Jensen VM9115 User manual

VM9115

Operating Instructions

160

watts peak

40W x 4

VM9115

Thank you for choosing a Jensen product. We hope you will nd the instructions

in this owner’s manual clear and easy to follow. If you take a few minutes to look

through it, you’ll learn how to use all the features of your new Jensen VM9115

Mobile Multimedia Receiver for maximum enjoyment.

CONTENTS

Features ...............................................................................................................3

Controls and Indicators ......................................................................................6

Using the TFT Monitor ........................................................................................5

Operating Instructions .......................................................................................10

Settings Menu .....................................................................................................16

Tuner Operation .................................................................................................24

DVD/VCD Video Operation ................................................................................30

DVD/CD Audio Operation ..................................................................................36

MP3/WMA Operation .........................................................................................40

iPod® Operation ..................................................................................................47

Rear Camera Operation ......................................................................................51

Troubleshooting .................................................................................................42

Care and Maintenance .......................................................................................56

Specications ......................................................................................................57

Common Replacement Parts .............................................................................59

VM9115

FEATURES

Congratulations on your purchase of the Jensen VM9115 Mobile Multimedia

Receiver. It’s a good idea to read all of the instructions before beginning the

installation. We recommend having your Jensen VM9115 installed by a reputable

installation shop.

DVD

• Fast Forward/Reverse - 2X, 4X, 8X, and 20X

• Slow Motion Forward/Reverse - 1/2, 1/4, 1/6, and 1/8

• Play, Pause, Stop, Next Chapter, and Previous Chapter

CD / MP3 / WMA

• CD-Text Compatible

• ID3 Tag Compatible

• Directory Search (MP3 / WMA Only)

• Burn up to 1500 MP3, and WMA Files onto a DVD+R / RW

• Audible Forward / Reverse Track Search (CD-DA Only)

• Random, Repeat, and Intro

• Play, Pause, Stop, Next Track, and Previous Track

AM-FM

• USA / Europe / Latin America / Asia Frequency Spacing

• 30 Station Presets (18 FM / 12 AM)

• Auto Stereo / Mono•Local / Distance

• Auto Store / Preview Scan

Chassis

• 1.0 DIN (Import / ISO-DIN Mountable)

• Motorized Flip-Out / Flip-Up TFT Screen

• 7” TFT Active Matrix TFT

• 336,960 Sub Pixels (1440W X 234H)

• Screen Tilt / Angle Adjustment

• Beep Tone Conrmation (ON-OFF Option)

• Heat Management System - Forced Air-Cooling To Keep The Chip-Sets Operating

at Nominal Temperatures

General

• Front Panel Audio/Video Input

• Three-Band Tone control (Bass, Mid and Treble) with Eight Preset EQ Curves

• Front Panel A/V Aux Input for Portable Media Devices

• Rear Line Output

• Programmable Volume Control

• Touch Screen Calibration Mode

VM9115

iPod®/iPhone®

• iPod®/ iPhone© via USB

• High Speed Direct Connect Interface to Access iPod® Playlists, Artists, Albums

and Songs. Play music and view video/photo* les from your iPod.*

Video/photo playback requires jLink-USB iPod® interface cable (sold separately).

• Power Management Charges iPod® while connected.

Rear Camera

• The VM9115 is “camera ready.” Before accessing any camera features, you must

purchase and install a rear video camera. Once the rear camera is connected and

operating properly, the CAMERA source mode will become active.

VM9115

WARNING! Never install this unit where operation and viewing could interfere

with safe driving conditions.

WARNING! To reduce the risk of a trac accident (except when using for rear

view video camera) never use the video display function while driving the

vehicle. This is a violation of federal law.

WARNING! Never disassemble or adjust the unit.

WARNING! To prevent injury from shock or re, never expose this unit to

moisture or water.

WARNING! Never use irregular discs.

WARNING! To prevent damage to the mechanism inside this unit, avoid impact to

the TFT monitor.

WARNING! The monitor employs an automatic motorized mechanism. To prevent

damage to the core mechanism, please do not push, pull or swivel the monitor

manually.

VM9115

CONTROLS AND INDICATORS

1. CLOSE/OPEN

Press to activate the automatic mechanical system and move the TFT monitor

into the viewing position. Press again to close the TFT.

2. PIC/BAND

With the monitor open, press PIC to adjust the Brightness and Contrast (see

“Image/Display Settings”).

With the monitor closed, press BAND to change between three FM and two

AM bands.

3. TFT Display

4. WIDE/

With the monitor open, press WIDE to adjust the display aspect of the picture

to one of two settings: Full or STANDBY.

With the monitor closed, press to seek backward.

