Jacuzzi Real Salon DT00 User manual

Imagine the essence of centuries of

opulence, captured for a lap-of-luxury

experience all your own. Our Reál®

whirlpool delivers magniﬁcence,

beautifully, functionally with an

embracing hourglass shape.

features:

• Multi-speed motor

• 4 fully adjustable PowerPro® jets

• 4 rotating neck jets

• 2 directionally adjustable foot jets

• Sculpted armrests

• 900 watt variable speed heated air blower

• Bottom air channels for maximum massage

• 256 color Chromatherapy lighting system

• All-in-one electronic control panel

• Drain-assist purge system

• RapidHeat™ inline heater

• PrO

™

Ozone Sanitation System standard

réal® salon™ spa

model number: DT00

exterior dimensions:

72" long x 42" wide x 26" high

interior dimensions:

45" long x 24" wide

# of Jets/type of Jets:

4 PowerPro®Jets

4 AccuPro™ Rotating Neck Jets

2 AccuPro™ Foot Jets

operating gallons:

90 gallons

réal®salon™ spa

royal. kingly. réal, to the Spanish. a truly regal experience in contoured elegance—time-honored styling, gentle curves.

Detail: Softly curving lines and sculpted armrests make

the Réal®whirlpool bath a beautiful place to relax

and revitalize. Jacuzzi’s exclusive Magic Touch™ control

system puts a customized bath right at your ﬁngertips.

Real®

Salon™ Spa

Model: DT00

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Ordering Information

Product Code:

DT00 Real™ Salon™ Spa

Right Hand

• Center Drain Location

• Accessories / Hardware:

Rotary Drain Kit, 30” Cable #K606

Trim Kit: 2 BMH Jet Rings #J869

2 X Trim Kit: 2 Neck Jet Rings #P556

Trim Kit: 4 HTA Jet Rings, 3 Control Panel

overlays #P205

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(849) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

72” L x 42” W x 26” H

(1829 mm) L x (1067 mm) W x (660 mm) H

Drain/Overﬂow

A: 20 “ (508 mm) B: 14” (356 mm)

Cutout

70” (1778 mm) x 40” (1016 mm)

Total Weight

1230 lb (558 kg) / 59 lb/ft2(287 kg/m2)

Operating Gallonage

90 U.S. Gal. (341Liters)

Product Weight

179 lb (81 kg)

Skirt Mounting

Not Available

Electrical Speciﬁcations

Requires a dedicated GFCI protected separate circuit.

Blower: 120VAC, 20AMP, 60 Hz.

Motor/Pump and RapidHeat™: 240VAC, 20AMP, 60 Hz.

Heater (Standard)

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N BN60000

† Add 1/4” to this dimension when roughing-in for 3-wall niche.

10-1/2"

36"

14"

5-1/4"

42"

72"

Moto

12" H x 24" L

Service Access

Heater

Blower

18" x 4"*

END VIEW

25"

SIDE VIEW

72"

(51 mm)

(Inlet Heater)

(Motor) (Blower)

# FS08 12/06

DRAIN/OVERFLOW

Product Shown: Real™ Salon™ Spa Right Hand Shown Model: DT00

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
