ISAFE MOBILE IS540.2 Instruction manual

IS540.2

QUICK START MANUAL

IS540.2 | MODEL M540A01

Document No. 1060MM01REV00

Version: 2023-06-28

i.safe MOBILE GmbH

i_Park Tauberfranken 10

97922 Lauda-Koenigshofen

Germany

Tel. +49 9343 60148-0

[email protected]

www.isafe-mobile.com

DEVICE OVERVIEW/FUNCTIONS

13 14 15

CONTENTS

English.............................................................................. 4

Deutsch............................................................................. 9

Česky .............................................................................. 15

Dansk.............................................................................. 20

Español ............................................................................ 25

Suomi.............................................................................. 31

Français............................................................................ 37

Magyar ............................................................................ 43

Italiano ............................................................................48

Nederlands ........................................................................54

Norsk .............................................................................. 60

Polski .............................................................................. 65

Português (EU)..................................................................... 71

Português (BR) ..................................................................... 76

Русский............................................................................ 82

Svenska ............................................................................88

Hrvatski............................................................................99

Slovenská.........................................................................100

Српски ...........................................................................105

Korean ........................................................................... 111

Japanese ........................................................................116

Chinese...........................................................................122

Arabic ............................................................................127

ENGLISH

FIRST

This Quick Start Manual contains all the important health and safety instructions for using the

device IS540.2 (model M540A01) safely.

Read the “Safety” section of this Quick Start Manual carefully before using the device. If you

do not follow these instructions or do not understand them, this could lead to death, severe

injuries and damage to the device.

Read the Operating Manual before using the device.

The Operating Manual with detailed information and instructions concerning the device

can be found at www.isafe-mobile.com/en/support/downloads

Also read the Safety Instructions before using the device. These can be found

in the device packaging and at www.isafe-mobile.com/en/support/downloads

Follow all instructions given on the device and on the packaging.

Follow local safety regulations.

SAFETY

USE IN EXPLOSION HAZARDOUS AREAS

Only use the device in explosion hazardous areas of zones2/22 or outside of

explosion hazardous areas.

Before entering an explosion hazardous area with the device,

•make sure that only approved accessories are connected to the device, see section

“Connecting approved accessories”,

•make sure that no gap can be seen between the two halves of the device,

•make sure the device is not damaged,

•make sure that all the labels on the device are readable,

•make sure the battery is screwed tight.

If you use the device in an explosion hazardous area,

•do not loosen the screws on the device,

•do not connect any accessories to the device,

•do not open any interface cover,

•do not charge the device,

•do not open the device,

•do not damage the device.

Switch o the device immediately and leave the explosion hazardous area without delay if

•malfunctions occur on the device,

•you have damaged the housing of the device,

•you have exposed the device to excessive loads,

•the labels on the device are no longer readable.

USE OUTSIDE OF EXPLOSION HAZARDOUS AREAS

Do not modify the device structurally.

Do not expose the device to high temperatures.

Do not expose the device to strong UV radiation.

Do not expose the device to processes with high electrical charges.

Do not expose the device to aggressive acids or bases.

Do not use the device in places where its use is prohibited.

Turn o the device in clinics or other medical facilities.

Always keep a safety distance of at least 15cm between the device and a pacemaker or

hearing aid. The device can aect the functioning of medical devices such as pacemakers and

hearing aids.

When using the device while driving a motor vehicle, be sure to comply with applicable

national laws.

WHEN USING EARPHONES OR HEADSETS

First set the volume control on the device to 50% of the maximum volume.

Gradually adjust the volume.

DEVICE OVERVIEW/FUNCTIONS (see illustration on page 2)

1 LOUDSPEAKER

2 FUNCTION KEY RED: Optional function, e.g. SOS - function can be assigned via

Button App (system integrated).

3 FRONT CAMERA

16PIN ISM INTERFACE: Connection for approved accessories. Also see section

“Connecting approved accessories”.

5 SIDE KEY RIGHT: Optional function, e.g. camera - function can be assigned via Button

App (system integrated).

6 MICROPHONE

7 USB INTERFACE:

Connection for the USB-C Cable or for other

equipment

approved

by i.safe MOBILE GmbH. Also see sections “Charging” and “Connecting approved

accessories”.

8 LOUDNESS CONTROL: Volume up/Volume down.

9 SIDE KEY LEFT: Optional function - function can be assigned via Button App (system

integrated).

10 POWER KEY: A long press switches the device on/o. A short press switches the stand-

by mode on/o.

