IWAKI PUMPS EH-E Series User manual

Read this manual before use of product

IWAKI

Electromagnetic Metering Pump

EH-E Type

Instruction Manual

T308-3 02/06

( )Country codes

IWAKI CO.,LTD. 6-6 Kanda-Sudacho 2-chome Chiyoda-ku Tokyo 101-8558 Japan

TEL:(81)3 3254 2935 FAX:3 3252 8892(http://www.iwakipumps.jp)

U.S.A. : IWAKI WALCHEM Corporation

Australia : IWAKI Pumps Australia Pty. Ltd.

Singapore : IWAKI Singapore Pte. Ltd.

Indonesia : IWAKI Singapore (Indonesia Branch)

Malaysia : IWAKIm Sdn. Bhd.

Taiwan : IWAKI Pumps Taiwan Co., Ltd.

Thailand : IWAKI (Thailand) Co.,Ltd.

Hong Kong : IWAKI Pumps Co., Ltd.

China : IWAKI Pumps Co., Ltd. (Guangzhou office)

China : IWAKI Pumps Co., Ltd. (Beijing office)

China : IWAKI Pumps (Shanghai) Co., Ltd.

Philippines : IWAKI Chemical Pumps Philippines, Inc.

Korea : IWAKI Korea Co.,Ltd.

TEL : (1)508 429 1440 FAX : 508 429 1386

TEL : (61)2 9899 2411 FAX : 2 9899 2421

TEL : (65)763 2744 FAX : 763 2372

TEL : (62)21 690 6607 FAX : 21 690 6612

TEL : (60)3 7803 8807 FAX : 3 7803 4800

TEL : (886)2 8227 6900 FAX : 2 8227 6818

TEL : (66)2 320 1303 FAX : 2 322 2477

TEL : (852)2 607 1168 FAX : 2 607 1000

TEL : (86)20 8130 0605 FAX : 20 8130 0601

TEL : (86)10 6442 7713 FAX : 10 6442 7712

TEL : (86)21 6272 7502 FAX : 21 6272 6929

TEL : (63)2 888 0245 FAX : 2 843 3096

TEL : (82)2 3474 0523 FAX : 2 3474 0221

Germany : IWAKI EUROPE GmbH

Italy : IWAKI Italia S.R.L.

Denmark : IWAKI Pumper A/S

Sweden : IWAKI Sverige AB

Finland : IWAKI Suomi Oy

Norway : IWAKI Norge AS

France : IWAKI France S.A.

U.K. : IWAKI PUMPS (UK) LTD.

Switzerland: IWAKI (Schweiz) AG

Austria : IWAKI (Austria) GmbH

Holland : IWAKI Holland B.V.

Spain : IWAKI Iberica Pumps, S.A.

Belgium : IWAKI Belgium n.v.

TEL : (49)2154 9254 0 FAX : 2154 1028

TEL : (39)02 990 3931 FAX : 02 990 42888

TEL : (45)48 24 2345 FAX : 48 24 2346

TEL : (46)8 511 72900 FAX : 8 511 72922

TEL : (358)9 2742714 FAX : 9 2742715

TEL : (47)66 81 16 60 FAX : 66 81 16 61

TEL : (33)1 69 63 33 70 FAX : 1 64 49 92 73

TEL : (44)1743 231363 FAX : 1743 366507

TEL : (41)32 3235024 FAX : 32 3226084

TEL : (43)2236 33469 FAX : 2236 33469

TEL : (31)297 241121 FAX : 297 273902

TEL : (34)943 630030 FAX : 943 628799

TEL : (32)1430 7007 FAX : 1430 7008

Thank you for choosing an Iwaki's EH-E Series metering pump. This instruction

manual deals with the correct installation, operation, maintenance, and trou-

bleshooting procedures for the EH-E model metering pump. Please read through it

carefully to ensure the optimum performance, safety and service of your pump.

