CSMA 1120

ApplicAtion Guide

mixer-Amplifiers

coffee shop

ON SAB

ON SAB

CD /OPTICAL

SPK 1 + 2 VIRTUAL

CSR-V

Speakers

Music

Input

Wireless Mic.

Standard Features

• Fanless,space-saving1Udesign

• Iluminatedringsmakethem

easytoseeandoperate

• Euro-blocktypemic/lineinput

connectorsandoutputconnectors

• Independentbassandtreblecontrols

foreachoutputchannel

• Supports70Vand100Vdistributed

audiosystemswithoutneeding

aseparatetransformer

• RemotevolumecontrolcapabilityusingJBL

CSR-VmoduleandstandardEhternetcable

• Prioritymuting

• Phantompower

• UniversalpowersupplyaceptsAC

voltagesfrom100to240VAC,50/0Hz.

• Three-year,no-faultfullytransferablewarranty

Idealforcommercialandindustrialuse,ournewlineoflightweightmixer-ampsleverageCrown’shigh-efciencyDriveCore™

TechnologyandHARMAN’sGreenEdge™environmentally-consciousmanufacturing–sotheyquicklypayforthemselves

inenergysavings.Withasleekindustriallookandacleanfrontpanelfeaturingonlyvolumecontrolsforeachchannel,they

offeryouaneasy-to-useprofessionaltoolwithuncompromisedperformance.

Quantity Model Brand

Mixer-Amplier

1 CSMA1120 JBLCommercial

Speakers6-8”

98008*/8128**/

CNTRL26CT JBLCommercial/JBL

MountingHardware

(onlyrequiredwith

8008and8128)

**MTC-8128C

**MEC-RAIL

*CSSBB4x6

*CSSBB8x6

*CSS-TR4/8x12

JBLCommercial/JBL

WirelessMicrophone

1 WM40miniorWMS470 AKG

*/** suggested product combinations/system bundles

Speaker

Mixer/Amplier

WirelessMicrophone

CSR-V

SatelliteMusicReceiver

Z2

ApplicAtion Guide

mixer-Amplifiers

coffee shop

jblcommercialproducts.com ©2013HARMAN.Allrightsreserved.