11 SENSORS: Proximity sensor, light sensor.

12 EYELET: Eyelet for hand strap.

13 BACK CAMERA

14 LED FLASH

15 NOISE CANCELLING: Noise cancelling microphone.

16 LOUDSPEAKER: Loudspeaker for hands-free function.

17 BATTERY

18 CHARGING CONTACTS

PREPARATION

The device has a card holder with a slot for a nano-SIM card and with a slot for a microSD card

up to 128 GB.

Carefully pull the card holder out of the card slot.

Insert the SIM card into the nano-SIM card slot (1) with the gold-coloured contacts facing down.

Insert the microSD card into the slot provided (2) with the gold-colored contacts facing down.

Carefully slide the card holder into the card slot.

Place the battery in the battery compartment.

Hand-tighten the screws using the Torx Screwdriver provided.

Check that the battery is seated correctly and securely.

Activate eSIM

The device has a nano-SIM card slot and an additional eSIM. The eSIM is a non-removable,

integrated digital SIM. eSIM is not supported by all mobile service provider.

You can activate the eSIM in several ways:

1. Via the Android™ Setup Wizard during initial device setup:

Scan the eSIM QR code that you have received from your service provider or manually enter

the eID that you have received from your service provider.

2. Via the settings menu of the smartphone:

> Settings > Network & Internet > Mobile network (add Network) > Download SIM > scan (or

manually enter) eSIM QR code that you have received from your service provider.

SWITCHING ON

Press and hold the on/o key for about 3 seconds.

When turning on the device for the rst time, follow the instructions on the screen.

Enter the device or SIM PIN when the input dialog for the device or SIM PIN appears after

switching on.

If you have inserted two SIM cards, select a favorite card. Information on operating the device

can be found at www.isafe-mobile.com/en/support/service under the menu item “FAQ“.

CHARGING

Only charge the device outside of explosion hazardous areas.

Only charge the device using the USB-C Cable supplied or other charging equipment

approved by i.safe MOBILE GmbH.

Do not charge the device in the vicinity of ammable substances.

Only charge the device at ambient temperatures between 0°C to +45°C (+32°F to +113°F).

Charge the device under dry indoor conditions only.

Do not charge the device in environments dusty or humid.

Connect the adapter suitable for your country to the power supply unit.

Connect the USB-C Cable to the power supply unit.

Connect the USB-C Cable to the USB interface of the device.

CONNECTING APPROVED ACCESSORIES

Only connect accessories approved by i.safe MOBILE GmbH to the device. Accessories

approved by i.safe MOBILE GmbH can be found at www.isafe-mobile.com/en/products

Connect approved accessories to the 16-pin ISM interface of the device only outside of

explosion hazardous areas.

Never open the cover of the 16-pin ISM interface in explosion hazardous areas.

Operate approved accessories in explosion hazardous areas only on the 16-pin ISM interface

of the device. Wired connections via the USB interface are prohibited.

Connect the plug of the accessory securely to the 16-pin ISM interface of the device and

check that the plug is seated correctly and securely before entering explosion hazardous

areas.

Only remove approved accessories from the 16-pin ISM interface outside of explosion

hazardous areas.

Close the 16-pin ISM interface with the cover provided when you are not using accessories.

Only use USB interface outside of explosion hazardous areas.

Never open the cover of the USB interface in explosion hazardous areas.

Approved accessories can be connected to any 16-pin ISM interface and to the USB interface.

Loosen the screw on the 16-pin ISM interface cover using the Screwdriver included in the

approved accessory package. Remove the cover as shown.

Connect the plug of the approved accessory to the 16-pin ISM interface as shown.

Hand-tighten the screws.

Check that the plug is seated correctly and securely.

The USB interface is used for charging and data transfer.

Connect approved accessories or other devices to the USB interface only by using the USB-C

Cable or by using other equipment approved by i.safe MOBILE GmbH.

MAINTENANCE/REPAIR

Contact the i.safe MOBILE GmbH repair service at

www.isafe-mobile.com/en/support/service if the device is not working normally,

if the device needs to be repaired or if a replacement part is required.

RETURN SHIPMENT

Contact the i.safe MOBILE GmbH repair service at

www.isafe-mobile.com/en/support/service

CLEANING

Turn o the device before cleaning.

Do not charge the device while cleaning.

Do not use chemical agents for cleaning.

Clean the device and the Power Adapter with a soft, moistened antistatic cloth.

Clean the display screen regularly with a soft, antistatic cloth.

STORAGE

Store the device at a humidity of 10% to 60% at the following ambient temperatures:

Up to one month: -20°C to +45°C (-4°F to +113°F)

Up to 3 months: -10°C to +35°C (+14°F to +113°F)

Over 3 months: -10°C to +25°C (+14°F to +77°F)

If you do not use the device for a longer period of time, note the following:

Switch o the device.

For longer storage without use, charge the device to approx. 50% to 70% using the USB-C

Cable supplied or other charging equipment approved by i.safe MOBILE GmbH.