Contents

IMPORTANT INSTRUCTION .........................................................................1

Safety Section ...........................................................................2

1. INTRODUCTION ......................................................................................5

1. Unpacking ............................................................................6

2. Operation Principle ...............................................................6

3. Specifications .......................................................................7

4. Operation Function .............................................................10

5. Controller Display ...............................................................12

6. Dimensions ........................................................................14

2. INSTALLATION ......................................................................................18

1. Notes on Installation ...........................................................19

2. Location .............................................................................21

3. Tubing ................................................................................22

4. Electrical Wiring ..................................................................25

3. OPERATION ..........................................................................................28

1. Precaution for Operation .....................................................29

1-1. Bleeding .....................................................................29

1-2. Adjustment of Discharge Capacity ...............................31

2. Operation ...........................................................................33

2-1. Overview Operating Scheme .......................................33

2-2. Setting and Operation of Controller .............................35

4. MAINTENANCE .....................................................................................45

1. Maintenance .......................................................................46

2. Diaphragm Replacement ....................................................46

3. Valve Replacement .............................................................46

4. Tubing ................................................................................46

5. Consumable parts ..............................................................46

6. Names of Part and Structure ...............................................47

7. Troubleshooting ..................................................................49

Types of Symbols

Indicates that "Warning" or "Caution" must be exercised. Inside

this triangle, a concrete and practical image provided as a warning

or caution message is depicted.

Indicates a prohibited action or procedure. Inside or near this cir-

cle, a concrete and practical image of the activity to be avoided is

depicted.

Indicates an important action or procedure which must be per-

formed or carried out without fail. Failure to follow the instructions

herein can lead to malfunction or damage to the pump.

For the Safe and Correct Handling of the Pump

• Read the "Safety Instructions" sections carefully to prevent accidents involving your

customers or other person and to avoid damage or loss of other assets. Always follow

the instructions and advice found in these sections.

• Observe and abide by the instructions described in this manual. These instructions are

very important for protecting pump users from dangerous conditions and situations

related with the use of the pump system.

• The symbols relate to the following meanings described below.

Warning

Caution

Important Instruction

Nonobservance or misapplication of the contents of

the "Warning" section could lead to a serious acci-

dent, including death or injury.

Nonobservance or misapplication of the contents of

the "Caution" section could lead to serious physical

injury to the user or serious damage to the product.

Safety Section

Warning

•Wear protectors

If you touch or come in contact with any type of hazardous chemical liquid, including

but not limited to chemicals, you may experience a serious injury. Wear protective

gear (protective mask, gloves, etc.) during the pump operation.

Wear protective

gear

•Turn off the power supply

Working without disconnecting the power supply cause an electrical shock. Before

engaging upon any working procedures involving the pump, make sure to turn the

power supply switch off and to stop the pump and other related devices.

Electrical Shock

•Terminate operation

When you detect or become aware of a dangerous sign or abnormal condition dur-

ing operation, terminate the operation immediately and start from the beginning

again.

•For specified application only

The use of a pump in any application other than those clearly specified may result in

injury or damage to the pump. Use the pump strictly in accordance with the pump

specifications and application range.

Prohibited

•No remodeling

Never remodel a pump. Otherwise, a serious accident may result. Iwaki will not be

responsible for any accident or damage of any kind which is caused by the user

remodeling the pump without first obtaining permission or instructions from lwaki.

No remodeling

•Operating site must be free of water and humidity

The pump is not designed to be water-proof or dust-proof. The use of the pump in

places where water splashes or humidity is high may result in an electrical shock or

short circuit.

Prohibited

Safety Section

Caution

•Spill-out accident

Protective measures should be taken against any accidental spill-out or leakage of

the operating liquid as a result of unexpected damage on the pump or the related

piping.

Caution

•Qualified operators only

The pump operator and pump operation supervisor must not allow any operators

who have little or no knowledge of the pump to run and operate the pump. Pump

operators must have a sound knowledge of the pump and its operation.

Prohibited

•Specified power only

Do not operate the pump on voltage which is not specified on the nameplate.

Failure to do so may result in damage or fire. Only the specified power level is to be

applied.

Prohibited

•Do not run the pump dry

Do not run the pump dry (without liquid inside the pump). Heat generated as a

result of abrasion between elements inside the pump during operation without liquid

may damage the inside of the pump.

Prohibited

•Do not wet or dampen

If an electric part or wiring gets wet with the liquid spilled over accidentally, a fire or

electrical shock may be caused. Install the system in a place free from liquid

spillage or leakage.

Do not wet or

dampen

•Do not damage or change power cable

Do not scratch, damage, process, or pull the power cable forcibly. An extra load

onto the cable, such as heating the cable or placing something heavy on the cable,

may damage the cable and finally cause a fire or an electrical shock.

Caution

•Ventilate

Poisoning may result during an operation which involves, toxic or odorous liquid.

Ventilate the operating site sufficiently.

