IRiver S10 1GB User manual
S10.
SERIES
S
•Intuitive iriver D-Click System™
•17.5g, ultra light player
•Comes with Lanyard Earphones
•Color OLED Display (1.15”)
•Plays up to 8 hours with internal rechargeable battery
•Supports music file such as MP3, WMA and OGG Q10
•FM radio and FM recording reservation
•Voice recording
•USB 2.0, Ultra Fast Data Transfer
• Comes with iriver plus 3 software
• Firmware Upgradable
• Alarm with real-time clock
Launching - Sep, 2006
Model variation
S10 1GB / S10 2GB *
Color variation
Black & White
Always enjoyable
*1GB=1,000MB = 1,000,000,000Byte. Not all memory space available for file storage.
Black & White Only
Simple Shining
and Stylish
S10.
1. Necklace Reborn
1) Earphone wires can be adjusted in length except in the hook part of the necklace to
allow you the maximum convenience.
2) The clip-on hook makes up for the potential shortcoming of the necklace-type earphone
wires that can easily be detached from the main body.
2. Pivot Function
S10 features the pivot function to provide greater convenience when using it in the
necklace form. The window automatically makes a pivotal turn to fit the display by 180
degress.
3. Lighter Than Ever
Stylish design, various functions, and internal battery: everything in just 17.5g. Lighter
than ever S10 in small size offers you the better portability and greater comfort for your
neck than ever.
4. D-Click System, Speed Along
S10 follows upon on the D-Click System of the U10 despite of its small size for the greater
user convenience. The command response rate was significantly enhanced to allow
easier and faster access to different services.
5. Colorful Display Organization
1.15-inch OLED offers you the brightest and clearest display of 65,000 colors. Mobile
emoticons can add an extra flare to the blend LED, and personally-set slide shows can be
used as a screen saver option.
6. Recharge? Dowload? Earphone? All in One from Now
A mini- USB port is all you need to recharge the power, download the music, and listen to
the music with S10 through the earphone port on the top part of the main body.
S10 Features - new concept, new style S10
SSERIES
S10.
S10 Functions – Small Yet Compact
SSERIES
1. Small in Size, Big in Performance
S10 may be small in size, but it does not leave any useful functions behind. It supports a
number of codec types including MP3, WMA, ASF, and OGG (including Q10), allows 8-
hour simultaneous play, and accommodates other basic functions. At the same time,
complementary functions such as the FM radio reception/recording, image viewer, voice
recording, timer, alarm, and portable data storage.
2. Storage Me Crazy!
Small yet powerful S10 goes far into offering large storage up to 2GB to leave no
consumer needs behind.
3. iriver Plus 3 Compatible
iriver Plus 3 supports the library function through which all contents including music, video,
image, and e-book files can be transmitted. Any contents of your choice can be dragged
and dropped into the iriver Plus 3 for transmission, and the image files can be
automatically transformed into the optimal size and type at the time of transmission.
4. FM Radio & Schedule Planner
Automated tuning and frequency memory functions allow you the easy-access to the
high-quality FM radio transmission. The programs of your choice can be recorded both on
site and through timer. The clock and alarm functions also make S10 the schedule
planner from your dream.
S10.
S10 Design – Simple Modernity
SSERIES
1. Brighter than the Jewelries: S10
S10 allows you the top of the time trendy look in simple modernity. Its small and thin
design Is sure to make you the fashion leader of the time anyway you want.
© COPYRIGHT 2006 iriver ALL RIGHT RESERVED
iriver is a registered trademark of ReignCom Ltd. All other company or product names are trademarks or registered trademarks of their respective owners.
All technical features are subject to change without notice. The final version of the product may differ slightly from the pictures and verbal descriptions provided
herein.
Detailed Specification
Series iriver S Series
Continuous Playback Time
Connection Type
Equalizer
Dimensions
Weight
Operational Temperature
Recording
Multimedia
Support File Type BMP
O/S Windows requirement Windows 98SE/ME/2000/XP
Product S10
Models in the S10 Capacity / Color 1GB / 2GB* (Black/White)
8 hours
USB 2.0
Normal / Classic / Live / Pop / Rock / Jazz / Ubass / Metal / Dance / Party / SRS 2.0 / Custom
EQ
Approx. 42(W) x 30(H) x 10.8(D) mm
Approx. 17.5g
-5 ~ 40
General
Voice, FM
Display Main Set Display 1.15-inch OLED Display (96x128)
Power Battery Built-in Lithium Polymer Rechargeable Battery
Frequency Range 20Hz~20kHz
Headphone Output Power 15mW + 15mW (at Max. Volume)
S/N Ratio 90dB
No. Channels Stereo (L+R)
Frequency Range KR,US,EU : 87.5MHz ~ 108MHz, JP : 76MHz ~ 108MHz
S/N Ratio 60dB : a weighted
Antenna Headphone / Earphone-Cord Antenna
Audio File Type MPEG 1/2/2.5 Layer 3, WMA, ASF, OGG
Bit Rate MP3, WMA : 8kbps ~ 320kbps / OGG : Up to Q10
Tag ID3 V1 Tag, ID3 V2 2.0, ID3 V2 3.0, ID3 V2 4.0
www.iriver.com
Audio
Support
FM Tuner
Audio
S10.
SSERIES
*1GB=1,000MB = 1,000,000,000Byte. Not all memory space available for file storage.
