Jenn-Air JDR8880RDB10 User manual

COOKTOP PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

11−11 Litho in U.S.A. (amd) (eeb) Part No. W10141329 Rev. B

30" FREE STANDING

DUAL FUEL

CONVECTION RANGE

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8113P622−60

Manual, Owners

8119P367−60

Wiring Diagram

2 Grate, Double

74009143 Black

74009145 Gray

3 Cap, Burner

74007414 Black, (LF)

74007416 Black,(LR)

74007925 Black,Medium (3)

74007420 Gray,(RF)

74007422 Gray,(LR)

74007752 Gray,Medium (3)

4 Base, Burner

74007411 5K, Center (1)

74007413 16K, RF

74007698 12K,9.2K (3)

5 Panel, Manifold

74009138 Black

74009139 White

74009146 Stainless

6 74009147 Knob, Valve

7 Cooktop

74009086 Black

74009087 White

CONTROL PANEL PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

W10141329

Illus. Part

No. No. DESCRIPTION

1 End Cap

74009022 Black (Right)

74009023 Black (Left)

8507P333−60

Control

3 Backgaurd Assy.

74011912 Black

74011913 Stainless

74011914 White

4 Sheild, Heat Visor

74009202 Black

74009203 White

5 74010983 Cover, Rear Wire

6 74001530 Screw

7 74009444 Shield, Vent

8 74011982 Bracket, Control

OVEN PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

W10141329

OVEN PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

W10141329

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Panel, Side

74008709 White

74009710 Black

2 74008701 Retainer, Side

3 74011910 Element, Broil

4 12001656 Oven Sensor

5 74001530 Screw

6 74011177 Fan Assy. Convect

7 74005401 Screw

8 47005783 Cover, Convection

9 74008695 Support, Oven

7406P456−60

Element, Bake

740086960

Gasket

12 74008763 Rack, Oven

13 74009651 Cover, Main Wire

8026P090−60

Smoke Eliminator

15 74008798 Screw, Shoulder #8

16 74008690 Spacer, Side Panel

17 74011896 Latch, Door Lock

18 74011278 Light, Oven

7407P103−60

Bulb, Oven Light

20 74008687 Runner, Drawer

21 74004078 Roller, Drawer

22 74005231 Shaft, Drawer

23 74008762 Bottom, Wire Cover

24 74008699 Back, Main

25 74010551 Receiver, Hinge

26 74003976 Screw, Shoulder

27 74008694 Support, Oven

28 74008741 Bottom, Oven

29 74005564 Anti−Tip Bracket

30 74002373 Leg, Leveling

31 74008688 Stop, Drawer

32 74006398 Cord, Power

33 74008715 Switch, Limit

34 74008340 Panel, Access

35 74008760 Cover, Wire Lower

3605F146−51

Plate, Conduit

7103P027−60

Nut,Terminal Block

7401P039−60

Block, Terminal

Following Parts Not Illustrated

5171P790−60

Harness, Main

5171P839−60

Harness, Ignition

7509P115−60

Kit,

LP Conversion

12500100 Kit, Broiler Pan

MANIFOLD PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

W10141329

Illus. Part

No. No. DESCRIPTION

1 74009098 Module, Spark

2 74008815 Pipe, Manifold

3 Valve, Burner

74010629 5K Copreci (1)

74010751 16K Copreci (1)

74010752 12K Copreci (3)

4 74010753 Harness, Switch

5 Orifice Holder

74009099 RF

74009100 RR

7527P097−60

Center

7527P100−60

7527P101−60

6 74009958 Ignitor,Top Burner

7506P519−60

Tubing, Supply

8 74005560 Regulator

DRAWER PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

W10141329

Illus. Part

No. No. DESCRIPTION

1 74005546 Spacer, Rubber

2 74008877 Drawer, Service

3 74009105 Sheild, Heat

4 74009268 Screw

5 74008908 Handle, Drawer

7103P082−60

Nut

7 74005231 Shaft, Roller

8 74004078 Roller, Drawer

7101P072−60

Screw

10 Panel, Drawer

74008856 White

74009035 Black

11 74009518 Panel, Drawer

(Stainless Models)

DOOR PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

W10141329

DOOR PARTS

For Models: JDR8880RDB10, JDR8880RDW10, JDR8880RDS10

(Black) (White) (Stainless)

W10141329

Illus. Part

No. No. DESCRIPTION

7902P805−60

Glass, Outer

2 311426 Nut

3 74008914 Spacer, Handle

7760P218−60

Panel, (Stainless)

5 74008920 Handle, Door

6 Trim, Side

74010560 Black

74010561 White

7 Glass, Door

74008684 White

74008686 Black

8 Trim, Bottom

74008757 White

74008889 Black

9 Tape,Double Sided

74009014 White

74009025 Black

3801F918−51

Bracket, Glass

(Stainless Models)

7002P482−60

Insulation, Foil

12 74008916 Gasket, Window

13 74008926 Liner, Door

14 74003645 Glass, Inner

3601F380−51

Baffle, Door

(Stainless Models)

16 Trim, Top

74008747 White

74008890 Black

7002P484−60

Insulation, Door

18 Bracket, Handle

74009412 Left

74009413S

Right

19 74004224 Tape

8270P090−60

Tape, Foil 3"

7101P282−60

Screw

22 74010546 Hinge, Door

23 74011458 Bracket, Glass

24 74003647 Insulation, Door

This manual suits for next models