Caution

•Damaged pump

Never operate a damaged pump. A damaged pump may cause leakage or electri-

cal shock.

Prohibited

Safety Section

Caution

•Arrange grounding

Do not operate the pump without connecting the grounding wire. Otherwise, an

electrical shock may result. Make sure the grounding wire is connected with

grounding terminal.

Grounding

•Install an earth leakage breaker

The operation of a pump without using an earth leakage breaker may cause an

electrical shock. Please install a leakage breaker in the system.

Electrical Shock

•Handling of power cable

Use of a defective or damaged power cable may result in a fire or electrical shock.

Handle the power cable carefully.

Electrical Shock

•Follow the instruction manual

Replace the consumable part by following the descriptions in the instruction manual.

Do not disassemble any part of the pump if the disassembling procedure for the part

in question is not included in the instruction manual.

•Disposal of used pump

Disposal of used or damaged pumps must be done in accordance with the relevant

local law and regulations. (Consult a licensed industrial waste products disposing

company.)

•Limited operating site and storage

Do not install or store the pump in the following places :

Places where a flammable gas or material is used or stored.

Places where the ambient temperature is extremely high (40 °C or higher) or

extremely low (0 °C or lower).

Prohibited

1. INTRODUCTION

1. Unpacking

...........................................

2. Operation Principle

.............................

3. Specifications

......................................

4. Operation Function

...........................

5. Controller Display

..............................

6. Dimensions

.......................................

1. Unpacking

After unpacking the goods, check the following

points to ascertain that the product is exactly as

you ordered.

If you find anything wrong, please get in touch with

your dealer.

(1) Do the model, voltage, etc., shown on the name-

plate represent what you ordered?

(2) Has the goods been damaged in transit? Are

the bolts and nuts loose?

2. Operation Principle

The EH Series electronic metering pump consists

of a pump unit, a drive unit, and a control unit.

The drive unit is an electromagnetic solenoid.

When the solenoid coil is energized by the control

unit the armature shaft moves forward due to the

magnetic force of the solenoid. The shaft is

attached to a PTFE faced diaphragm which is part

of the pump unit. The diaphragm is forced into the

pump head cavity decreasing volume and increas-

ing pressure which forces liquid in the pump head

out though the discharge check valves. When the

solenoid coil is de-energized, a spring returns the

armature to its starting position. This action pulls

the diaphragm out of the head cavity increasing

volume and decreasing pressure. Atmospheric

pressure then pushes liquid from the supply tank

through the suction check valves to refill the pump

head.

Control unit

Stroke length

adjusting dial

Drive unit

Pump

head

Valve

SpringPlunger Diaphragm

3. Specifications

•Pump identification

EH - E 30 PC - 23U P E 8 -

M M

asdf ghjk l

aSeries name EH Series

sDrive component E : 48 W

dDiaphragm effective diameter 30 : 30 mm 35 : 35 mm 45 : 45 mm 55 : 55 mm

fMaterial of liquid end

Symbol Pump head

& Fittings Gasket

VC PVC

PTFE

V6 PVC

PC GFRPP

VM M-PVC

FC PVDF

SH SUS316

Valve Balls Valve seat &

O-ring (Gasket) Diaphragm

CE FKM

PTFE

(bonded to EPDM)

SUS316 EPDM

CE FKM

CE PCTFE (PTFE)

HC276 SUS316 (PTFE)

PVC : Polyvinyl chloride (Transparent)

GFRPP : Glass fiber reinforced polypropylene

M-PVC : Polyvinyl chloride (Machined)

CE : Alumina ceramic

SUS316 : 316 Stainless steel

FKM : Fluoroelastomer

EPDM : Ethylene propylene diene methylene

PTFE : Polytetrafluoroethylene

PVDF : Polyvinylidenefluoride

HC276 : Hastelloy C276

gVoltage symbol

Symbol Voltage Input voltage Frequency

100 AC 100 V AC 90 ~ 110 V 50-60 Hz

11U AC 110 V, 115 V AC 90 ~ 126 V 50-60 Hz

20J AC 200 V AC 180 ~ 220 V 50-60 Hz

23U AC 230 V AC 207 ~ 253 V 50-60 Hz

20E AC 220, 230, 240 V AC 198 ~ 264 V 50-60 Hz

hPower code

P with plug

No symbol without plug

jController E : E type

kConnection

lSpecial configuration

01~99: Special material, special connection port diameter, etc.

