

3. Safety Instructions

Please read and understand all of the following instructions, prior

to using this tool. Failure to do so, may void the warranty.

7523H-English_Manuals 11/19/13 8:34 AM Page 2

DANGER!

Class IIIa aser Product

Max. Power Output: ≤5mW

Wavelength: 640-660nm

HIS OOL EMI S LASER RADIA ION.

DO NO S ARE IN O BEAM.

AVOID DIREC EYE EXPOSURE.

ATTENTION IMPORTANT

• Read all instructions prior to operating this laser tool. Do not remove any labels from tool.

• Do not stare directly at the laser beam.

• Do not project the laser beam directly into the eyes of others.

• Do not set up laser tool at eye level or operate the tool near a reflective surface as

the laser beam could be projected into your eyes or into the eyes of others.

• Do not place the laser tool in a manner that may cause someone to unintentionally

look into the laser beam. Serious eye injury may result.

• Do not operate the tool in explosive environments, i.e. in the presence of gases or

flammable liquids.

• Keep the laser tool out of the reach of children and other untrained persons.

• Do not attempt to view the laser beam through optical tools such as telescopes as

serious eye injury may result.

• Always turn the laser tool off when not in use or left unattended for a period of time.

• Remove the batteries when storing the tool for an extended time (more than 3 months)

to avoid damage to the tool should the batteries deteriorate.

• Do not attempt to repair or disassemble the laser tool. If unqualified persons attempt

to repair this tool, warranty will be void.

• Use only original Johnson

parts and accessories purchased from your Johnson

authorized dealer. Use of non-Johnson

parts and accessories will void warranty.

7523H-English_Manuals 11/19/13 8:34 AM Page 3

4. Location/Content of Warning Labels

7523H-English_Manuals 11/19/13 8:34 AM Page 4

5. Location of Part/Components

Power Switch

Cross

Check Vial

Rotating/Head Pivot

Horizontal Bubble

Vertical

Bubble

Front Foot

Rear Foot

Rear eveling

Foot Adjustment

Battery Compartment

Magnet

7523H-English_Manuals 11/19/13 8:34 AM Page 5

6. Using the Product

Battery Installation

Remove battery door on side of unit, and put in two alkaline “AAA”

batteries according to the illustrated polarity requirements, on the

battery cover door. Replace the battery door.

Note: Used (discharged) batteries are hazardous waste and should be

disposed of properly.

Power On/Off

1. Press power switch to project laser line or point.

2. Press power switch again to shut off laser output.

Switch Between Laser Point

and Laser Line

1. Rotate the head to switch between laser

line and laser point. Rotating the head up or

down converts laser from a dot to a line, or

line to a dot. Rotating the conversion head

lens counter-clockwise, while in line mode,

rotates line from horizontal to vertical. Rotate to switch

between point

and line

7523H-English_Manuals 11/19/13 8:34 AM Page 6

Note: The rotating head can only be turned

in the direction indicated by arrow.

7. echnical Specifications

aser Wavelength 650nm ± 10

aser Classification Class IIIa

Maximum Power Output ≤5mW

Accuracy ± 3/8"/50 ft. (±0.5mm/m)

Interior Range Up to 100 ft. (30m) depending upon

light conditions

Power Supply 2 “AAA” alkaline batteries (included)

Battery ife Approx. battery life 70 hours

continuous use

Dimensions 2" x 7" x 0.875"

(51 x 177 x 22mm)

Weight 0.3 lbs. (0.14 kg)

Working Temperature 14°F to 113°F (-10°C to +45°C)

Rotating Direction

Arrow

Conversion

Head

Rotatable Line Status

7523H-English_Manuals 11/19/13 8:34 AM Page 7

8. Application Demonstrations

Projects one laser point

Projects one horizontal laser line

Projects one vertical laser line

7523H-English_Manuals 11/19/13 8:34 AM Page 8

9. Care and Handling

•This laser unit is a precision tool that must be handled with care.

•Avoid exposing unit to shock vibrations and extreme temperatures.

•Before moving or transporting the unit, make sure that the unit

is turned off.

•Remove the batteries when storing the unit for an extended time

(more than three months) to avoid damage to the unit should

the batteries deteriorate.

•Avoid getting the unit wet.

•Keep the laser unit dry and clean, especially the laser output

window. Remove any moisture or dirt with a soft, dry cloth.

•Do not use harsh chemicals, strong detergents or cleaning solvents

to clean the laser unit.

7523H-English_Manuals 11/19/13 8:34 AM Page 9

10. Product Warranty

Johnson evel & Tool offers a three year limited warranty on each of its

products. You can obtain a copy of the limited warranty for a Johnson

evel & Tool product by contacting Johnson evel & Tool's Customer

Service Department, as provided below, or by visiting our web site at

www.johnsonlevel.com. The limited warranty for each product

contains various limitations and exclusions.

Do not return this product to the store/retailer or place of purchase.

Non-warranty repairs and course calibration must be done by an

authorized Johnson®service center or Johnson evel & Tool's limited

warranty, if applicable, will be void and there will be NO WARRANTY.

Contact one of our service centers for all non-warranty repairs.

A list of service centers can be found on our web site at

www.johnsonlevel.com or by calling our Customer Service

Department. Contact our Customer Service Department for Return

Material Authorization (RMA) for warranty repairs (manufacturing

defects only). Proof of purchase is required.

NO E: The user is responsible for the proper use and care of the prod-

uct. It is the responsibility of the user to verify the calibration of the instru-

ment before each use.

For further assistance, or if you experience problems with this product

that are not addressed in this instruction manual, please contact our

Customer Service Dept.

In the U.S., contact Johnson evel & Tool’s Customer Service

Department at 888-9- EVE S.

In Canada, contact Johnson evel & Tool’s Customer Service

Department at 800-346-6682.

7523H-English_Manuals 11/19/13 8:34 AM Page 10
