Jacuzzi Amiga BE30-LH User manual

amiga™ pure air®ll bath

Your best friend at the end of any long

day, the Amiga™ surrounds you with a

simple, enveloping form.

features:

• Exclusive 360º Balanced Airﬂow™ system

• 600 watt variable speed heated air blower

• Thermal Lumbar Comfort (TLC) ™

• Timed purge cycle

• Safely use salts and aromatic oils

• PrO

™

Ozone Sanitation System standard

amiga™ pure air®ll bath

model number: BE30 – LH

exterior dimensions:

72" long x 36" wide x 20¾" high

interior dimensions:

45" long x 22" wide

operating gallons:

53 gallons

like any good friend—any good “amiga”—the amiga™ pure air®ll bath is versatile and accommodating. a pure pleasure.

Detail: The Amiga™ Pure Air® ll bath features

the electronic Wave Pulse™ control system, and

Jacuzzi’s exclusive Thermal Lumbar Comfort

system—an extra ridge of air channels that deliver

a soothing, warming lower back massage.

Amiga™ Pure Air II™ Bath

Model: BE30

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Ordering Information

Product Code:

BE30 Amiga™ Pure Air® II Bath

Left Hand

• Accessories / Hardware:

Trim Kit Rotary: #BN21

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(845) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

72” L x 36” W x 20-3/4” H

(1829 mm) L x (914 mm) W x (527 mm) H

Drain/Overﬂow

A: 16-7/8” (429 mm) B: 14” (356 mm)

Cutout

70” x 34”

Total Weight

791 lb (359 kg) / 44 lb/sq. ft. (215 kg/m2)

Operating Gallonage

53 U.S. Gal. (201 Liters)

Product Weight

100 lb (45 kg)

Skirt Mounting

Optional U-Frame

Electrical Speciﬁcations

Requires a dedicated GFCI protected separate circuit.

Blower: 120 VAC, 15 AMP, 60 Hz.

Heater

No water heater is available on this unit. Blower has integral air heater.

72''

18''

36''

2''

16'' x 4''*

14''

Blower

12" H x 18" L

Service Access

Optional

Service Access

END VIEW

SIDE VIEW

(51 mm) (Blower)

#FR03 12/06

DRAIN/OVERFLOW

Product Shown: Amiga™ Pure Air® II Bath Left Hand Shown Model: BE30

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