Charge the device every 3 to 6 months to avoid deep discharge.

Store it in a cool, dry place to keep the battery functional.

RECYCLING

DO NOT throw away batteries with household waste.

Always dispose electronic products, batteries and packaging material at the appro-

priate collection points. This way, you prevent uncontrolled waste disposal and

promote the recycling of material resources.

You can obtain further information from regional waste disposal companies,

state authorities or the i.safe MOBILE GmbH service centre responsible for your

country or region at www.isafe-mobile.com/en/support/service

TRADEMARKS

i.safe MOBILE GmbH and the i.safe MOBILE GmbH logo are registered trademarks of

the i.safe MOBILE GmbH.

Comes with the Google™ app and Google Chrome™

Google and Google Chrome are trademarks of Google LLC.

Android is a trademark of Google LLC.

All other trademarks and copyrights are the properties of their respective owners.

DEUTSCH

ZUERST

Diese Schnellstartanleitung enthält alle wichtigen gesundheits- und sicherheitsrelevanten

Anweisungen für eine sichere Verwendung des Geräts IS540.2 (Modell M540A01).

Lesen Sie vor der Verwendung des Geräts den Abschnitt „Sicherheit“ in dieser Schnellstar-

tanleitung sorgfältig durch. Wenn Sie die Sicherheitshinweise nicht beachten oder nicht

verstehen, kann dies zu Tod und schweren Verletzungen führen.

Lesen Sie vor der Verwendung des Geräts die Bedienungsanleitung!

Die Bedienungsanleitung mit detaillierten Informationen und Anweisungen zum Gerät

nden Sie unter www.isafe-mobile.com/de/support/downloads

Lesen Sie vor der Verwendung des Geräts auch die Sicherheitsvorschriften.

Diese nden Sie in der Verpackung Ihres Geräts und unter

www.isafe-mobile.com/de/support/downloads

Beachten Sie alle Anweisungen auf dem Gerät und auf der Verpackung.

Befolgen Sie die örtlichen Sicherheitsvorschriften.

SICHERHEIT

EINSATZ IN EXPLOSIONSGEFÄHRDETEN BEREICHEN

Verwenden Sie das Gerät nur in explosionsgefährdeten Bereichen der Zonen

2/22

oder außer-

halb von explosionsgefährdeten Bereichen.

Bevor Sie mit dem Gerät einen explosionsgefährdeten Bereich betreten,

•stellen Sie sicher, dass nur freigegebenes Zubehör am Gerät angeschlossen ist, siehe

Abschnitt „Freigegebenes Zubehör anschließen“,

•stellen Sie sicher, dass zwischen den beiden Gerätehälften kein Spalt erkennbar ist,

•stellen Sie sicher, dass das Gerät nicht beschädigt ist,

•stellen Sie sicher, dass alle Beschriftungen auf dem Gerät lesbar sind,

•stellen Sie sicher, dass die Batterie fest verschraubt ist.

Wenn Sie das Gerät innerhalb eines explosionsgefährdeten Bereiches verwenden,

•lösen Sie die Schrauben am Gerät nicht,

•schließen Sie kein Zubehör an das Gerät an,

•önen Sie keine Schnittstellenabdeckung,

•laden Sie das Gerät nicht,

•önen Sie das Gerät nicht,

•beschädigen Sie das Gerät nicht.

Schalten Sie das Gerät sofort aus und verlassen Sie umgehend den explosionsgefährdeten

Bereich, wenn

• am Gerät Fehlfunktionen auftreten,

• Sie das Gehäuse des Geräts beschädigt haben,

• Sie das Gerät übermäßigen Belastungen ausgesetzt haben,

• die Beschriftungen auf dem Gerät nicht mehr lesbar sind.

EINSATZ AUSSERHALB EXPLOSIONSGEFÄHRDETER BEREICHE

Verändern Sie das Gerät nicht baulich.

Setzen Sie das Gerät keinen hohen Temperaturen aus.

Setzen Sie das Gerät keiner starken UV-Strahlung aus.

Setzen Sie das Gerät keinen elektrisch stark auadenden Prozessen aus.

Setzen Sie das Gerät keinen aggressiven Säuren oder Basen aus.

Benutzen Sie das Gerät nicht an Orten, an denen das Benutzen verboten ist.

Schalten Sie das Gerät in Kliniken oder anderen medizinischen Einrichtungen aus.

Halten Sie immer einen Sicherheitsabstand von mindestens 15cm zwischen Gerät und

einem Herzschrittmacher oder einer Hörhilfe ein. Das Gerät kann die Funktion von

medizinischen Geräten wie Herzschrittmachern oder Hörhilfen beeinussen.

