IRobot Discovery/400 series User manual

Discovery/400 series Owner’s Manual

Dear iRobot Roomba Owner,

Thank you for purchasing an iRobot Roomba vacuum cleaning

robot. You’ve joined the millions of people who clean with robots -

the smarter way to get it done.

Please take a few moments to read this manual and get acquainted

with your Roomba, to get the best performance from your robot.

If you have any questions, visit our website at www.irobot.com for

more information.

these exclusive beneﬁts:

• Take advantage of iRobot’s award-winning customer service

Get support tailored to your speciﬁc robot, including answers

to questions, maintenance tips, video demos, live chat and

more.

• Get product updates and other valuable information

Be among the ﬁrst to ﬁnd out about new robots, exclusive

discounts and special promotions.

When you register, you can also tell us about your experience

with your Roomba; iRobot listens to our customers and makes

enhancements to our robots based on your valued feedback. We’d

love to hear from you!

On behalf of the entire team, thank you for choosing iRobot; we

appreciate your business, feedback and loyalty.

Here’s to robots that make a difference!

Yours for less chores and more life,

Colin Angle

Chairman, CEO and Co-Founder

iRobot Corporation

P.S. Don’t miss out on your exclusive beneﬁts! Register your

Roomba online right now at www.irobot.com/register.

For more detailed information, visit: www.irobot.com 3

Important Tips

Roomba contains electronic parts. DO NOT submerge Roomba or spray it

with water. Clean with a dry cloth only.

For Best Performance

• Remove and clean Roomba’s brushes after every use.

• Empty Roomba’s bin and clean its lter after every use.

• Use a Virtual Wall®(optional accessory) to keep Roomba cleaning where

you want it.

• Use your Roomba frequently.

Battery Life

To extend Roomba’s battery life and keep Roomba cleaning at peak

performance:

• Always keep Roomba plugged in when not in use.

• Recharge Roomba as soon as possible. Waiting several days to

recharge Roomba can damage the battery.

• For storage off the charger, remove the battery from Roomba and store

in a cool, dry place.

• Blue or black batteries should be stored after Roomba has been

used.

• Yellow batteries should be stored after being fully charged.

4 iRobot Roomba Owner’s Manual

Table of Contents

iRobot Roomba Anatomy..................................... 5 - 10

Cleaning Pattern.........................................................11

Cleaning Modes..........................................................11

Cleaning System.........................................................12

Battery Storage and Charging ........................... 13 - 14

Virtual Wall (optional accessory for select models)... 15 - 16

Home Base (optional accessory for select models) ........17

Remote Control

(optional accessory for select models) ............................18

Scheduler Remote Control

(optional accessory for select models) ....................19 - 23

Maintenance ...................................................... 24 - 25

Troubleshooting......................................................... 26

Important Safety Instructions ................................... 27

iRobot Customer Care .............................................. 28

For more detailed information, visit: www.irobot.com 5

Cliff Sensor

Openings

Edge-Cleaning

Side Brush

Vacuum Inlet

Replaceable

Caster Wheel

Battery

Flexible

Brush

Brush Guard Release Tabs

Brush Bearings

Brush

Guard

Main

Brush

Brush Caps

iRobot Roomba Anatomy

6 iRobot Roomba Owner’s Manual

iRobot Roomba Anatomy

Power

and Clean

Button

Virtual Wall

Sensor

Bin Release Battery

Charger

Socket

Serial Port

Handle

Bin

4000 Model Series

For more detailed information, visit: www.irobot.com 7

iRobot Roomba Anatomy

User Interface

Power

and Clean

Button

Virtual Wall

Sensor

Bin Release

Battery

Charger

Socket

Serial Port

Handle

Bin

410 Model Series

Spot

Cleaning

Button Cleaning

Button

Status Light

Focus

Power Button

Charging

Indicator

8 iRobot Roomba Owner’s Manual

iRobot Roomba Anatomy

User Interface

411- 419 Model Series

Virtual Wall

Sensor

Bin Release

Battery Charger

Socket

Serial Port

Handle

Spot

Cleaning

Button

Cleaning

Button Max

Cleaning

Button

Status Light

Dirt Detect™

Power Button

Charging

Indicator

For more detailed information, visit: www.irobot.com 9

iRobot Roomba Anatomy

User Interface

420- 434 Model Series

Battery Charger Socket

Serial Port

Bin Release

Virtual Wall

Sensor

Handle

Power

Button

Spot

Button

Cleaning

Button

Max

Cleaning

Button

Status

Light Dirt

Detect™

10 iRobot Roomba Owner’s Manual

User Interface

435- 440 Model Series

iRobot Roomba Anatomy

Virtual Wall Sensor

Bin Release

Button Battery Charger

Socket

Serial Port

Bin

CLEAN/

Power

Button SPOT Button

SPOT Button

CLEAN/

Power

Button