•Controller identification

Symbol

Applicable hose dia. (ID ×OD) Type

8 ×

13 (mm) VC, V6, PC, VM

9 ×

12 (mm) VC, V6, PC, VM

10 ×

12 (mm) FC

1/2” ×

3/8” (inch) VC, V6, PC, VM, FC

14 Rc 3/8” SH

15 NPT 3/8” SH

9 Rc 1/4” SH

10 NPT 1/4” SH

10 ×

16 (mm) VC, V6, PC, VM

EHC - 100 P E - ****

asdfg

aController name

sVoltage symbol

50-60

dLead wire

fController

gSpecial configuration

10 0 AC 100 V AC 90 ~ 126 V

11 U AC 110 V, AC 115 V AC 90 ~ 126 V

20 J AC 200 V AC 180 ~ 220 V

20 E AC 220 V, AC 230 V, AC 240 V AC 198 ~ 264 V

23 U AC 230 V AC 207 ~ 253 V

P : with plug

0 ~ 99

No symbol : without plug

Points to be noted in handling

1. Do not detach the control unit unless unavoidable.

2. Never use the control unit with pumps having different symbols for driving unit and power source voltage

specified on the control unit. (Check the nameplate.)

Caution

Operation with a pump having different symbols for driving unit and power source voltage other than

those specified may cause failure or trouble in the electronic circuit of the control unit or the driving

unit of the pump.

This manual suits for next models

Table of contents

Other IWAKI PUMPS Water Pump manuals

IWAKI PUMPS

IWAKI PUMPS MD-F Series User manual

IWAKI PUMPS

IWAKI PUMPS MDM Series User manual

IWAKI PUMPS

IWAKI PUMPS EJ-B Series User manual

IWAKI PUMPS

IWAKI PUMPS EJ-B User manual

IWAKI PUMPS

IWAKI PUMPS MDF-L250 User manual

IWAKI PUMPS

IWAKI PUMPS AMP Series User manual

IWAKI PUMPS

IWAKI PUMPS Hicera V Series User manual

IWAKI PUMPS

IWAKI PUMPS FF Series User manual

IWAKI PUMPS

IWAKI PUMPS EWN-R User manual

IWAKI PUMPS

IWAKI PUMPS EWN-R User manual

IWAKI PUMPS

IWAKI PUMPS MX-F250 User manual

IWAKI PUMPS

IWAKI PUMPS PDS-105 RA User manual

IWAKI PUMPS

IWAKI PUMPS IX-D Series User manual

IWAKI PUMPS

IWAKI PUMPS FA Series User manual

IWAKI PUMPS

IWAKI PUMPS PDA-W Series User manual

IWAKI PUMPS

IWAKI PUMPS APN-110 Series User manual

IWAKI PUMPS

IWAKI PUMPS APN-450 User manual

IWAKI PUMPS

IWAKI PUMPS MX-F100 User manual

IWAKI PUMPS

IWAKI PUMPS EHN-B11VC User manual

IWAKI PUMPS

IWAKI PUMPS APN-110-D4 User manual

IWAKI PUMPS

IWAKI PUMPS NRD Series User manual

IWAKI PUMPS

IWAKI PUMPS Hi-Techno IX-B Series User manual

IWAKI PUMPS

IWAKI PUMPS EWN-R User manual

IWAKI PUMPS

IWAKI PUMPS EWN-W User manual

Popular Water Pump manuals by other brands

Neptun

Neptun NPHW 5500 operating instructions

Sensidyne

Sensidyne Gilian BDX-II Operation & service manual

Draper

Draper 47808 instructions

Trolla

Trolla 12820 manual

Sunfab

Sunfab SVH Series installation guide

WilTec

WilTec 50740 Operation manual

Fieldmann

Fieldmann FVC 5015 EK user manual

Everbilt

Everbilt EFSUB5-122HD Use and care guide

Graco

Graco Husky 3300e manual

esotec

esotec 101018 operating manual

moyno

moyno 2000 CC Service manual

Becker

Becker BASIC VASF 2.80/1-0.AC230 operating instructions

Sykes AmeriPumps

Sykes AmeriPumps GP100M Operation and maintenance instructions

DUROMAX

DUROMAX XP WX Series user manual

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 operating instructions

Franklin Electric

Franklin Electric IPS Installation & operation manual

Xylem

Xylem e-1532 Series instruction manual

Milton Roy

Milton Roy PRIMEROYAL instruction manual