Achten Sie bei der Verwendung des Geräts während der Steuerung eines Kraftfahrzeugs

auf die entsprechenden Landesgesetze.

BEI DER VERWENDUNG VON KOPFHÖRERN ODER HEADSETS

Stellen Sie die Lautstärkeregelung am Gerät zuerst auf 50% der maximalen

Lautstärke ein.

Passen Sie die Lautstärke schrittweise an.

GERÄTEÜBERSICHT/FUNKTIONEN (siehe Abbildung Seite 2)

1LAUTSPRECHER

2 FUNKTIONSTASTE ROT: Optionale Funktion, z.B. SOS - Funktion kann über Button

App (systemintegriert) zugewiesen werden.

3KAMERA VORDERSEITE

16PIN ISMSCHNITTSTELLE:

Anschluss für freigegebenes

Zubehör.

Siehe auch Abschnitt „Freigegebenes Zubehör anschließen“.

5 SEITENTASTE RECHTS: Optionale Funktion, z.B. Kamera - Funktion kann über Button

App (systemintegriert) zugewiesen werden.

6MIKROFON

7USBSCHNITTSTELLE:Anschluss für das USB-C-Kabel

oder andere von der i.safe MOBILE GmbH freigegebene Geräte.

Siehe auch Abschnitte

„Laden“ und „Freigegebenes Zubehör anschließen“.

8LAUTSTÄRKEREGELUNG:Lauter/Leiser.

9 SEITENTASTE LINKS: Optionale Funktion - Funktion kann über Button App (systemin-

tegriert) zugewiesen werden.

This manual suits for next models

Table of contents

Other ISAFE MOBILE Cell Phone manuals

ISAFE MOBILE

ISAFE MOBILE IS930.2 Instruction manual

ISAFE MOBILE

ISAFE MOBILE M53A01 Instruction manual

ISAFE MOBILE

ISAFE MOBILE M360A01 User manual

ISAFE MOBILE

ISAFE MOBILE IS320.1 Operator's manual

ISAFE MOBILE

ISAFE MOBILE IS655.2 Instruction manual

ISAFE MOBILE

ISAFE MOBILE IS530.2 Instruction manual

ISAFE MOBILE

ISAFE MOBILE IS730.2 Instruction manual

ISAFE MOBILE

ISAFE MOBILE RG930EX Parts list manual

ISAFE MOBILE

ISAFE MOBILE IS330.1 Operator's manual

ISAFE MOBILE

ISAFE MOBILE IS655.RG Operator's manual

ISAFE MOBILE

ISAFE MOBILE ADVANTAGE 1 SERIES User manual

ISAFE MOBILE

ISAFE MOBILE IS725.2 Instruction manual

ISAFE MOBILE

ISAFE MOBILE IS330.1 User manual

ISAFE MOBILE

ISAFE MOBILE IS760.2 Instruction manual

ISAFE MOBILE

ISAFE MOBILE IS310.2 Instruction manual

ISAFE MOBILE

ISAFE MOBILE CHALLENGER 2.0 Operator's manual

ISAFE MOBILE

ISAFE MOBILE IS740.2 Operator's manual

ISAFE MOBILE

ISAFE MOBILE M53A01 User manual

ISAFE MOBILE

ISAFE MOBILE IS530.M1 User manual

ISAFE MOBILE

ISAFE MOBILE IS530.M1 Operator's manual

ISAFE MOBILE

ISAFE MOBILE IS540.M1 Instruction manual

ISAFE MOBILE

ISAFE MOBILE M655A01 Instruction manual

ISAFE MOBILE

ISAFE MOBILE innovation 2.0 Operator's manual

ISAFE MOBILE

ISAFE MOBILE EXECUTIVE 2.0 Operator's manual

Popular Cell Phone manuals by other brands

Zte

Zte BLADE A520 quick start guide

Nokia

Nokia Lumia 620 user guide

Blackbe;rry

Blackbe;rry KEYone Safety and product information

Bea-fon

Bea-fon X5 Premium quick guide

Blackbe;rry

Blackbe;rry 8707 Series user guide

Blackbe;rry

Blackbe;rry Storm Troubleshooting

LG LM-X420QN user guide

LifeWatch

LifeWatch V user guide

Bea-fon

Bea-fon SILVER LINE SL860 user guide

IKI Mobile

IKI Mobile KF4.5i user manual

Hitech

Hitech HT-850 user guide

Yezz

Yezz Fashion F10 user manual

Point Mobile

Point Mobile PM60 user manual

Blackbe;rry

Blackbe;rry Q10 user guide

Blackbe;rry

Blackbe;rry Bold 9900 user guide

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 user guide

LG LM-K420EMW user guide

LG Thrive user manual
