Jacuzzi EN27 Series User manual
6Proper Removal from the Pool
a) b)
Activate the Lift System.
Remove the cleaner from the pool
using the handle.Never lift the
cleaner out of the pool by the
fl oating cable.
c) d)
QUICK START GUIDE
TYPE EN27--
TYPE EN37--
This Quick Start Guide contains essential installation and
startup instructions. For additional operation, maintenance and
troubleshooting instructions, please refer to the complete Owner’s
Manual. Read the complete manual and all safety warnings
before commencing installation.
www.jacuzzipool.com
www.jacuzzipool.com
© 2020 Jacuzzi Inc. All rights reserved.
Jacuzzi®is a registered trademark of Jacuzzi Inc.All other brands, product names, company
names, trade names and trademarks used are the property of their respective owners.
Jacuzzi may add to change or remove any part of these materials at any time, without
notice. Reproduction in whole or inpart without written permission is prohibited.
International products may be configured differently to meet local electrical requirements.
Dimensions are approximate.
Press the Start/Stop
button to begin cleaning. Read the complete manual
for additional information.
Start Cleaning
5
Unplug & Untangle.
Clean the Filter Canister.
H0722100_REVA
• Never turn on the cleaner unless it is
fully submerged in the water. Doing
so will void the warranty and may
cause severe damage to the cleaner
motors.
• Do not use an extension cord to
connect the control unit.
• Ensure that children do not attempt
to access the cleaner while in
operation.
Connect Floating Cable
2
Submerge Cleaner in Pool
3
a)
b)
Never swim with the
cleaner in the pool.
Recommended entry
point in the pool
Hold the handle and
submerge in pool
a)
b) Wait for bubbles to stop
completely, then let the
cleaner sink to the bottom
of the pool.
"CLICK"
"CLICK"
"CLICK"
"CLICK"
"Click"
1full caddy assembly
instructions found
separately
GFCI
120V
5 ft. (1.5m) US
3m (10ft) Canada
c) For optimal patterning and reduced cord
tangling, submerge the cleaner at the
recommended entry point in the pool.
Spread all of the length of cable out over the
pool to avoid tangling and ensure adequate
coverage.
4Control Box Buttons
Start/Stop
cleaning
Select cleaning
mode
Remove cleaner
from the pool