5. TILT/

With the monitor open, press TILT to activate the tilt function. Use the rotary

encoder to make adjustments while the blue tilt icon is ashing.

With the monitor closed, press to seek forward.

6. EJECT

Press to eject a disc. Press and hold to reset the core mechanism position.

7. USB Interface Cover

Covers the USB interface connector. Open the cover and insert a USB device

for playback of music/video les.

8. A/V Input

Attach a compatible A/V device.

9. DISC SLOT

10. LCD Display

11. / SRC

Press to turn the unit on. Press and hold to turn the unit o. When on, press

once to select the playing mode.

12. Rotary Encoder

Rotate to adjust the volume. Press to activate the MUTE function and silence

the receiver. Press again to resume sound.

While in tuner mode, press and hold to activate the LOC feature. Repeat to

deactivate.

13. RESET

Press to reset the system settings to factory default (except the password and

parental lock setting).

14. DISP

With the monitor open, during DVD playback, press once to view Time, Title,

Chapter info or twice for Audio, Subtitle, Angle, and Bit rate info.

With the monitor closed, press to view alternate LCD display information.

VM9115

14 11

12 6

1245

A/V

INPUT

TILT

PIC WIDE

VM9115

SRC

VM9115

USING THE TFT MONITOR

Opening/Closing the TFT Monitor

Open TFT Monitor

Press the OPEN button on the front panel to activate the mechanism that moves

the display panel into the viewing position.

Close TFT Monitor

Press the OPEN button on the front panel to load the display panel back into the

compartment.

TFT Monitor Auto Open

• If “TFT Auto Open” is “on” when the unit is turned on, the monitor automatically

moves to the viewing position.

• If “TFT Auto Open” is “o” when the unit is turned on, press the OPEN button to

move the monitor into the viewing position.

• If “TFT Auto Open” is set to “Manual”, the TFT will not close when the key is

turned o.

Monitor Tilt Angle Adjustment

A known characteristic of TFT panels is the quality of the display in relationship to

the viewing angle. The adjust the monitor angle optimum viewing:

1. Press the TILT button on the unit.

2. While the blue tilt icon is ashing, turn the rotary encoder to adjust the screen

angle.

VM9115

Monitor Movement Mechanism

If an obstruction occurs in the monitor path, the following protective measures

can be executed to prevent damage to the mechanism or monitor:

Table 1: Monitor Protective Measures

Obstruction Self Protection OPEN Button

Pressed

Power

Reconnected

Monitor loading

out horizontally

Monitor is

automatically

loaded into unit

Monitor fully

extended

horizontally

Monitor is

automatically

loaded into unit

Monitor loading in

horizontally

Unit stops at

obstruction point

Monitor fully

extended

horizontally

Monitor is

automatically

loaded into unit

Monitor loading

out vertically

Unit stops at

obstruction point

Monitor swivels

back to the unit

Monitor swivels

back to the unit

Monitor loading in

vertically

Unit stops at

obstruction point

Monitor swivels

back to the unit

Monitor swivels

back to the unit

After the protective procedure is executed, normal operation is resumed by

pressing the OPEN button or disconnecting and reconnecting the power.

TFT Aspect Ratio

With the monitor open, press and hold the WIDE button on the monitor to adjust

the aspect ratio as follows:

FULL

The entire screen is extended horizontally to the aspect ratio of 16 to 9. The

extension ratio is the same at any point.

STANDBY

The screen becomes black. Touch the screen to resume.

VM9115

OPERATING INSTRUCTIONS

Power On / O

Press the /SRC button on the unit to turn the unit on. You can also turn on the

unit by pressing the OPEN button and opening the TFT screen.

Press and hold the /SRC button to power o the unit. The monitor is drawn

back into the main compartment.

Audible Beep Conrmation

An audible beep tone conrms each function selection. The Beep tone can be

disabled through the Setup menu.

Mute/Line Mute

Press the rotary encoder MUTE button on the front panel to mute the volume.

Press the rotary encoder button again to restore the volume. Adjusting the

volume or using any of the audio setup features cancels the mute function.

Playing Source Selection

When the monitor is closed, press the SRC button to change between available

audio playing sources in the following order: RADIO, DISC, USB, and AUX IN. The

mode is displayed on the LCD display.

Source Menu

You can also use the touch screen to change the source through the SOURCE

MENU. To access the SOURCE MENU, touch the top left corner of the screen or

press the SRC button on the front panel.

Touch the Disc, Radio, USB, Aux In, Camera or Settings button to select the

corresponding source.

NOTE: If an iPod® is attached to a USB port, “IPOD” appears instead of the text

“USB.”
